01 |
|
Idler assy. |
2 |
InternBDB: 429 223 40 | InternKon: 936 608 40 / 2
|
585-3115 |
|
|
02 |
|
Tensioner |
4 |
InternBDB: 934 622 40 TT | InternKon: 936 608 40 / 7
|
485-3118a |
|
|
03 |
488 028 40
|
Plate |
4 |
InternKon: 936 608 40 / 8
|
|
|
|
04 |
308 670 99
|
Bolt |
16 |
InternBDB: M20x100 /931 | InternKon: 936 608 40 / 18
|
|
|
|
05 |
334 686 99
|
Nut |
16 |
InternBDB: M 20 /985 | InternKon: 936 608 40 / 19
|
|
|
|
06 |
|
Track roller |
14 |
InternBDB: 429 235 40 | InternKon: 936 608 40 / 3
|
585-3125a |
|
|
07 |
500 128 98
|
Bolt (standard) |
56 |
InternBDB: M24x220 /931 10.9 | InternKon: 936 608 40 / 12
|
|
|
|
07 |
513 637 98
|
Bolt (cold weather design) |
56 |
InternBDB: 6KTSHR M24X 220 10.9 KALTZ DIN 00931 | InternKon: 936 608 40 / 12
|
|
|
|
08 |
316 213 99
|
Washer |
136 |
InternBDB: 25 /6916 | InternKon: 936 608 40 / 11
|
|
|
|
09 |
514 678 40
|
Nut (standard) |
56 |
InternKon: 936 608 40 / 13
|
|
|
|
09 |
936 611 40
|
Nut (cold weather design) |
56 |
InternBDB: NASENMUTTER M24TT PC 3000- 6 | InternKon: 936 608 40 / 13
|
|
|
|
10 |
308 886 99
|
Bolt (standard) |
24 |
InternBDB: M24x120/931 10.9 | InternKon: 936 608 40 / 10
|
|
|
|
10 |
501 111 98
|
Bolt (cold weather design) |
24 |
InternBDB: 6KTSHR M24X 120 10.9 KALTZ DIN 00931 | InternKon: 936 608 40 / 10
|
|
|
|
11 |
457 126 40
|
Cover |
2 |
InternKon: 936 608 40 / 21
|
|
|
|
12 |
480 096 40
|
Cover |
2 |
InternKon: 936 608 40 / 24
|
|
|
|
13 |
307 819 99
|
Bolt |
8 |
InternBDB: M16 x 20 / 933 | InternKon: 936 608 40 / 22
|
|
|
|
14 |
517 123 98
|
Lock washer |
8 |
InternBDB: 16 WN 65593840 | InternKon: 936 608 40 / 23
|
|
|
|
15 |
307 800 99
|
Bolt |
8 |
InternBDB: M12 x 20 / 933 | InternKon: 936 608 40 / 25
|
|
|
|
16 |
51 118 98
|
Lock washer |
16 |
InternBDB: 12 WN 65593840 | InternKon: 936 608 40 / 26
|
|
|
|
17 |
927 709 40
|
Cover |
2 |
InternKon: 936 608 40 / 27
|
|
|
|
18 |
|
Top roller |
6 |
InternBDB: 429 230 40 | InternKon: 936 608 40 / 4
|
585-3127a |
|
|
19 |
927 710 40
|
Cover |
2 |
InternKon: 936 608 40 / 28
|
|
|
|
20 |
307 804 99
|
Bolt |
8 |
InternBDB: M12x30/933 | InternKon: 936 608 40 / 29
|
|
