SLIP RING | PC 7000-6E 35 003 11.06.2019 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
01	986 208 40	Slip ring assy.	1
02		Frame assy.	1
03		Ring body assy.	1	991-1125
04	798 037 73	Current supply unit	1
05		Hood assy. with inspection glass	1
06		Hood assy. with line entrance	1
07		Hood	1
08		lower plate, weld on part	1
09	764 607 73	ball bearing	1
10	307 679 99	bolt	4
11	512 470 98	lock washer	28
12	340 461 99	washer	20
13	512 467 98	nut	10
14	795 926 73	assembly rail	-2
15	307 781 99	bolt	3
16	343 095 99	lock washer	3
17	307 730 99	Bolt	6
18	340 506 99	Washer	10
19	512 465 98	Nut	10
20	343 106 99	Lock washer	1
21	307 732 99	Bolt	1
22		Regulated radiator	1
23	951 359 40	Light	1
24		Window	1
25		Cover	1
26		Line entrance assy.	1
27		Heater with regulator	1
28	307 693 99	Bolt	2
29	350 560 99	Grease nipple	4
30		Angle / point of lubrication	1
31	798 889 73	Union	4
32	307 805 99	Bolt	8
33	318 991 99	Screw	8
34		Lock washer	12
35	506 890 98	Wascher	64
36	512 557 98	Nut	80
37	332 078 99	Nut	4
38		Switch retainer	1
39		parallel pin	2
40	377 750 99	Bolt	4
41		Lock washer	8
42	764 584 73	Switch	2
43	319 561 99	Screw	4
44	796 098 73	cable clamp	2
45	318 367 99	countersunk screw	8
46	505 955 99	assembly rail	-2
47	940 673 40	clamp	6
48	765 569 73	hose (polyethylen)	-2
49	377 752 99	Bolt	4
50		Cable retainer	1
51	795 927 73	switch retainer	1
52	270 873 40	cable channel	-2
53	307 691 99	bolt	12
54	332 079 99	nut	22
55		clamp box	1
56	950 153 40	disconnect terminal 16 mmІ	1
57	950 149 40	Through clamp 16 mmІ	2
58	906 612 40	through clamp 2,5 mmІ	32
59	906 613 40	disconnect terminal 2,5 mm	3
60	950 152 40	disconnect terminal 4 mmІ	2
61	941 291 40	Protective wire clip 4 mmІ	3
62	950 154 40	cross connection link	3
63	950 147 40	Through clamp 4 mmІ	12
64		Bolt	16
65	512 467 98	Nut	32
66		laminated paper	2
67		plug	4
68	318 118 99	Bolt	10
69	332 336 99	Nut	6
70	313 503 99	Eyebolt	2
71		cable gland	1
72		current collector bold	2
73	512 467 98	nut	2
74	307 824 99	Bolt	4
75	340 469 99	Washer	4
76	512 466 98	nut	4
77		grounding cable	1
78	343 112 99	lock washer	1
79	340 591 99	washer	1
80	307 804 99	Bolt	1
81		laminated paper	3
82		washer	12
83	307 753 99	bolt	12
84	307 756 99	bolt	4
100		Carrier	1
101		Carrier	1
102	798 039 73	HST - 250, 10 KV	6
103		Connection rail	4
104	798 040 73	HST - 250, 10 KV (PE)	2
105		Grounding bolt	2
106	307 827 99	Bolt	6
107	343 817 99	Lock washer	8
108	307 824 99	Bolt	2
109	307 779 99	Bolt	8
110	343 095 99	Lock washer	8
111	798 114 73	20 KV Inside isolator, 75x175	6
112	765 623 73	Trestle	8
113	798 041 73	Copper graphit brush 100A	16
114	798 042 73	Draw spring	16
115	765 635 73	Lever	16
116	794 313 73	Bolt	32
117	334 608 99	Nut	32
118	307 730 99	Bolt	6
119	343 106 99	Lock washer	6
120	307 754 99	Bolt	8
121	343 108 99	Lock washer	8
122	340 507 99	Washer	8
123		Bushing	6
124	307 805 99	Bolt	4
125	340 467 99	Washer	4
126	504 271 98	Lock washer	4
127	332 334 99	Nut	4
\|$$113			-2
\|$$114			-2
