#	Part Number	Partname	Quantity	Options
\|$$1		Graphic 1	-1
01	323 078 40	Grating 180x330	2	InternBDB: Grдpel 40x2 \| InternKon: 371 590 40 / 69
02	390 429 40	Platform	1	InternKon: 371 590 40 / 16
03	323 315 40	Grating 480x720	3	InternKon: 371 590 40 / 46
04	324 416 40	Grating 120x720	1	InternKon: 371 590 40 / 47
05	334 036 40	Rail	1	InternKon: 371 590 40 / 24
06	324 543 40	Grating 420x1920	1	InternKon: 371 590 40 / 56
07	324 540 40	Grating 300x1500	2	InternKon: 371 590 40 / 55
08	324 539 40	Grating 240x900	1	InternKon: 371 590 40 / 54
09	502 354 98	Bolt	40	InternBDB: M8x40 /963 \| InternKon: 371 590 40 / 60
10	317 318 40	Wing nut	40	InternBDB: Grдpel 366.001 \| InternKon: 371 590 40 / 59
11	317 319 40	Threaded block	-2	InternKon: 371 590 40 / 58
12	399 899 40	Ladder	1	InternKon: 371 590 40 / 29
13	399 896 40	Ladder	1	InternKon: 371 590 40 / 30
14	346 498 99	Lock washer	10	InternBDB: 12 /128 \| InternKon: 371 590 40 / 68
15	307 802 99	Bolt	10	InternBDB: M12x25 /933
16	414 371 40	Grating 420x900	2	InternKon: 371 590 40 / 81
17	426 750 40	Grating 420x900	1	InternKon: 371 590 40 / 82
18	426 751 40	Grating 420x900	1	InternKon: 371 590 40 / 83
19	426 752 40	Grating 480x510	1	InternKon: 371 590 40 / 84
20	414 516 40	Clip	-2	InternBDB: Grдpel 3000575001 \| InternKon: 371 590 40 / 80
21	403 275 40	Clip	-2	InternBDB: 3003234001 \| InternKon: 371 590 40 / 58
22	389 830 40	Platform	2	InternKon: 371 590 40 / 11
\|$$24		Graphic 2	-1
23	324 538 40	Grating	2	InternBDB: Grдpel 40x2 \| InternKon: 371 590 40 / 53
24	334 038 40	Rail	1	InternKon: 371 590 40 / 23
25	399 880 40	Rail	1	InternKon: 371 590 40 / 14
26	399 881 40	Rail	1	InternKon: 371 590 40 / 13
27	334 035 40	Rail	1	InternKon: 371 590 40 / 25
30	317 312 40	Grating 300x660	2	InternKon: 371 590 40 / 49
31	323 455 40	Grating 180x660	1	InternKon: 371 590 40 / 50
32	334 032 40	Platform	1	InternKon: 371 590 40 / 18
33	317 311 40	Grating 300x510	3	InternKon: 371 590 40 / 57
34	261 840 40	Pin	4	InternKon: 371 590 40 / 32
35	399 883 40	Angle	1	InternKon: 371 590 40 / 35
36	399 885 40	Rubber-metal block	1	InternKon: 371 590 40 / 64
37	307 774 99	Bolt	4	InternBDB: M10x18 /933 \| InternKon: 371 590 40 / 65
38	343 095 99	Lock washer	4	InternBDB: 10 /128 \| InternKon: 371 590 40 / 66
39	502 354 98	Bolt	40	InternBDB: M8x40 /963 \| InternKon: 371 590 40 / 60
40	317 318 40	Wing nut	40	InternBDB: Grдpel 366.001 \| InternKon: 371 590 40 / 59
41	317 319 40	Threaded block	-2	InternKon: 371 590 40 / 58
42	414 516 40	Clip	-2	InternBDB: Grдpel 3000575001 \| InternKon: 371 590 40 / 80
43	403 275 40	Clip	-2	InternBDB: 3003234001 \| InternKon: 371 590 40 / 58
44	324 542 40	Grating 420x1290	1	InternKon: 371 590 40 / 51
45	270 189 40	Grating 420x1650	1	InternKon: 371 590 40 / 52
47	343 112 99	Lock washer	8	InternBDB: 12 /128
48	307 802 99	Bolt	8	InternBDB: M12x25 /933
