01 |
|
Switch framing |
1 |
InternBDB: 939 352 40 | InternKon: 944 002 40 / 1
|
355-2167d |
|
|
02 |
307 732 99
|
Bolt |
4 |
InternBDB: M6x25 /933 | InternKon: 944 002 40 / 21
|
|
|
|
03 |
343 106 99
|
Lock washer |
4 |
InternBDB: 6 /127 | InternKon: 944 002 40 / 22
|
|
|
|
04 |
|
Horn |
1 |
InternBDB: 256 886 40 | InternKon: 944 002 40 / 9
|
113-2150 |
|
|
05 |
941 398 40
|
Temperature sensor |
1 |
InternBDB: mit Messumformer W071P210330932 SIKA | InternKon: 944 002 40 / 34
|
|
|
|
06 |
309 691 40
|
Battery 12 V 200 AH |
2 |
InternKon: 944 002 40 / 23
|
|
|
|
07 |
307 777 99
|
Bolt |
6 |
InternBDB: M10x25 /933 10.9 | InternKon: 944 002 40 / 45
|
|
|
|
08 |
340 465 99
|
Washer |
20 |
InternBDB: 10,5/125 | InternKon: 944 002 40 / 46
|
|
|
|
09 |
350 768 99
|
Washer |
6 |
InternBDB: R11,0 DIN00440 | InternKon: 944 002 40 / 48
|
|
|
|
10 |
946 209 40
|
Retainer assy. |
3 |
InternKon: 944 002 40 / 49
|
|
|
|
11 |
655 530 40
|
Strab |
3 |
InternKon: 944 002 40 / 47
|
|
|
|
12 |
343 108 99
|
Lock washer |
1 |
InternBDB: 8 /127 | InternKon: 944 002 40 / 11
|
|
|
|
13 |
319 143 99
|
Screw |
1 |
InternBDB: M8x40 /912 | InternKon: 944 002 40 / 10
|
|
|
|
14 |
944 949 40
|
Harness X60a-X2 |
1 |
InternKon: 944 002 40 / 58
|
|
|
|
15 |
942 798 40
|
Harness - lighting equipment - pedestal |
1 |
InternKon: 944 002 40 / 19
|
|
|
|
16 |
944 116 40
|
Harness - horn |
1 |
InternKon: 944 002 40 / 20
|
|
|
|
17 |
939 347 40
|
Harness - temperature transmitter - outer temperature |
1 |
InternKon: 944 002 40 / 3
|
|
|
|
18 |
943 938 40
|
Harness - battery |
1 |
InternKon: 944 002 40 / 50
|
|
|
|
19 |
944 041 40
|
Harness - battery |
1 |
InternKon: 944 002 40 / 51
|
|
|
|
22 |
944 117 40
|
Cable VHMS-controller CN3A |
1 |
InternKon: 944 002 40 / 4
|
|
|
|
23 |
944 115 40
|
Cable VHMS-controller CN4A |
1 |
InternKon: 944 002 40 / 5
|
|
|
|
24 |
944 118 40
|
Cable VHMS-controller CN4B |
1 |
InternKon: 944 002 40 / 6
|
|
|
|
25 |
944 119 40
|
Cable VHMS-controller CN1A |
1 |
InternKon: 944 002 40 / 7
|
|
|
|
26 |
952 024 40
|
Cable Can-Bus |
1 |
InternKon: 944 002 40 / 8
|
|
|
|
27 |
0443452711
|
Clip |
1 |
InternKon: 944 002 40 / 27
|
|
|
|
28 |
307 754 99
|
Bolt |
5 |
InternBDB: M 8x25 DIN00933 | InternKon: 944 002 40 / 26
|
|
|
|
29 |
340 464 99
|
Washer |
47 |
InternBDB: 8,4 DIN 00125 | InternKon: 944 002 40 / 16
|
|
|
|
30 |
946 250 40
|
Load limitation valve |
1 |
InternBDB: Bosch Rexroth RC4-4/20+LIC/KOMPC051 TL | InternKon: 944 002 40 / 29
|
|
|
|
31 |
946 299 40
