01 |
405 862 40
|
Cylinder assy. |
1 |
InternBDB: E-ST AT-Nr. 669 402 73
|
|
|
|
02 |
405 863 40
|
Barrel |
1 |
InternKon: 405 862 40 / 1
|
|
|
|
03 |
405 864 40
|
Piston |
1 |
InternKon: 405 862 40 / 2
|
|
|
|
04 |
405 865 40
|
Bottom |
1 |
InternKon: 405 862 40 / 3
|
|
|
|
05 |
405 866 40
|
Disk |
1 |
InternKon: 405 862 40 / 4
|
|
|
|
06 |
405 867 40
|
Spring |
1 |
InternBDB: 1,6x10x36 | InternKon: 405 862 40 / 5
|
|
|
|
07 |
405 868 40
|
Spring |
1 |
InternBDB: 2x20x225 | InternKon: 405 862 40 / 6
|
|
|
|
08 |
502 968 98
|
O-ring |
1 |
InternBDB: 18x3/NB80 | InternKon: 405 862 40 / 7
|
|
|
|
09 |
324 235 40
|
Backring |
2 |
InternBDB: Techno Parts SP01182344 | InternKon: 405 862 40 / 8
|
|
|
|
10 |
323 902 40
|
Stripper |
1 |
InternBDB: Praedifa 18x26x7/ A1N90 1035 | InternKon: 405 862 40 / 9
|
|
|
|
11 |
300 257 99
|
Angle joint |
1 |
InternBDB: AS10/71802 | InternKon: 405 862 40 / 10
|
|
|
|
12 |
319 315 99
|
Screw |
1 |
InternBDB: M6x60/912 | InternKon: 405 862 40 / 11
|
|
|
|
13 |
325 221 99
|
Thread pin |
1 |
InternBDB: M12x16/914 | InternKon: 405 862 40 / 12
|
|
|
|
14 |
307 810 99
|
Bolt |
1 |
InternBDB: M12x60/933 | InternKon: 405 862 40 / 13
|
|
|
|
15 |
332 110 99
|
Nut |
1 |
InternBDB: M6/934 | InternKon: 405 862 40 / 14
|
|
|
|
16 |
332 334 99
|
Nut |
1 |
InternBDB: M12/934 | InternKon: 405 862 40 / 15
|
|
|
|
17 |
500 383 98
|
O-ring |
1 |
InternBDB: 31,42x2,62B/ NB 90 | InternKon: 405 862 40 / 16
|
|
|
|
18 |
340 463 99
|
Washer |
1 |
InternBDB: 6,4/125 | InternKon: 405 862 40 / 17
|
|
|
|
19 |
328 262 99
|
Stud |
1 |
InternBDB: M10x25/938 | InternKon: 405 862 40 / 18
|
|
|
|
20 |
332 113 99
|
Nut |
1 |
InternBDB: M10/934 | InternKon: 405 862 40 / 19
|
|
|
|
21 |
300 258 99
|
Angle joint |
1 |
InternBDB: GE-AS16/71802 | InternKon: 405 862 40 / 20
|
|
|
|
|$$22 |
695 889 73
|
Seal kit
consist. of fig-nos: 08-10,17 |
1 |
|
|
|
|
30 |
372 171 99
|
Union |
2 |
InternBDB: DDL 10/2353 | InternKon: 420 170 40 / 69
|
|
|
|
31 |
226 355 40
|
Nozzle |
1 |
InternBDB: 1 mm | InternKon: 420 170 40 / 24
|
|
|
|
32 |
687 254
|
Union |
1 |
InternBDB: E-ST | InternKon: 420 170 40 / 25
|
|
|
|
33 |
374 416 99
|
Socket |
1 |
InternBDB: L 10 G 1/4
|
|
|
|
34 |
211 242 99
|
Plastic pipe Ш 10
Bulk ware, state length
required |
-2 |
InternBDB: /16982 | InternKon: 420 170 40 / 102
|
|
|
|
35 |
159 966 40
|
Clamping ring |
2 |
InternKon: 420 170 40 / 99
|
|
|
|
36 |
007 577 98
|
Sleeve |
2 |
InternKon: 420 170 40 / 100
|
|
|
|
37 |
533 986 99
|
Plate |
1 |
InternBDB: E 1 a
|
|
|
|
38 |
533 984 99
|
Half clamp |
2 |
InternBDB: C 1 a / 10
|
|
|
|
39 |
320 214 99
|
Screw |
2 |
InternBDB: M6x20/912
|
|
|
|
40 |
340 405 99
|
Washer |
2 |
InternBDB: 6,4/433
|
|
