OPERATOR'S STAND | PC5500-6E S/N 15060 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC5500-6E S/N 15060

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?		Operator's seat	1	InternBDB: 904 600 40 \| InternKon: 942 046 40 / 8	991-0330
?		Operation panel	1		715-1922d
?		Manipulator	2	InternBDB: 921 521 40 \| InternKon: 942 046 40 / 16	991-0514
?		Manipulator	2	InternBDB: 903 401 40 \| InternKon: 943 249 40 / 4	991-0122b
?		Manipulator	3	InternBDB: 903 402 40 \| InternKon: 943 249 40 / 5	991-0121b
?	490 958 40	Socket	7	InternBDB: Gr. + Ha. GHW-NR 14019.562.699 \| InternKon: 942 046 40 / 19
?	490 959 40	Housing	7	InternBDB: Gr. + Ha. GHW-NR 14020.562.699 \| InternKon: 942 046 40 / 20
?	515 129 40	Contact	80	InternBDB: Gr. + Ha. GHW-NR 46851.213.179 \| InternKon: 942 046 40 / 21
?	490 960 40	Tab	80	InternBDB: Gr. + Ha. GHW-NR 26260.331.179 \| InternKon: 942 046 40 / 22
?	634 374 40	Cable	1	InternBDB: FSG 3522S10-90.00A
?	319 227 99	Screw	28	InternBDB: M6x20 /912 10.9
?	635 329 40	Cable 18-pol.	-2	InternKon: 942 046 40 / 10
?	769 587 73	Hose	-2	InternBDB: Matek 114 100 473 BRW Fluidtechnik 077 421 \| InternKon: 001 550 153 / 4
?	793 738 73	Cable flange DN 48-90°	2	InternBDB: PMA BVOD - P 488 GT \| InternKon: 001 550 153 / 5
?	517 957 98	Bolt	8	InternBDB: AM6x25/7985 4.8 \| InternKon: 001 550 153 / 6
?	769 582 73	Control panel	2	InternBDB: Matek 111 002 572 \| InternKon: 001 550 153 / 3
?	318 604 99	Bolt	8	InternBDB: M10x16 /912
?	343 110 99	Lock washer	8	InternBDB: A 10 /127
?	769 588 73	Safety sheeting sw	-2	InternBDB: Matek 111 011 617 Reiff 107 1280 (1445x10000x4)
?	793 735 73	Cover plate	1	InternBDB: Matek 509 004 000
?	320 471 99	Bolt	10	InternBDB: M6x12 /7991
?	769 585 73	Seal	2	InternBDB: Matek 503 000 007
?	318 914 99	Screw	16	InternBDB: M8x16 /912
?	769 586 73	Face	1	InternBDB: Matek-Nr. 503 003 000
?	907 748 40	Fire extinguisher	1	InternBDB: Minimax WS 6 F-C Schaum
?	414 500 40	Bracket	1	InternBDB: 521 695 90
?	307 779 99	Bolt	2	InternBDB: M 10x30 / 933
?	907 104 40	Grommet 20	6	InternBDB: 20/0 +4-13,5 0120 Roxtec \| InternKon: 903 480 40 / 6
?	921 523 40	Face	1	InternKon: 943 249 40 / 14
?	906 761 40	Grommet 30	12	InternBDB: 30/0 +12 -22 0130 Roxtec \| InternKon: 903 480 40 / 2
?	906 760 40	Grommet 40	3	InternBDB: 40/0 +22 -32 0140 Roxtec \| InternKon: 903 480 40 / 3
?	907 223 40	Grommet 15	3	InternBDB: 15 W 40 3x0 +3,5 -10,5 0615 Roxtec \| InternKon: 903 480 40 / 4
?	906 758 40	Seal	1	InternBDB: 0500 Roxtec \| InternKon: 903 480 40 / 1
?	906 762 40	Shim	1	InternBDB: 10/0x12 0310 Roxtec \| InternKon: 903 480 40 / 5
?	907 105 40	Rail	2	InternBDB: 0503 \| InternKon: 903 480 40 / 7
?	793 736 73	Safety lever assy.	1	InternBDB: Matec 509 04 0000
?	793 737 73	Tension spring	1	InternBDB: Matec 509 0400 10 \| InternKon: 509 04 0000 / 10
?	319 140 99	Bolt	4	InternBDB: M8x20/912 \| InternKon: 509 04 0000 / 11
?	340 507 99	Washer	4	InternBDB: 8,4/125 \| InternKon: 509 04 0000 / 12