|
Harness - plug RC 4 |
1 |
InternKon: 944 002 40 / 86
|
|
|
|
32 |
943 429 40
|
Angle |
2 |
InternKon: 944 002 40 / 56
|
|
|
|
33 |
334 600 99
|
Nut |
4 |
InternBDB: M12/985 | InternKon: 944 002 40 / 54
|
|
|
|
34 |
340 467 40
|
Washer |
4 |
InternBDB: 13,0/125 | InternKon: 944 002 40 / 55
|
|
|
|
35 |
940 689 40
|
Moulding material |
2 |
InternBDB: 260x500 NK 20 | InternKon: 944 002 40 / 57
|
|
|
|
36 |
946 204 40
|
Cover assy. |
1 |
InternKon: 944 002 40 / 17
|
|
|
|
37 |
334 599 99
|
Nut |
43 |
InternBDB: M8/985 | InternKon: 944 002 40 / 15
|
|
|
|
38 |
944 044 40
|
Assembly box |
1 |
InternKon: 944 002 40 / 91
|
|
|
|
39 |
944 042 40
|
Assembly box |
1 |
InternKon: 944 002 40 / 93
|
|
|
|
40 |
946 462 40
|
Harness X63d-X2 |
1 |
InternKon: 944 002 40 / 53
|
|
|
|
41 |
507 596 98
|
Washer |
20 |
InternBDB: A 11 DIN07989 | InternKon: 944 002 40 / 52
|
|
|
|
42 |
797 350 73
|
VHMS-controller |
1 |
InternBDB: MH 801 007826177500 /7826-17-7501 | InternKon: 944 002 40 / 24
|
|
|
|
43 |
346 499 99
|
Lock washer |
4 |
InternBDB: 6 /128 | InternKon: 944 002 40 / 33
|
|
|
|
44 |
307 631 99
|
Bolt |
4 |
InternBDB: M6x10 /933 | InternKon: 944 002 40 / 30
|
|
|
|
45 |
307 740 99
|
Bolt |
4 |
InternBDB: M6x60 /933 | InternKon: 944 002 40 / 31
|
|
|
|
46 |
944 960 40
|
Harness X63c-2-X2 |
1 |
InternKon: 944 002 40 / 68
|
|
|
|
47 |
944 950 40
|
Harness X60b-X2 |
1 |
InternKon: 944 002 40 / 59
|
|
|
|
48 |
944 951 40
|
Harness X60c-X2 |
1 |
InternKon: 944 002 40 / 60
|
|
|
|
49 |
944 952 40
|
Harness X61a-X2 |
1 |
InternKon: 944 002 40 / 61
|
|
|
|
50 |
944 953 40
|
Harness X61b-X2 |
1 |
InternKon: 944 002 40 / 62
|
|
|
|
51 |
944 955 40
|
Harness X61c-X2 |
1 |
InternKon: 944 002 40 / 63
|
|
|
|
52 |
944 956 40
|
Harness X62a-X2 |
1 |
InternKon: 944 002 40 / 64
|
|
|
|
53 |
944 957 40
|
Harness X62b-X2 |
1 |
InternKon: 944 002 40 / 65
|
|
|
|
54 |
944 958 40
|
Harness X63a-2-X2 |
1 |
InternKon: 944 002 40 / 66
|
|
|
|
55 |
944 959 40
|
Harness X63b-2-X2 |
1 |
InternKon: 944 002 40 / 67
|
|
|
|
60 |
0443451610
|
Clip |
16 |
InternKon: 944 002 40 / 12
|
|
|
|
61 |
343 610 99
|
Washer |
14 |
InternBDB: 10,5/6798 | InternKon: 944 002 40 / 14
|
|
|
|
62 |
507 037 98
|
Nut |
14 |
InternBDB: M10/985 | InternKon: 944 002 40 / 13
|
|
|
|
63 |
0443451210
|
Clip |
18 |
InternKon: 944 002 40 / 18
|
|
|
|
64 |
944 110 40
|
Retainer assy. |
1 |
InternKon: 944 002 40 / 35
|
|
|
|
65 |
307 775 99
|
Bolt |
2 |
InternBDB: M10x20/933 | InternKon: 944 002 40 / 36
|
|
