00 |
566 530 40
|
Valve block assy. |
1 |
InternKon: 489 250 40 / 01
|
|
|
|
01 |
566 516 40
|
Valve block |
1 |
InternKon: 566 530 40 / 1
|
|
|
|
02 |
761 591 73
|
Pressure sequence stag |
1 |
InternBDB: Rexroth M 07010 - 583 485 | InternKon: 566 530 40 / 2
|
|
|
|
03 |
448 991 40
|
Valve block |
1 |
InternKon: 566 530 40 / 3
|
|
|
|
05 |
371 394 99
|
Non-return valve |
2 |
InternBDB: RHV 20-PSM-ed 010 873 99 | InternKon: 566 530 40 / 5
|
|
|
|
06 |
504 420 98
|
Non-return valve |
2 |
InternBDB: RHZ 20-PSM-ed 010 874 99 | InternKon: 566 530 40 / 6
|
|
|
|
07 |
371 977 99
|
Union |
4 |
InternBDB: FFS 20 /2353 | InternKon: 566 530 40 / 7
|
|
|
|
08 |
372 185 99
|
Union |
3 |
InternBDB: DDS 20 /2353 | InternKon: 566 530 40 / 8
|
|
|
|
09 |
372 462 99
|
Union |
2 |
InternBDB: DS 20 /2353 | InternKon: 566 530 40 / 9
|
|
|
|
10 |
372 173 99
|
Union |
1 |
InternBDB: DDL 15 /2353 | InternKon: 566 530 40 / 10
|
|
|
|
11 |
370 506 99
|
Union |
1 |
InternBDB: CS 20 /2353 | InternKon: 566 530 40 / 11
|
|
|
|
12 |
502 135 98
|
Bolt |
4 |
InternBDB: M8x95 /931 | InternKon: 566 530 40 / 12
|
|
|
|
13 |
371 783 99
|
Socket |
1 |
InternBDB: EVGE 15-LM- ed | InternKon: 566 530 40 / 13
|
|
|
|
14 |
488 026 40
|
Pipe assy. Ш 20 |
1 |
InternKon: 566 530 40 / 14
|
|
|
|
15 |
457 299 40
|
Pipe assy. Ш 20 |
1 |
InternKon: 566 530 40 / 15
|
|
|
|
16 |
488 027 40
|
Pipe assy. Ш 20 |
1 |
InternKon: 566 530 40 / 16
|
|
|
|
17 |
462 812 40
|
Pipe assy. Ш 20 |
1 |
InternKon: 566 530 40 / 17
|
|
|
|
18 |
371 260 99
|
Union nut |
1 |
InternBDB: AS 20 /3870 | InternKon: 566 530 40 / 18
|
|
|
|
19 |
371 233 99
|
Olive |
1 |
InternBDB: S 20 /3861 | InternKon: 566 530 40 / 19
|
|
|
|
20 |
461 133 40
|
Ball cock |
1 |
InternBDB: Argus BK 3021-0016- 5942-50 | InternKon: 566 530 40 / 20
|
|
|
|
21 |
215 539 99
|
Pipe Ш 20
Bulk ware, state length
required |
1 |
InternBDB: 20x3 /2391 | InternKon: 566 530 40 / 21
|
|
|
|
23 |
373 754 99
|
Union |
1 |
InternBDB: TR 15/10/15-L 010 877 99 | InternKon: 566 530 40 / 23
|
|
|
|
24 |
623 450 40
|
Hose assy. DN 8 x 590 |
1 |
InternBDB: DOL 10 / DOL 10 | InternKon: 566 530 40 / 24
|
|
|
|
27 |
372 426 99
|
Union |
1 |
InternBDB: CL 15 /2353 | InternKon: 566 530 40 / 27
|
|
|
|
28 |
640 488 40
|
Pipe assy. Ш 15 |
1 |
InternKon: 566 530 40 / 28
|
|
|
|
29 |
087 232 40
|
Ball cock |
1 |
InternBDB: Argus 3021-0013-5941-80 | InternKon: 566 530 40 / 30
|
|
|
|
30 |
371 242 99
|
Olive |
1 |
InternBDB: l 15 | InternKon: 566 530 40 / 29
|
|
|
|
31 |
371 275 99
|
Union nut |
1 |
InternBDB: AL 15 | InternKon: 566 530 40 / 22
|
|
|
|
32 |
006 894 98
|
Union |
1 |
InternBDB: 10 LR | InternKon: 566 530 40 / 43
|
|
|
|
|$$30 |
215 811 99
|
Pipe Ш 15
Bulk ware, state length
required |
-2 |
InternBDB: 15x1,5 /2391
|
|
