Diagram image 1 of 2

PC4000-6 S/N 08195

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-6 S/N 08195

? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?		Radiator assembly	1	InternBDB: 928 704 40 \| InternKon: 942 290 40 / 1	991-0602
?	891 479 40	Fan cage	1	InternKon: 942 290 40 / 8
?	891 478 40	Fan cage	1	InternKon: 942 290 40 / 7
?	891 481 40	Fan cage	1	InternKon: 942 290 40 / 9
?	908 029 40	Plate	1	InternKon: 942 290 40 / 102
?	891 476 40	Plate	1	InternKon: 942 290 40 / 2
?	607 003 40	Plate	12	InternKon: 942 290 40 / 18
?	510 745 98	Resilient sleeve	24	InternKon: 942 290 40 / 19
?	308 782 99	Bolt	24	InternBDB: M12x70 10.9 DIN00931 \| InternKon: 942 290 40 / 20
?	308 426 99	Bolt	12	InternBDB: M16x80 10.9 DIN00931 \| InternKon: 942 290 40 / 22
?	510 733 98	Resilient sleeve	12	InternKon: 942 290 40 / 21
?	507 596 98	Washer	19	InternBDB: A11 DIN07989 \| InternKon: 942 290 40 / 32
?	334 599 99	Nut	27	InternBDB: M8 DIN00985 \| InternKon: 942 290 40 / 31
?	908 007 40	Plate	2	InternKon: 942 290 40 / 100
?	307 754 99	Bolt	4	InternBDB: M8x25 DIN00933 \| InternKon: 942 290 40 / 53
?	340 507 99	Washer	8	InternBDB: 8,4 DIN00125 \| InternKon: 942 290 40 / 101
?	913 402 40	Fuel coolant	1	InternBDB: Mesabi TL \| InternKon: 942 290 40 / 109
?	930 936 40	Bracket, left	1	InternKon: 942 290 40 / 108
?	930 937 40	Bracket, right	1	InternKon: 942 290 40 / 110
?	308 640 99	Bolt	4	InternBDB: M16x120 8.8 DIN00931 \| InternKon: 942 290 40 / 113
?	332 336 99	Nut	4	InternBDB: M16 8 DIN00934 \| InternKon: 942 290 40 / 115
?	517 192 98	Lock washer	4	InternBDB: 16 W 65593740 \| InternKon: 942 290 40 / 114
?	500 814 98	Bolt	3	InternBDB: M12x60 8.8 DIN00931 \| InternKon: 942 290 40 / 111
?	510 745 98	Spacer	7	InternBDB: 13/25x40 \| InternKon: 942 290 40 / 112
?	308 608 99	Bolt	4	InternBDB: M12x70 8.8 DIN00931 \| InternKon: 942 290 40 / 116