|
|
66 |
343 855 99
|
Lock washer |
2 |
InternBDB: 10/7980 | InternKon: 944 002 40 / 38
|
|
|
|
67 |
332 197 99
|
Nut |
2 |
InternBDB: M10/934 | InternKon: 944 002 40 / 37
|
|
|
|
68 |
509 064 98
|
Clamp set |
1 |
InternBDB: S-5-E/3015 | InternKon: 944 002 40 / 39
|
|
|
|
69 |
500 398 98
|
Cover plate |
1 |
InternBDB: S-DP-A-5/3015 | InternKon: 944 002 40 / 40
|
|
|
|
70 |
302 178 99
|
Bolt |
2 |
InternBDB: M16x130/601 | InternKon: 944 002 40 / 41
|
|
|
|
71 |
504 005 98
|
Clamp set |
1 |
InternBDB: S-4-G-38/3015 | InternKon: 944 002 40 / 42
|
|
|
|
72 |
502 965 98
|
Cover plate |
1 |
InternBDB: S-DP-S-4/3015 | InternKon: 944 002 40 / 43
|
|
|
|
73 |
308 612 99
|
Bolt |
2 |
InternBDB: M12x100/931 | InternKon: 944 002 40 / 44
|
|
|
|
74 |
0819320010
|
Clip |
1 |
InternKon: 944 002 40 / 87
|
|
|
|
75 |
944 961 40
|
Harness X64a-X2 |
1 |
InternKon: 944 002 40 / 69
|
|
|
|
76 |
944 962 40
|
Harness X65a-X2 |
1 |
InternKon: 944 002 40 / 70
|
|
|
|
77 |
944 963 40
|
Harness X65b-X2 |
1 |
InternKon: 944 002 40 / 71
|
|
|
|
78 |
944 965 40
|
Harness X67a-X2 |
1 |
InternKon: 944 002 40 / 73
|
|
|
|
79 |
944 966 40
|
Harness X67b-X2 |
1 |
InternKon: 944 002 40 / 74
|
|
|
|
80 |
944 967 40
|
Harness X67c-X2 |
1 |
InternKon: 944 002 40 / 75
|
|
|
|
81 |
944 968 40
|
Harness X68a-X2 |
1 |
InternKon: 944 002 40 / 76
|
|
|
|
82 |
944 969 40
|
Harness X85a-X2 |
1 |
InternKon: 944 002 40 / 77
|
|
|
|
83 |
944 970 40
|
Harness X85b-X2 |
1 |
InternKon: 944 002 40 / 78
|
|
|
|
84 |
944 971 40
|
Harness X85c-X2 |
1 |
InternKon: 944 002 40 / 79
|
|
|
|
85 |
944 972 40
|
Harness X85d-X2 |
1 |
InternKon: 944 002 40 / 80
|
|
|
|
86 |
944 973 40
|
Harness X85e-X2 |
1 |
InternKon: 944 002 40 / 81
|
|
|
|
87 |
944 974 40
|
Harness X85f-X2 |
1 |
InternKon: 944 002 40 / 82
|
|
|
|
88 |
944 975 40
|
Harness X85g-X2 |
1 |
InternKon: 944 002 40 / 83
|
|
|
|
89 |
944 976 40
|
Harness X85h-X2 |
1 |
InternKon: 944 002 40 / 84
|
|
|
|
90 |
944 964 40
|
Harness X66a-X2 |
1 |
InternKon: 944 002 40 / 72
|
|
|
|
91 |
946 222 40
|
Cap |
6 |
InternBDB: DT 18 | InternKon: 944 002 40 / 101
|
|
|
|
92 |
946 220 40
|
Cap |
6 |
InternBDB: DT 24 | InternKon: 944 002 40 / 102
|
|
|
|
93 |
946 224 40
|
Cap |
6 |
InternBDB: DT 24 | InternKon: 944 002 40 / 103
|
|
|
|
94 |
946 218 40
|
Cap |
6 |
InternBDB: DT 18 | InternKon: 944 002 40 / 104
|
|
|
|
95 |
307 727 99
|
Bolt |
12 |
InternBDB: M6x12/933 | InternKon: 944 002 40 / 105
|
|
|
|
96 |
340 463 99
|
Washer |
12 |
