ELECTRIC EQUIPMENT | PC4000-6 S/N 08195 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC4000-6 S/N 08195

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?		Lighting equipment	-2		355-2106b
?		Battery cables	-2		355-2130i
?		Cables oil tank	-2		355-2138c
?		Cables - tank sensor	-2		355-2140a
?		Electr. parts - ladder	-2		355-2143b
?		Electr. parts - air intake	-2		355-2146b
?		Electric-Cab Support	-2		355-2134i
?		Cables - control blocks - h.p.-filter	-2		355-2181b
?		Cables - control- and filter plate	-2		355-2183d
?		Cables - engine and transmitter	-2		355-2185e
?		Cables Pump Distributor Gear	-2		355-2156c
?	340 465 99	Washer	10	InternBDB: B 10,5 / DIN 125 / 140HV \| InternKon: 944 011 40 / 2
?	938 576 40	Holding device	5	InternKon: 944 011 40 / 1
?	307 780 99	Bolt	5	InternBDB: M 10 x 35 / DIN 933 / 8.8 \| InternKon: 944 011 40 / 3
?	507 037 98	Nut	5	InternBDB: M 10 / DIN 985 / 8 \| InternKon: 944 011 40 / 4
?	938 333 40	Cable grommet	1	InternKon: 944 011 40 / 5
?	510 745 98	Resilient sleeve	2	InternBDB: 13/25x40 / WN 34194840 / 42CrMo4-TQ+T \| InternKon: 944 011 40 / 6
?	307 810 99	Bolt	2	InternBDB: M 12 x 60 / DIN 933 / 8.8 \| InternKon: 944 011 40 / 7
?	308 624 99	Screw	1	InternBDB: M10x65 / DIN 931 \| InternKon: 944 003 40 / 8
?	340 611 99	Washer	15	InternBDB: 14/1440 \| InternKon: 944 003 40 / 4
?	340 465 99	Washer	19	InternBDB: 10,5/125 \| InternKon: 944 003 40 / 6
?	507 037 98	Nut	17	InternBDB: M10/985 \| InternKon: 944 003 40 / 5
?	510 746 99	Resilient sleeve	4	InternBDB: 10,5 / 25x35 \| InternKon: 944 003 40 / 7
?	0443453211	Clip	6	InternKon: 944 003 40 / 1
?	0443451610	Clip	9	InternKon: 944 003 40 / 2
?	0443451210	Clip	6	InternKon: 944 003 40 / 3
?	500 399 98	Weld-on plate	2	InternBDB: S-AP-A-5 / DIN 3015 / W1 \| InternKon: 944 011 40 / 8
?	502 977 98	Clamp pair	2	InternBDB: S-4-G-50 / DIN 3015 / PA \| InternKon: 944 011 40 / 9
?	511 858 98	Cover plate	2	InternBDB: L-5 / DIN 3015 / W1 \| InternKon: 944 011 40 / 10
?	307 816 99	Bolt	4	InternBDB: M12 x 100 / DIN 933 / 8.8 \| InternKon: 944 011 40 / 11
?	343 006 99	Washer	4	InternBDB: 13 / DIN 93 / USt13-03 \| InternKon: 944 011 40 / 12
