EXHAUST SYSTEM | PC4000-6 S/N 08195 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	912 486 40	Holding device, muffler	2	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 1
02	936 036 40	Exhaust pipe	1	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 2
03	936 037 40	Exhaust pipe	1	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 3
04	936 034 40	Exhaust pipe	1	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 4
05	936 035 40	Exhaust pipe	1	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 5
06	894 258 40	Strap retainer	4	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 6
07	210 976 40	Muffler	2	InternBDB: 10" MOM19-0001 \| InternKon: 936 040 40 / 7
08	906 476 40	Protecting cap	2	InternBDB: 10" / 254mm / 202-0030 / Stahl \| InternKon: 936 040 40 / 8
09	939 401 40	Turbo charger cover r.h.	1	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 9
10	906 474 40	Broadband clamp	4	InternBDB: 8 \| InternKon: 936 040 40 / 10
11	906 473 40	Flex tube	2	InternBDB: 8 \| InternKon: 936 040 40 / 11
12	502 434 98	Bolt	16	InternBDB: M16x90 / DIN 933 / 10.9 \| InternKon: 936 040 40 / 12
13	510 733 98	Resilient sleeve	16	InternBDB: 17/30x50 / WN 34194840 / 42CRMO4-TQ+T \| InternKon: 936 040 40 / 13
14	332 355 99	Nut	16	InternBDB: M16 / DIN 934 / 10 \| InternKon: 936 040 40 / 14
15	332 336 99	Nut	48	InternBDB: M16 / DIN 934 / 8 \| InternKon: 936 040 40 / 15
16	307 829 99	Bolt	16	InternBDB: M16x65 / DIN 933 / 8.8 \| InternKon: 936 040 40 / 16
17	340 688 99	Washer	8	InternBDB: 17,0 / St / DIN 7349 \| InternKon: 936 040 40 / 17
18	307 804 99	Bolt	10	InternBDB: M 12x30 / DIN 933 / 8.8 \| InternKon: 936 040 40 / 18
19	512 545 98	Washer	10	InternBDB: A13,0 / 140 HV / DIN 125 \| InternKon: 936 040 40 / 19
20	334 600 99	Nut	10	InternBDB: M 12 / DIN 985 / 8 \| InternKon: 936 040 40 / 20
21	894 268 40	Pipe	2	InternBDB: 255x2x110 / St 1203 \| InternKon: 936 040 40 / 21
22	906 507 40	Broadband clamp	2	InternBDB: 10" / 254mm / 268-3610 / Edelstahl \| InternKon: 936 040 40 / 22
23	935 272 40	Cover plate	2	InternKon: 936 040 40 / 23
24	340 465 99	Washer	28	InternBDB: 10,5 / 140HV / DIN 125 \| InternKon: 936 040 40 / 24
25	307 779 99	Bolt	24	InternBDB: M10x30 / DIN 933 / 8.8 \| InternKon: 936 040 40 / 25
26	507 037 98	Nut	28	InternBDB: M10 / DIN 985 / 8 \| InternKon: 936 040 40 / 26
27	940 017 40	Foam profile 1,64m	-2	InternBDB: Silikon 5x40 selbstklebend \| InternKon: 936 040 40 / 27
28	940 017 40	Foam profile 1,64m	-2	InternBDB: Silikon 5x40 selbstklebend \| InternKon: 936 040 40 / 28
29	940 017 40	Foam profile 0,77m	-2	InternBDB: Silikon 5x40 selbstklebend \| InternKon: 936 040 40 / 29
30	940 017 40	Foam profile 1,64m	-2	InternBDB: Silikon 5x40 selbstklebend \| InternKon: 936 040 40 / 30
31	940 017 40	Foam profile 1,64m	-2	InternBDB: Silikon 5x40 selbstklebend \| InternKon: 936 040 40 / 31
32	940 017 40	Foam profile 0,77m	-2	InternBDB: Silikon 5x40 selbstklebend \| InternKon: 936 040 40 / 32
33	945 304 40	Turbo charger cover l.h.	1	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 33
34	945 799 40	heat protection l. h.	2	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 34
35	939 410 40	heat protection, r.h.	2	InternBDB: PC 4000-6 \| InternKon: 936 040 40 / 35