InternBDB: 6,4/125 | InternKon: 944 002 40 / 106
|
|
|
|
97 |
896 521 40
|
End pin |
1 |
InternBDB: Pflitsch 4,0x25 | InternKon: 944 116 40 / 3
|
|
|
|
98 |
056 070 40
|
Cable sleeve 1,0 - 1,5 |
452 |
InternKon: 944 116 40 / 10
|
|
|
|
99 |
940 471 40
|
Fitting M16/DN10 |
1 |
InternBDB: PMA BVIR-M160 | InternKon: 944 116 40 / 1
|
|
|
|
100 |
907 704 40
|
Cable union |
1 |
InternBDB: Pflitsch 21650YNPM3x3,5 | InternKon: 944 116 40 / 2
|
|
|
|
101 |
055 108 40
|
Cable shoe |
1 |
InternBDB: 2,5 | InternKon: 944 116 40 / 8
|
|
|
|
102 |
932 530 40
|
Cable shoe |
1 |
InternBDB: 33408 000 000 DIN 46237 | InternKon: 944 116 40 / 7
|
|
|
|
103 |
940 461 40
|
Insulating tube B5x0,6 |
-2 |
InternBDB: B5x0,6 PUR 70 Shore | InternKon: 944 116 40 / 9
|
|
|
|
106 |
634 173 40
|
E/A - Cable, binear |
5 |
InternBDB: 4306.02.008 Intercontrol | InternKon: 939 352 40 / 110
|
|
|
|
107 |
907 661 40
|
E/A - Cable, analog |
3 |
InternBDB: 4306.04.003 Intercontrol | InternKon: 939 352 40 / 111
|
|
|
|
108 |
655 631 40
|
Pipe adapter DN 12/10 |
1 |
InternBDB: BAVR-12 T 10 T | InternKon: 942 798 40 / 4
|
|
|
|
109 |
906 420 40
|
T-Distributor DN12 |
1 |
InternBDB: PMA BFTL-12 12 12TTT | InternKon: 942 798 40 / 3
|
|
|
|
110 |
255 992 40
|
Push-on contact housing |
1 |
InternBDB: AMP 180900/160449-1 | InternKon: 942 798 40 / 6
|
|
|
|
111 |
323 961 40
|
Sleeve |
1 |
InternBDB: 35180 6,3x0,8 | InternKon: 942 798 40 / 8
|
|
|
|
112 |
907 480 40
|
Cable union DN 10-90 |
1 |
InternBDB: PMA BVWV-M160 | InternKon: 942 798 40 / 9
|
|
|
|
113 |
517 320 98
|
Cable nut |
1 |
InternBDB: M12x1,5 DIN 50262 | InternKon: 942 798 40 / 10
|
|
|
|
114 |
440 092 40
|
Plug |
1 |
InternBDB: 1,5-2,5 | InternKon: 942 798 40 / 11
|
|
|
|
115 |
504 546 99
|
Cable nut |
1 |
InternBDB: APG 9 DIN 46258 | InternKon: 942 798 40 / 12
|
|
|
|
116 |
907 477 40
|
Cable union DN 12 |
3 |
InternBDB: PMA BVNV-M162 | InternKon: 942 798 40 / 13
|
|
|
|
117 |
517 327 98
|
Reducing M20M16 |
2 |
InternBDB: M20x1,5 M16x1,5/50262 | InternKon: 942 798 40 / 14
|
|
|
|
118 |
517 321 98
|
Cable nut |
2 |
InternBDB: M16x1,5 DIN 50262 | InternKon: 942 798 40 / 15
|
|
|
|
119 |
926 550 40
|
Spotlight assy. |
1 |
InternKon: 942 798 40 / 7
|
|
|
|
120 |
634 009 40
|
Spotlight without lamp |
-2 |
InternKon: 926 550 40 / 1
|
|
|
|
121 |
507 383 99
|
Halogen lamp 24V /70W |
1 |
InternBDB: H1 24V /70W | InternKon: 926 550 40 / 2
|
|
|
|
122 |
769 155 73
|
Seal |
1 |
InternBDB: ABL 18-1 401
|
|
|
|
123 |
769 156 73
|
Glass, white |
1 |
