01 |
654 478 40
|
Hydr. motor assy. |
1 |
InternBDB: Brueninghaus A2FLM 355 / 60 W-VZH 01 927 427
|
|
|
|
02 |
319 320 99
|
Bolt |
8 |
InternBDB: M18x50 /912 10.9 | InternKon: 927 427 / 10
|
|
|
|
03 |
757 290 73
|
Connector plate |
1 |
InternBDB: 913 797 | InternKon: 927 427 / 05
|
|
|
|
04 |
345 632 99
|
Pin |
2 |
InternBDB: 10 M6x32 /6325 | InternKon: 927 427 / 11
|
|
|
|
05 |
505 933 98
|
O-ring |
1 |
InternBDB: 172x4 Viton 80 | InternKon: 927 427 / 08
|
|
|
|
06 |
|
Housing |
1 |
InternBDB: 913 233 | InternKon: 927 427 / 04
|
|
|
|
07 |
767 039 73
|
Plug |
1 |
InternBDB: 532 347 HN8-WD M14x1,5 V WN 1040 | InternKon: 927 427 / 13
|
|
|
|
08 |
767 040 73
|
Plug |
1 |
InternBDB: 636 797 HN8-WD M33x2 V WN 1040 | InternKon: 927 427 / 12
|
|
|
|
09 |
767 032 73
|
Transmission
consist. of fig-nos: 10-35 |
1 |
InternBDB: 927 428 | InternKon: 927 427 / 01
|
|
|
|
10 |
345 630 99
|
Pin |
1 |
InternBDB: 10 M6x24 /6325 | InternKon: 927 428 / 32
|
|
|
|
11 |
757 292 73
|
Centering pin |
1 |
InternBDB: 921 157 | InternKon: 927 428 / 12
|
|
|
|
12 |
757 293 73
|
Control plate |
1 |
InternBDB: 921 114 | InternKon: 927 428 / 07
|
|
|
|
13 |
757 294 73
|
Spacer screw |
1 |
InternBDB: 933 066 | InternKon: 927 428 / 17
|
|
|
|
14 |
762 750 73
|
Adjusting ring |
1 |
InternBDB: 936 002 | InternKon: 927 428 / 13
|
|
|
|
15 |
757 296 73
|
Cylinder |
1 |
InternBDB: 920 134 | InternKon: 927 428 / 06
|
|
|
|
16 |
757 297 73
|
Disc |
1 |
InternBDB: 933 031 | InternKon: 927 428 / 15
|
|
|
|
17 |
757 298 73
|
Spring |
1 |
InternBDB: 933 287 | InternKon: 927 428 / 14
|
|
|
|
18 |
757 299 73
|
Pivot |
1 |
InternBDB: 921 122 | InternKon: 927 428 / 08
|
|
|
|
19 |
757 300 73
|
Piston with rings |
7 |
InternBDB: 921 084 +2x 921 092 | InternKon: 927 428 / 03
|
|
|
|
20 |
319 241 99
|
Screw |
14 |
InternBDB: M8x20 /912 10.9 | InternKon: 927 428 / 39
|
|
|
|
21 |
756 371 73
|
Withdrawal plate |
1 |
InternBDB: 903 490 | InternKon: 927 428 / 09
|
|
|
|
22 |
767 033 73
|
Driving flange |
1 |
InternBDB: 914 828 | InternKon: 927 428 / 01
|
|
|
|
23 |
767 034 73
|
Guide shoe |
7 |
InternBDB: 742 465 | InternKon: 927 428 / 18
|
|
|
|
24 |
767 035 73
|
Roller bearing |
1 |
InternBDB: 914 859 | InternKon: 927 428 / 21
|
|
|
|
25 |
767 036 73
|
Adjusting disk |
1 |
InternBDB: 914 858 | InternKon: 927 428 / 16
|
|
|
|
26 |
767 037 73
|
Roller bearing |
1 |
InternBDB: NJ 2214 M / 5412 914 860 | InternKon: 927 428 / 22
|
|
|
|
27 |
341 377 99
|
Shim ring |
1 |
InternBDB: 70 x 90 x 1 | InternKon: 927 428 / 34
|
|
|
|
28 |
342 560 99
|
Circlip |
1 |
InternBDB: 70 x 2,5 / 471 | InternKon: 927 428 / 30
|
|
|
|
29 |
767 038 73
|
Race |
1 |
InternBDB: 937 898 | InternKon: 927 428 / 10
|
|
|
|
30 |
514 025 98
|
O-ring |
1 |
InternBDB: 205x5 Viton 80 | InternKon: 927 428 / 25
|
|
|
|
31 |
998 898
|
Circlip |
1 |
InternBDB: 513 202 | InternKon: 927 428 / 28
|
|
|
|
32 |
514 045 98
|
O-ring |
1 |
InternBDB: 140x2,5 80 Sh Viton | InternKon: 927 428 / 26
|
|
|
|
33 |
504 216 98
|
Shaft seal |
1 |
InternBDB: 70x90x7 BABSL 1,0 619 728 | InternKon: 927 428 / 24
|
|
|
|
34 |
757 306 73
|
Sealing flange |
1 |
InternBDB: 921 149 | InternKon: 927 428 / 11
|
|
|
|
35 |
342 679 99
|
Circlip |
1 |
InternBDB: 145x4 /472 | InternKon: 927 428 / 29
|
|
|
|
36 |
763 884 73
|
Spring |
7 |
InternBDB: 717 207 | InternKon: 927 428 / 31
|
|
