Diagram image 1 of 3

PC5500-6 S/N 15056

01 01 01 01 02 02 02 02 03 04 07 08

PC5500-6 S/N 15056

01 01 01 01 02 02 02 02 02 03 03 04 04 06 08 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22

PC5500-6 S/N 15056

02 02 04 04 04 04 04 05 08 08 08 08

#	Part Number	Partname	Quantity	Options
01	655 759 40	Cable protection hose PG 16	-2	InternBDB: HTDL PG 16 330.016.2 \| InternKon: 933 983 40 / 66
02	440 426 40	Cable union PG 16	20	InternBDB: PG 16 7363 Thomas u. Betts \| InternKon: 933 983 40 / 69
03	270 843 40	Cable union PG 29	9	InternBDB: PG 29 7366 Thomas u. Betts \| InternKon: 933 983 40 / 71
04	655 761 40	Cable protection hose PG 29	-2	InternBDB: HTDL PG 29 330.026.2 \| InternKon: 933 983 40 / 68
05	440 386 40	Cable protection hose PG 29-90	2	InternBDB: PG 29 -90 7355 Thomas u. Betts \| InternKon: 933 983 40 / 72
06	255 712 40	Housing empty	1	InternBDB: Bopla A 125
07	654 640 40	Housing empty	1	InternBDB: Bopla A 165
08	653 758 40	Reducing 3/4-PG 16	19	InternKon: 933 983 40 / 73
09	539 282 40	Reducing	6	InternBDB: 1x3/4 \| InternKon: 933 983 40 / 74
10	654 600 40	Cable AWG 16 SW	-2	InternBDB: ELEKTROLITZE AWG 16 SW CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 16
11	654 602 40	Cable AWG 16 GN	-2	InternBDB: ELEKTROLITZE AWG 16 GN CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 17
12	654 601 40	Cable AWG 16 WS	-2	InternBDB: ELEKTROLITZE AWG 16 WS CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 18
13	323 165 40	Cable AWG 12 GN	-2	InternBDB: ELEKTROLITZE AWG 12 GN CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 19
14	323 341 40	Cable AWG 12 WS	-2	InternBDB: ELEKTROLITZE AWG 12 WS CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 21
15	323 164 40	Cable AWG 12 SW	-2	InternBDB: ELEKTROLITZE AWG 12 SW CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 22
16	323 167 40	Cable AWG 14 GN	-2	InternBDB: ELEKTROLITZE AWG 14 GN CSA APPROB \| InternKon: 933 983 40 / 23
17	323 168 40	Cable AWG 14 SW	-2	InternBDB: ELEKTROLITZE AWG 14 SW CSA APPROB \| InternKon: 933 983 40 / 24
18	323 342 40	Cable AWG 14 WS	-2	InternBDB: ELEKTROLITZE AWG 14 WS CSA APPROB \| InternKon: 933 983 40 / 25
19	655 417 40	Cable AWG 16 RT	-2	InternBDB: ELEKTROLITZE AWG 16 RT CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 65
20	907 331 40	Cable AWG 2 WS	-2	InternBDB: ELEKTROLITZE AWG 2 WS CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 60
21	907 332 40	Cable AWG 2 SW	-2	InternBDB: ELEKTROLITZE AWG 2 SW CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 61
22	907 329 40	Cable AWG 2 GN	-2	InternBDB: ELEKTROLITZE AWG 2 GN CSA APPROB TEW/105' 600V \| InternKon: 933 983 40 / 59
