ROTARY JOINT | H455S S/N 15005 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	659 009 40	Rotary joint, assy.	1	InternBDB: DBM AT-Nr. 710 596 73
02	319 299 99	Screw	4	InternBDB: M16x70 /912 10.9 \| InternKon: 659 009 40 / 23
03	365 404 40	Cover	1	InternKon: 659 009 40 / 4
04	360 924 40	Sealing element	10	InternBDB: Bu. u. Luy. GS-50993- 3202-10N \| InternKon: 659 009 40 / 12
05	360 931 40	O-ring	10	InternBDB: Bu. u. Luy. 278,8x7 451-MS-28775 \| InternKon: 659 009 40 / 13
06	304 352 99	Bolt	8	InternBDB: M16x140 /931 10.9 \| InternKon: 659 009 40 / 21
07	316 211 99	Washer	8	InternBDB: 17 /6916 \| InternKon: 659 009 40 / 25
08	368 724 40	Driving ring	1	InternKon: 659 009 40 / 3
09	004 860 98	Grease nipple	2	InternBDB: AR 1/4 011 207 99 \| InternKon: 659 009 40 / 27
10	365 405 40	Race	1	InternKon: 659 009 40 / 5
11	502 860 98	O-ring	1	InternBDB: 190x10 /70 3770 \| InternKon: 659 009 40 / 16
12	659 007 40	Rotor	1	InternKon: 659 009 40 / 2
13	360 873 40	Plug	2	InternBDB: Ermeto vsti M26x1,5 -ed \| InternKon: 659 009 40 / 19
14	504 375 98	O-ring	4	InternBDB: 47,5x4 /80 3770 \| InternKon: 659 009 40 / 17
15	360 932 40	Support ring	4	InternBDB: Prдdifa 1,5x48,2x55 \| InternKon: 659 009 40 / 18
16	507 718 40	Plug	4	InternKon: 659 009 40 / 9
17	365 411 40	Plug	4	InternKon: 659 009 40 / 10
18	360 923 40	Piston guide ring	4	InternBDB: Bu. u. Luy. BB-50705- 3000A-TLG-R \| InternKon: 659 009 40 / 14
19	504 376 98	O-ring	1	InternBDB: 335x10 /70 3770 \| InternKon: 659 009 40 / 15
20	659 006 40	Housing	1	InternKon: 659 009 40 / 1
21	365 408 40	Half disk	2	InternKon: 659 009 40 / 8
22	365 407 40	Centering disk	1	InternKon: 659 009 40 / 7
23	343 004 99	Washer	8	InternBDB: 8,4 /93 \| InternKon: 659 009 40 / 26
24	307 754 99	Bolt	8	InternBDB: M8x25 /933 \| InternKon: 659 009 40 / 24
25	365 406 40	Support flange	1	InternKon: 659 009 40 / 6
26	510 729 98	Sleeve	8	InternKon: 659 009 40 / 11
27	308 321 99	Bolt	8	InternBDB: M16x90 /931 10.9 \| InternKon: 659 009 40 / 22
28	173 493 40	Plug	2	InternBDB: Vsti M18x1,5 ed \| InternKon: 659 009 40 / 20
\|$$29	780 899 73	Seal kit fig-nos. 04,05,11,14,15,18+19	-2	InternBDB: E-ST
