OIL TANK ASSY. | H65 26051 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

H65 26051

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?	405 780 40	Oil tank w/o mounting parts	1	InternKon: / 1
?	405 812 40	Cover	1	InternKon: / 2
?	405 815 40	Cover assy.	1	InternKon: / 3
?	428 114 40	Cover assy.	1	InternKon: / 4
?	405 830 40	Suction pipe	1	InternKon: / 5
?	241 225 40	Filter pipe	1	InternKon: / 6
?	336 654 40	Filter cover	1	InternKon: / 7
?	355 097 40	Filter cover	1	InternKon: / 8
?	405 819 40	Clamp strap	1	InternKon: / 9
?	405 820 40	Valve block	1	InternKon: / 10
?	405 821 40	Valve cover	1	InternKon: / 11
?	186 667 40	Cover seal	1	InternBDB: Perbunan N50-60 \| InternKon: / 13
?	366 505 40	Bush	1	InternKon: / 15
?	211 242 99	Plastic pipe Ш 10 300 lg. Bulk ware, state length required	1	InternBDB: 10x1,85 /16982 \| InternKon: / 17
?	145 162 40	Seal washer	2	InternBDB: Klingerit \| InternKon: / 18
?	366 504 40	Compression spring	1	InternBDB: 10x50X107/2098 \| InternKon: / 20
?	255 794 40	Filler w/o cap	1	InternBDB: Eppensteiner EF 6 \| InternKon: / 21
?		Return oil filter	1	InternBDB: 358 601 40 \| InternKon: / 22	090-5569a
?		Return oil filter	1	InternBDB: 414 024 40 \| InternKon: / 23	090-5575
?	255 774 40	Filter assy.	1	InternBDB: Pall Typ HC 9500 S-UJ4-H \| InternKon: / 24
?		Pressure relief valve	1	InternBDB: 324 832 40 \| InternKon: / 25	090-0406
?	324 825 40	Annular flap	1	InternBDB: PN10 CAVO Typ M 600 1 DN 200 \| InternKon: / 26
?	192 165 40	Pressure switch	1	InternBDB: Westinghouse 441 014 0210 \| InternKon: / 62
?	269 870 40	Cover tube	1	InternBDB: Noris MX 2 \| InternKon: / 28
?	323 249 40	Test insert	1	InternBDB: TH 31 40 ?-120 ? C \| InternKon: / 29
?	440 606 40	Oil level transmitter (see service bulletin 21-273)	1	InternBDB: Robertshaw 624-NHG-000-C (C-M0S) \| InternKon: / 30
?	269 281 40	Temperature transmitter	1	InternBDB: VDO 100-120 ? C 323.801/001/ 018 \| InternKon: / 31
?	255 721 40	Maintenance switch	1	InternBDB: Ma.u.Hu. 390 006 2903 \| InternKon: / 32
?	269 336 40	Felt disk	1	InternBDB: 230 053 1171 \| InternKon: / 33
?	006 806 98	O-ring	1	InternBDB: 275x5,0B NB70 \| InternKon: / 34
?	000 219 98	O-ring	1	InternBDB: 170x5 B NB80 \| InternKon: / 35
?	006 709 98	O-ring	1	InternBDB: 125x6,0B NB80 \| InternKon: / 36
?	137 179 40	O-ring	3	InternBDB: 74x3 B NB90 \| InternKon: / 37
?	405 822 40	Wall	1	InternKon: / 12
?	006 857 98	Spring	1	InternBDB: 3,5x25x8x61 \| InternKon: / 39
?	305 992 99	Cock	1	InternBDB: 3/4 /3529 \| InternKon: / 40
?	370 819 99	Cap	1	InternBDB: 3/4 /2991 \| InternKon: / 41
?	370 757 99	Twin nipple	2	InternBDB: 3/4 /2990 \| InternKon: / 42
?	202 967 40	Plug	1	InternBDB: VSTI G3/4 ED \| InternKon: / 43
?	304 309 99	Bolt	1	InternBDB: M30x200 /931 10.9 \| InternKon: / 44
?	307 804 99	Bolt	4	InternBDB: M12x30 /931 \| InternKon: / 46
?	500 106 98	Bolt	8	InternBDB: M8x16-SK/933 \| InternKon: / 65
?	308 587 99	Bolt	1	InternBDB: M10x120 /931 \| InternKon: / 47
?	308 560 99	Bolt	1	InternBDB: M8x70 /931 \| InternKon: / 48
?	082 184 40	Wire 1,2mm	-2	InternBDB: D9-1 G \| InternKon: / 66
?	307 750 99	Bolt	30	InternBDB: M8x15 /933 \| InternKon: / 50
?	319 292 99	Bolt	4	InternBDB: M16x90 /912 10.9 \| InternKon: / 51
?	319 164 99	Bolt	2	InternBDB: M12x130 /912 \| InternKon: / 52
?	319 425 99	Screw	4	InternBDB: M8x60 /912 \| InternKon: / 53
?	328 169 99	Bolt	8	InternBDB: M16x110 /938 \| InternKon: / 54
?	332 336 99	Nut	16	InternBDB: M 16 /934 \| InternKon: / 55
?	343 857 99	Lock washer	4	InternBDB: 16 /7980 \| InternKon: / 56
?	343 856 99	Lock washer	2	InternBDB: 12 /7980 \| InternKon: / 57
?	346 510 99	Lock washer	26	InternBDB: 8 /128 \| InternKon: / 58
?	371 858 99	Breech block	1	InternBDB: Buz 28-L \| InternKon: / 64
?	307 824 99	Bolt	11	InternBDB: M16x40 /933
?	084 020 40	Pressure switch	1	InternBDB: Westinghouse 414 014 0050 \| InternKon: / 27
