01 |
|
Air cleaner |
1 |
InternBDB: 226 921 40 | InternKon: 409 990 40 / 48
|
090-5546 |
|
|
02 |
007 617 98
|
Clamp |
10 |
InternBDB: 1S 164x25 | InternKon: 424 900 40 / 47
|
|
|
|
03 |
414 400 40
|
Elbow |
5 |
InternBDB: Cat 9 N 720 | InternKon: 424 900 40 / 28
|
|
|
|
04 |
424 936 40
|
Pipe |
1 |
InternKon: 424 900 40 / 8
|
|
|
|
05 |
424 958 40
|
Pipe |
1 |
InternKon: 424 900 40 / 24
|
|
|
|
06 |
424 954 40
|
Air intake pipe |
1 |
InternKon: 424 900 40 / 5
|
|
|
|
07 |
424 951 40
|
Intermediate pipe |
1 |
InternKon: 424 900 40 / 22
|
|
|
|
08 |
424 962 40
|
Absorbing wall |
1 |
InternKon: 424 900 40 / 23
|
|
|
|
09 |
269 336 40
|
Disk |
1 |
InternBDB: Ma. u. Hu. 230 053 1171 | InternKon: 424 900 40 / 50
|
|
|
|
10 |
145 895 40
|
Switch |
1 |
InternBDB: 390 069 901 | InternKon: 424 900 40 / 49
|
|
|
|
11 |
307 344 99
|
Bolt |
3 |
InternBDB: M12x30 /933 | InternKon: 424 900 40 / 52
|
|
|
|
12 |
308 614 99
|
Bolt |
2 |
InternBDB: M12x120 /931 | InternKon: 424 900 40 / 5
|
|
|
|
13 |
332 334 99
|
Nut |
10 |
InternBDB: M12 /934 | InternKon: 424 900 40 / 55
|
|
|
|
14 |
427 265 99
|
Base 100x8x500 |
1 |
InternKon: 424 900 40 / 59
|
|
