00 |
654 891 40
|
Hydr. motor assy. |
1 |
InternBDB: BrÑŒninghaus A2FM 500/60W-VZH-01 / 968 982 At-Nr. 710 769 73
|
|
|
|
01 |
|
Housing |
1 |
InternBDB: 929935 | InternKon: 968 982 / 4
|
|
|
|
02 |
513 375 98
|
Screw |
8 |
InternBDB: M20x55 /912 10.9 | InternKon: 968 982 / 10
|
|
|
|
03 |
767 347 73
|
Connection plate |
1 |
InternBDB: 929985 | InternKon: 968 982 / 5
|
|
|
|
04 |
345 632 99
|
Pin |
2 |
InternBDB: 10 M6x32/6325 | InternKon: 968 982 / 11
|
|
|
|
05 |
504 747 98
|
O-ring |
1 |
InternBDB: 192x4 Viton V 80 | InternKon: 968 982 / 8
|
|
|
|
06 |
173 494 40
|
Plug |
1 |
InternBDB: vsti33x2-ed | InternKon: 968 982 / 12
|
|
|
|
07 |
173 493 40
|
Plug |
1 |
InternBDB: vsti18x1,5-ed | InternKon: 968 982 / 13
|
|
|
|
08 |
766 389 73
|
Transmission, assy. fig-nos: 10-37 |
1 |
InternBDB: 968983 | InternKon: 968 982 / 1
|
|
|
|
10 |
753 246
|
Centering pin |
1 |
InternBDB: 788589 | InternKon: 968 983 / 12
|
|
|
|
11 |
345 648 99
|
Pin |
1 |
InternBDB: 8M6x24/6325 | InternKon: 968 983 / 32
|
|
|
|
12 |
767 349 73
|
Distribution |
1 |
InternBDB: 929934 | InternKon: 968 983 / 7
|
|
|
|
13 |
767 350 73
|
Spacer screw |
1 |
InternBDB: 934224 | InternKon: 968 983 / 17
|
|
|
|
14 |
767 351 73
|
Adjusting ring |
1 |
InternBDB: 934208 | InternKon: 968 983 / 13
|
|
|
|
15 |
767 352 73
|
Cylinder |
1 |
InternBDB: 728225 | InternKon: 968 983 / 6
|
|
|
|
16 |
767 353 73
|
Disk |
1 |
InternBDB: 934216 | InternKon: 968 983 / 15
|
|
|
|
17 |
767 354 73
|
Spring |
1 |
InternBDB: 934496 | InternKon: 968 983 / 14
|
|
|
|
18 |
767 355 73
|
Pivot |
1 |
InternBDB: 728268 | InternKon: 968 983 / 8
|
|
|
|
19 |
767 356 73
|
Piston with piston ring |
7 |
InternBDB: 771171 + 771198 | InternKon: 3 / 4
|
|
|
|
20 |
319 241 99
|
Screw |
14 |
InternBDB: M8x20/912 10.9 | InternKon: 968 983 / 39
|
|
|
|
21 |
754 374
|
Withdrawal plate |
1 |
InternBDB: 737062 | InternKon: 968 983 / 9
|
|
|
|
23 |
767 665 73
|
Drive shaft |
1 |
InternBDB: 944099 | InternKon: 968 983 / 1
|
|
|
|
24 |
502 246 98
|
Shaft seal |
1 |
InternBDB: 80x100x7 - Viton 393681 | InternKon: 968 983 / 24
|
|
|
|
25 |
504 098 98
|
O-ring |
1 |
InternBDB: 155x3,5 - Viton 80 | InternKon: 968 983 / 26
|
|
|
|
26 |
767 359 73
|
Sealing flange |
1 |
InternBDB: 926808 | InternKon: 968 983 / 11
|
|
|
|
27 |
342 682 99
|
Circlip |
1 |
InternBDB: 160x4/472 | InternKon: 968 983 / 29
|
|
|
|
29 |
767 700 73
|
Roller bearing |
1 |
InternBDB: 919929 | InternKon: 968 983 / 21
|
|
|
|
30 |
767 668 73
|
Adjusting disc |
1 |
InternBDB: 926807 | InternKon: 968 983 / 16
|
|
|
|
31 |
504 621 98
|
Roller bearing |
1 |
InternBDB: NJ 222 EM /5412 784435 | InternKon: 968 983 / 22
|
|
|
|
32 |
998 625
|
Shim ring |
1 |
InternBDB: 432989 110x140x1,0 | InternKon: 968 983 / 34
|
|
|
|
33 |
342 572 99
|
Circlip |
1 |
InternBDB: 110x4 /471 | InternKon: 968 983 / 30
|
|
|
|
34 |
504 748 98
|
O-ring |
1 |
InternBDB: 230x5 - Viton 80 | InternKon: 968 983 / 25
|
|
|
|
35 |
767 667 73
|
Race |
1 |
InternBDB: 926811 | InternKon: 968 983 / 10
|
|
|
|
36 |
754 496
|
Circlip |
1 |
InternBDB: 240x5 SO 127698 | InternKon: 968 983 / 28
|
|
|
|
37 |
767 733 73
|
Adjusting disc |
1 |
InternBDB: 926854 | InternKon: 968 983 / 20
|
|
|
|
|$$36 |
766 390 73
|
Seal kit fig-nos: 05-07,24,25,34 |
-2 |
InternBDB: E-St
|
|
|
|
|$$37 |
083 374
|
Adhesive set to fig-nos: 13, 20 50 ml |
-2 |
InternBDB: Loctite 242
|
|