InternBDB: ABL 18-10201
|
|
|
|
126 |
906 632 40
|
Plug |
1 |
InternBDB: AMP 176117-6 14-pol. Grau | InternKon: 944 115 40 / 1
|
|
|
|
127 |
901 394 40
|
Cable bush assy. |
2 |
InternKon: 944 115 40 / 3
|
|
|
|
128 |
906 577 40
|
Cable |
-2 |
InternBDB: UIC H+S 552 039.12 | InternKon: 944 115 40 / 8
|
|
|
|
130 |
906 631 40
|
Plug |
1 |
InternBDB: AMP 176114-6 10-pol. Grau | InternKon: 944 118 40 / 1
|
|
|
|
131 |
906 647 40
|
T-Splitter |
4 |
InternBDB: Deutsch DT-3P-P007 | InternKon: 944 120 40 / 1
|
|
|
|
132 |
913 246 40
|
Cable bush assy. |
6 |
InternKon: 944 120 40 / 2
|
|
|
|
133 |
906 947 40
|
Cable shoe |
2 |
InternBDB: 03530.311.011 | InternKon: 944 041 40 / 1
|
|
|
|
134 |
896 727 40
|
Cabel 10,0 |
-2 |
InternKon: 944 041 40 / 3
|
|
|
|
135 |
906 943 40
|
Pole end plate, black |
1 |
InternBDB: Mastervolt 06-84-57314/T 457 N3 V14 | InternKon: 944 041 40 / 4
|
|
|
|
136 |
906 942 40
|
Pole end plate, red |
1 |
InternBDB: Mastervolt 06-84-57302/T 457 N3 V02 | InternKon: 944 041 40 / 5
|
|
|
|
137 |
940 464 40
|
Insulating tube B8x0,7 |
-2 |
InternBDB: B8x0,7 PUR 70 Shore | InternKon: 944 041 40 / 9
|
|
|
|
140 |
940 471 40
|
Fitting M16/DN12 |
1 |
InternBDB: PMA BVIR-M160 | InternKon: 939 347 40 / 7
|
|
|
|
141 |
907 703 40
|
Cable union |
1 |
InternBDB: Pflitsch 21650YNPM4x3 | InternKon: 939 347 40 / 5
|
|
|
|
142 |
056 292 40
|
Cable strap |
3 |
InternBDB: Ty 23 11 | InternKon: 939 347 40 / 4
|
|
|
|
143 |
256 514 40
|
Plate |
27 |
InternKon: 939 347 40 / 3
|
|
|
|
144 |
795 495 73
|
Plug assy. |
1 |
InternBDB: 0819214920 | InternKon: 939 347 40 / 1
|
|
|
|
145 |
940 462 40
|
Insulating tube B6x0,6 |
-2 |
InternBDB: B6x0,6 PUR 70 Shore | InternKon: 939 347 40 / 2
|
|
|
|
146 |
896 520 40
|
End pin |
2 |
InternBDB: 3,0x25 | InternKon: 939 347 40 / 11
|
|
|
|
147 |
0819100770
|
Sealing pin |
2 |
InternBDB: NO114017 | InternKon: 939 347 40 / 12
|
|
|
|
149 |
500 090 98
|
Wire end ferrule 0,75-6 |
11 |
InternKon: 944 960 40 / 10
|
|
|
|
150 |
907 877 40
|
Cable 2x0,75 |
-2 |
InternBDB: 2x0,75 | InternKon: 944 960 40 / 8
|
|
|
|
151 |
907 981 40
|
Fitting DN29 |
1 |
InternBDB: PMA BVIVG-U359 | InternKon: 944 960 40 / 4
|
|
|
|
152 |
655 696 40
|
Cable protection hose DN 29 |
-2 |
InternBDB: PMA VCST-29 B | InternKon: 944 960 40 / 6
|
|
|
|
153 |
795 145 73
|
Socket |
13 |
InternBDB: Deutsch HD34-24-31SE-059 0819194106 | InternKon: 944 949 40 / 1
|
|
|
|
154 |
795 154 73
|
Cablesocket |
406 |
InternBDB: Deutsch 0819105420 / 0462-201-16141 / KES 08191 | InternKon: 944 949 40 / 2
