PLATFORM | PC4000-6E S/N 08202 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	461 755 40	Grating	1	InternBDB: 40x300x2790 \| InternKon: 930 204 40 / 35
02	906 866 40	Grating	1	InternBDB: 40x240x2790 \| InternKon: 930 204 40 / 36
03	931 186 40	Platform	1	InternKon: 930 204 40 / 4
04	915 146 40	Grating	2	InternKon: 930 204 40 / 15
05	931 185 40	Platform	1	InternKon: 930 204 40 / 5
07	308 637 99	Bolt	16	InternBDB: M16x90 DIN00931 \| InternKon: 930 204 40 / 20
08	510 733 98	Resilient sleeve	32	InternBDB: 7 / 30x50 \| InternKon: 930 204 40 / 21
09	317 313 40	Grating	2	InternBDB: 40x300x630 \| InternKon: 930 204 40 / 78
10	440 998 40	Grating	5	InternBDB: 40x480x630 \| InternKon: 930 204 40 / 77
11	270 192 40	Grating	1	InternBDB: 40x300x720 \| InternKon: 930 204 40 / 83
12	930 236 40	Grating	2	InternKon: 930 204 40 / 81
13	323 315 40	Grating	1	InternBDB: 40x480x720 \| InternKon: 930 204 40 / 82
14	930 237 40	Grating	1	InternKon: 930 204 40 / 29
19	945 970 40	Sheet	1	InternKon: 930 204 40 / 85
20	930 218 40	Threaded plate	4	InternBDB: 20x200x100 \| InternKon: 930 204 40 / 101
21	930 213 40	Platform	1	InternKon: 930 204 40 / 17
22	510 728 98	Resilient sleeve	6	InternBDB: 25 / 45x80 \| InternKon: 930 204 40 / 30
23	308 404 99	Bolt	6	InternBDB: M24X140 \| InternKon: 930 204 40 / 31
25	931 191 40	Retainer	1	InternKon: 930 204 40 / 80
26	510 744 98	Resilient sleeve	20	InternBDB: 13 / 25x32 \| InternKon: 930 204 40 / 26
27	308 605 99	Bolt	20	InternBDB: M12x55 DIN00931 \| InternKon: 930 204 40 / 25
28	502 354 98	Counter sunk screws	105	InternBDB: M8x40 DIN00963 \| InternKon: 930 204 40 / 34
29	317 318 40	Plastic wing nut	105	InternKon: 930 204 40 / 33
30	317 319 40	Threaded block	105	InternKon: 930 204 40 / 32
31	324 395 40	Grating	1	InternBDB: 40x480x675 \| InternKon: 930 204 40 / 107
32	931 486 40	Strip	1	InternKon: 930 204 40 / 116
33	904 310 40	Grating	4	InternKon: 930 204 40 / 18
34	904 308 40	Angle	1	InternKon: 930 204 40 / 40
35	954 102 40	Sheet metal	1	InternKon: 930 204 40 / 39
36	912 731 40	Grating	1	InternKon: 930 204 40 / 51
37	905 087 40	Grating	1	InternKon: 930 204 40 / 46
38	334 600 99	Nut	148	InternBDB: M12 DIN00985 \| InternKon: 930 204 40 / 49
39	307 804 99	Bolt	2	InternBDB: M12x30 DIN00933 \| InternKon: 930 204 40 / 48
40	901 007 40	Console	1	InternKon: 930 204 40 / 2
41	901 004 40	Console	2	InternKon: 930 204 40 / 3
42	334 599 99	Nut	8	InternBDB: M8 DIN00985 \| InternKon: 930 204 40 / 42
43	307 754 99	Bolt	8	InternBDB: M8x25 DIN00933 \| InternKon: 930 204 40 / 41
44	904 313 40	Console	2	InternKon: 930 204 40 / 38
46	939 450 40	Sheet metal	1	InternKon: 930 204 40 / 47
48	340 467 99	Washer	186	InternBDB: B13 DIN00125 \| InternKon: 930 204 40 / 58
49	507 121 98	Bolt	6	InternBDB: PM12x25 \| InternKon: 930 204 40 / 52
50	937 598 40	Platform	1	InternKon: 930 204 40 / 50
51	904 307 40	Grating	1	InternKon: 930 204 40 / 43
60	945 946 40	Platform	1	InternKon: 945 969 40 / 1
61	930 235 40	Battery cover	1	InternKon: 945 969 40 / 2
62	945 756 40	Battery cover	1	InternKon: 945 969 40 / 3
63	943 809 40	Hinge ri.	2	InternKon: 945 969 40 / 4
64	943 808 40	Hinge le.	2	InternKon: 945 969 40 / 5
65	511 744 98	Handle	2	InternKon: 945 969 40 / 6
66	308 608 99	Bolt	4	InternBDB: M12x70 8.8 DIN00931 \| InternKon: 945 969 40 / 7
67	510 741 98	Resilient sleeve	4	InternBDB: 13/25x50 WN 34194840 \| InternKon: 945 969 40 / 8
