PC5500-6 S/N 15056

Komatsu parts book diagram for PC5500-6 S/N 15056: POWER FRAME - GRATINGS

? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	873 038 40	Grid 480x1500	2	InternKon: 914 536 40 / 7
	?	873 039 40	Grid 480x1320	2	InternKon: 914 536 40 / 8
	?	914 535 40	Cover	4	InternKon: 914 536 40 / 1
	?	942 215 40	Hinge	4	InternKon: 914 536 40 / 2
	?	472 509 99	Chain	-2	InternKon: 914 535 40 / 6
	?	341 271 99	Trigger snap	4	InternBDB: C 70/5299 \| InternKon: 914 535 40 / 7
	?	307 339 99	Bolt	8	InternBDB: M12x16 \| InternKon: 914 536 40 / 15
	?	320 431 99	Bolt	16	InternBDB: M 8x25 / 7991 \| InternKon: 914 536 40 / 16
	?	334 599 99	Nut	16	InternBDB: M8 \| InternKon: 914 536 40 / 17
	?	502 354 98	Bolt	30	InternBDB: M8x40 \| InternKon: 914 536 40 / 14
	?	317 318 40	Wing nut, plastic	30	InternKon: 914 536 40 / 13
	?	317 319 40	Threaded block	30	InternKon: 914 536 40 / 12
	?	882 769 40	Handle	4	InternKon: 914 535 40 / 4
	?	334 599 40	Nut	8	InternBDB: M8x40 \| InternKon: 914 535 40 / 5

Komatsu PC5500-6 S/N 15056 parts catalog PDF

POWER FRAME - GRATINGS (515-1058c) in PC5500-6 S/N 15056. Diagram image and parts list.