|
|
|
|
155 |
940 629 40
|
Warmth shrink hose |
-2 |
InternBDB: 0,090 m / BÑŒrklin .05060 91F2570 | InternKon: 944 949 40 / 4
|
|
|
|
156 |
907 980 40
|
Fitting DN23 |
16 |
InternBDB: PMA BVIVG-U353 | InternKon: 944 949 40 / 3
|
|
|
|
157 |
655 652 40
|
Cable protection hose DN 23 |
-2 |
InternBDB: PMA VCSG-23 B | InternKon: 944 949 40 / 5
|
|
|
|
158 |
174 411 40
|
Cable strap |
28 |
InternBDB: 200x4,8 5315/C | InternKon: 944 949 40 / 9
|
|
|
|
160 |
317 319 40
|
Threaded bloc |
4 |
InternKon: 915 249 40 / 6
|
|
|
|
161 |
340 464 99
|
Washer |
46 |
InternBDB: 8,4 /125 | InternKon: 915 249 40 / 8
|
|
|
|
162 |
346 510 99
|
Lock washer |
9 |
InternBDB: 8 /128 | InternKon: 915 249 40 / 9
|
|
|
|
163 |
915 248 40
|
Plate |
-2 |
InternKon: 915 249 40 / 1
|
|
|
|
164 |
310 045 99
|
Threaded rod ca. 400 lg. |
-2 |
InternBDB: M 6 /975 | InternKon: 915 249 40 / 2
|
|
|
|
165 |
906 231 40
|
Circular bearing |
8 |
InternBDB: 521 8062 | InternKon: 915 249 40 / 3
|
|
|
|
166 |
350 762 99
|
Washer |
8 |
InternBDB: R 6,6 /440 | InternKon: 915 249 40 / 5
|
|
|
|
167 |
307 752 99
|
Bolt |
4 |
InternBDB: M8x20 /933 | InternKon: 915 249 40 / 7
|
|
|
|
168 |
507 025 98
|
Nut |
8 |
InternBDB: M6/985 | InternKon: 915 249 40 / 4
|
|
|
|
170 |
932 947 40
|
Plug housing 52-pole |
1 |
InternBDB: AMP-TYCO MT2/JPT R902602414 | InternKon: 946 299 40 / 1
|
|
|
|
171 |
940 747 40
|
Cable 20x0,5 |
-2 |
InternKon: 946 299 40 / 2
|
|
|
|
172 |
940 467 40
|
Insulating tube 14x1 |
-2 |
InternBDB: B 14x1 Sievert | InternKon: 946 299 40 / 5
|
|
|
|
173 |
907 653 40
|
Warmth shrink hose |
-2 |
InternBDB: BÑŒrklin 91F3752 | InternKon: 946 299 40 / 11
|
|
|
|
174 |
907 641 40
|
Wire end ferrule 0,5 |
20 |
InternKon: 946 299 40 / 6
|
|
|
|
175 |
907 477 40
|
Cable union DN 12 |
2 |
InternBDB: PMA BVYR-121010 TTT | InternKon: 943 938 40 / 2
|
|
|
|
176 |
655 649 40
|
Cable protection hose DN 10 |
-2 |
InternBDB: PMA VCST-10 B | InternKon: 943 938 40 / 3
|
|
|
|
177 |
655 625 40
|
Distributor DN12/10 |
1 |
InternBDB: PMA BVYR-12 10 10 TTT | InternKon: 943 938 40 / 1
|
|
|
|
178 |
655 650 40
|
Cable protection hose DN 12 |
-2 |
InternBDB: PMA VCST-12 B | InternKon: 943 938 40 / 4
|
|
|
|
179 |
515 214 40
|
Cable 2,5 |
-2 |
InternKon: 943 938 40 / 7
|
|
|
|
180 |
055 114 40
|
Cable shoe |
4 |
InternBDB: 2,5 | InternKon: 943 938 40 / 5
|
|
|
|
181 |
056 071 40
|
Cable sleeve 2,5 |
72 |
InternKon: 943 938 40 / 6
|
|
|
|
183 |
795 141 73
|
Socket |
7 |
