SWITCH FRAMING 1X1 | PC5500-6 S/N 15056 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	932 939 40	Power switch	1	InternBDB: Klц.-Mцl. 100A NZMB1-A100 Best-Nr 259079 \| InternKon: 933 983 40 / 11
02	940 705 40	Breaker 32 A	2	InternBDB: ABB S221-K32
03	940 703 40	Breaker 16 A	1	InternBDB: ABB S221-K16 \| InternKon: 933 983 40 / 54
04	907 828 40	Breaker 6 A	7	InternBDB: ABB S201-K6 \| InternKon: 933 983 40 / 27
05	907 835 40	Breaker 20 A	1	InternBDB: ABB S203-K20 \| InternKon: 933 983 40 / 32
06	907 834 40	Breaker 16 A	2	InternBDB: ABB S203-K16 \| InternKon: 933 983 40 / 26
07	940 738 40	Power breaker	1	InternBDB: ABB 230-240V 50Hz 1SBL281001R1500 \| InternKon: 933 983 40 / 75
08	940 676 40	Servo contactor	2	InternBDB: ABB 1SBLR8810 A16-30-32
09	940 673 40	Clamp	-2	InternBDB: ABB 1SNA206351R1600 BAM2
10	940 678 40	Distribution block	4	InternBDB: ABB 1SNA179657R1500 \| InternKon: 933 983 40 / 76
11	906 745 40	Through clamp 95,0	4	InternBDB: Wago 285-195 \| InternKon: 933 983 40 / 12
12	906 796 40	Protective wire clamp 95,0 GN/GL	1	InternBDB: Wago 285-197
13	940 551 40	Bridging comb 95,0	-2	InternBDB: Wago 285-495
14	906 770 40	Through clamp 10,0	13	InternBDB: Wago 284-901 \| InternKon: 933 983 40 / 39
15	906 793 40	Protective wire clip 10,0	5	InternBDB: Wago 284-907
16	906 774 40	Cover plate	3	InternBDB: Wago 284-325 \| InternKon: 933 983 40 / 40
17	906 777 40	Bridging comb 10,0	-2	InternBDB: Wago 284-402
18	906 768 40	Through clamp 6,0	3	InternBDB: Wago 282-901
19	906 792 40	Protective wire clip 6,0	1	InternBDB: Wago 282-907
20	906 772 40	Cover plate	2	InternBDB: Wago 282-325
21	906 612 40	Through clamp 2.5	30	InternBDB: Wago 870-531 \| InternKon: 933 983 40 / 35
22	906 630 40	Protective wire clip 2.5	12	InternBDB: Wago 870-537 \| InternKon: 933 983 40 / 53
23	906 613 40	Cover plate	5	InternBDB: Wago 870-573 \| InternKon: 933 983 40 / 36
24	906 614 40	Bridging comb 2.5 qmm, 2-fold	-2	InternBDB: Wago 870-402 \| InternKon: 933 983 40 / 41
25	940 709 40	Finger protection	1	InternBDB: ABB 1 SDA054958R0001 F TMAX T4
26	940 710 40	Phase partition wall	1	InternBDB: ABB 1 SDA054972R0001
27	907 951 40	Rail collector 1Ph	-2	InternBDB: ABB PS1/60/16 1Ph 2CDL210001R1660
28	940 638 40	Rail collector 3Ph	-2	InternBDB: ABB PS3/60/16SP 3Ph 2CDL230111R1660
29	792 806 73	Marker Set	1
31	323 232 40	Sectional plate	5	InternBDB: SA 120x500 33331 \| InternKon: 910 738 40 / 1
32	323 759 40	Assembly rail	2	InternBDB: TRAGSCHIENE CP 750 33109 \| InternKon: 910 738 40 / 2
33	323 237 40	Wiring terminal	8	InternBDB: KP 300 33004 \| InternKon: 910 738 40 / 3
34	323 233 40	Wiring profile	-2	InternBDB: LV78 33002 \| InternKon: 910 738 40 / 4
35	270 288 40	Wiring channel	-2	InternBDB: BA 640025 \| InternKon: 910 738 40 / 5
36	655 517 40	Cover 40 BN	-2	InternBDB: 300062 \| InternKon: 910 738 40 / 6
37	317 319 40	Olive	8	InternKon: 910 738 40 / 7
38	307 757 99	Bolt	8	InternBDB: M8x35 /933 \| InternKon: 910 738 40 / 8
39	340 464 99	Washer	8	InternBDB: B 6,4/ 125 \| InternKon: 910 738 40 / 9
40	346 510 99	Lock washer	8	InternBDB: A 8/ 128 \| InternKon: 910 738 40 / 10
41	500 106 98	Bolt	24	InternBDB: M8x16 /933
42	334 599 99	Nut	24	InternBDB: M 8 /985
