01 |
901 136 40
|
Frame |
1 |
InternKon: 931 100 40 / 1
|
|
|
|
03 |
931 101 40
|
Angle |
1 |
InternBDB: 5x352x1840 | InternKon: 931 100 40 / 2
|
|
|
|
04 |
270 187 40
|
Grid |
2 |
InternBDB: 2x40x360x780 | InternKon: 931 100 40 / 3
|
|
|
|
05 |
901 163 40
|
Grid |
1 |
InternKon: 931 100 40 / 5
|
|
|
|
06 |
901 164 40
|
Grid |
1 |
InternKon: 931 100 40 / 6
|
|
|
|
07 |
928 346 40
|
Grid |
1 |
InternBDB: 2x40x480x480 | InternKon: 931 100 40 / 7
|
|
|
|
08 |
901 165 40
|
Grid |
1 |
InternKon: 931 100 40 / 8
|
|
|
|
09 |
901 166 40
|
Grid |
1 |
InternKon: 931 100 40 / 9
|
|
|
|
10 |
907 221 40
|
Grid |
1 |
InternKon: 931 100 40 / 10
|
|
|
|
11 |
928 349 40
|
Grid |
1 |
InternKon: 931 100 40 / 13
|
|
|
|
12 |
340 111 99
|
Washer |
5 |
InternBDB: A14 / 7989 | InternKon: 931 100 40 / 15
|
|
|
|
13 |
324 539 40
|
Grid |
2 |
InternKon: 931 100 40 / 4
|
|
|
|
15 |
901 161 40
|
Plate |
2 |
InternBDB: 420x601 | InternKon: 931 100 40 / 24
|
|
|
|
16 |
931 448 40
|
Plate |
2 |
InternBDB: 420x574 | InternKon: 931 100 40 / 25
|
|
|
|
17 |
507 488 98
|
Thread pin |
16 |
InternBDB: PM 10x20 /32500 | InternKon: 931 100 40 / 26
|
|
|
|
18 |
307 425 99
|
Bolt |
7 |
InternBDB: M8x20 / 933 | InternKon: 931 100 40 / 27
|
|
|
|
19 |
317 319 40
|
Threaded block |
26 |
InternKon: 931 100 40 / 18
|
|
|
|
20 |
317 318 40
|
Wing nut, plastic |
26 |
InternKon: 931 100 40 / 19
|
|
|
|
21 |
502 354 98
|
Countersunk screw |
26 |
InternBDB: M8x40 /963 4.8 | InternKon: 931 100 40 / 20
|
|
|
|
22 |
931 105 40
|
Angle |
2 |
InternKon: 931 100 40 / 11
|
|
|
|
23 |
931 469 40
|
Foot plate |
1 |
InternKon: 931 100 40 / 12
|
|
|
|
24 |
510 130 98
|
Thread pin |
5 |
InternBDB: PM10x30 / 32500 | InternKon: 931 100 40 / 16
|
|
|
|
25 |
507 037 98
|
Nut |
21 |
InternBDB: M10 / 985 | InternKon: 931 100 40 / 17
|
|
|
|
26 |
308 637 99
|
Bolt |
4 |
InternBDB: M16x90 / 931 | InternKon: 931 100 40 / 21
|
|
|
|
27 |
334 601 99
|
Nut |
4 |
InternBDB: M16 / 985 | InternKon: 931 100 40 / 22
|
|
|
|
28 |
340 507 99
|
Washer |
7 |
InternBDB: A 8,4 / 125 | InternKon: 931 100 40 / 28
|
|
|
|
29 |
334 599 99
|
Nut |
7 |
InternBDB: M8 / 985 | InternKon: 931 100 40 / 29
|
|