InternBDB: Deutsch HD34-18-14SE-059 0819124106 | InternKon: 944 951 40 / 1
|
|
|
|
184 |
907 975 40
|
Fitting DN17 |
9 |
InternBDB: PMA BVIVG-U297 | InternKon: 944 951 40 / 4
|
|
|
|
185 |
655 651 40
|
Cable protection hose DN 17 |
-2 |
InternBDB: PMA VCST-17 B | InternKon: 944 951 40 / 6
|
|
|
|
186 |
795 122 73
|
Sealing plate |
52 |
InternBDB: 0819100770 KES114 017 | InternKon: 944 951 40 / 3
|
|
|
|
187 |
940 169 40
|
Cable 4x1,0 |
-2 |
InternBDB: Kemper 600c | InternKon: 946 462 40 / 7
|
|
|
|
189 |
0819174106
|
Socket |
1 |
InternBDB: Deutsch HD34-24-16SE-059 795 143 73 | InternKon: 944 964 40 / 1
|
|
|
|
190 |
0819150809
|
Panel lock washer |
-2 |
InternBDB: Deutsch 112264 | InternKon: 944 964 40 / 14
|
|
|
|
191 |
0819150808
|
Panel nut |
-2 |
InternBDB: Deutsch 112263-90 | InternKon: 944 964 40 / 15
|
|
|
|
192 |
941328 40
|
Seal ring |
-2 |
InternBDB: 44x51x | InternKon: 944 964 40 / 16
|
|
|
|
195 |
941 329 40
|
Seal ring |
-2 |
InternBDB: 39x44x2
|
|
|
|
196 |
906 634 40
|
Plug |
1 |
InternBDB: AMP 176119-6 20-pol. grau | InternKon: 944 119 40 / 1
|
|
|
|
197 |
906 635 40
|
Contact |
28 |
InternBDB: AMP 175025-7 | InternKon: 944 119 40 / 2
|
|
|
|
198 |
515 213 40
|
Cable 1,0 |
-2 |
InternKon: 944 119 40 / 4
|
|
|
|
200 |
906 633 40
|
Plug |
1 |
InternBDB: AMP 176118-6 18-pol. Grau | InternKon: 944 117 40 / 1
|
|
|
|
201 |
621 241 40
|
Soldering sleeve |
1 |
InternBDB: Souriau S-DSUP-09P 130N00-033 | InternKon: 944 117 40 / 3
|
|
|
|
202 |
621 242 40
|
Connector |
1 |
InternBDB: Souriau S-DSUP-HM090-U00-791 0-031 | InternKon: 944 117 40 / 4
|
|
|
|
203 |
634 576 40
|
Control line |
-2 |
InternBDB: BÑŒrklin 100AA-201 mit Abschirmung | InternKon: 944 117 40 / 7
|
|
|
|
204 |
940 726 40
|
Light switch |
1 |
InternBDB: Santon 51LC1K6 TL | InternKon: 944 781 40 / 1
|
|
|
|
205 |
321 010 99
|
Screw |
4 |
InternBDB: M5x25/84 | InternKon: 944 781 40 / 2
|
|
|
|
207 |
795 144 73
|
Socket |
1 |
InternBDB: Deutsch HD34-24-23SE-059 0819184106 | InternKon: 944 953 40 / 1
|
|
|
|
208 |
795 140 73
|
Socket |
2 |
InternBDB: Deutsch HD34-18-8SE-059 0819114106 | InternKon: 944 955 40 / 1
|
|
|
|
210 |
940 463 40
|
Insulating tube B7x0,7 |
-2 |
InternBDB: B7x0,7 PUR 70 Shore | InternKon: 944 117 40 / 8
|
|
|
|
211 |
795 174 73
|
Cablesocket |
55 |
InternBDB: Deutsch 0819105440 / 0462-203-12141 / KES 08191 | InternKon: 944 959 40 / 2
|
|
|
|
213 |
795 142 73
|
Socket |
4 |
InternBDB: Deutsch HD34-24-16SE-059 0819164106 | InternKon: 944 971 40 / 1
|
|
