VALVE BLOCK | PC3000-6E S/N 06262 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	566 516 40	Valve block	1	InternKon: 886 298 40 / 1
02	761 591 73	Pressure sequence stag	1	InternBDB: Rexroth M 07010 - 583 485 576 054 40 \| InternKon: 886 298 40 / 2
03	448 991 40	Valve block	1	InternBDB: VENTILBLOCK 105X135 \| InternKon: 886 298 40 / 3
05	371 394 99	Non-return valve	2	InternBDB: VENTIL RHV 20-PSM-ED ST ZN WN 01087399 \| InternKon: 886 298 40 / 5
06	504 420 98	Non-return valve	2	InternBDB: VENTIL RHZ 20-PSM-ED ST ZN WN 01087499 \| InternKon: 886 298 40 / 6
07	371 977 99	Union	4	InternBDB: VERSHR FF S20 ST ZN DIN 02353 \| InternKon: 886 298 40 / 7
08	372 185 99	Union	3	InternBDB: VERSHR DD S20 ST ZN DIN 02353 \| InternKon: 886 298 40 / 8
09	372 462 99	Union	2	InternBDB: VERSHR D S20E ST ZN DIN 02353 \| InternKon: 886 298 40 / 9
10	372 173 99	Union	1	InternBDB: VERSHR DD L15 ST ZN DIN 02353 \| InternKon: 886 298 40 / 10
11	370 506 99	Union	1	InternBDB: VERSHR C S20E ST ZN DIN 02353 \| InternKon: 886 298 40 / 11
12	502 135 98	Bolt	4	InternBDB: 6KTSHR M 8X 95 8.8 DIN 00931 \| InternKon: 886 298 40 / 12
13	374 407 99	Socket	1	InternBDB: SDS-L15XM18x1,5- TYPE E ST A3C ISO 08434 \| InternKon: 886 298 40 / 13
14	488 026 40	Pipe assy. Ш 20	1	InternKon: 886 298 40 / 14
15	457 299 40	Pipe assy. Ш 20	1	InternKon: 886 298 40 / 15
16	488 027 40	Pipe assy. Ш 20	1	InternKon: 886 298 40 / 16
17	462 812 40	Pipe assy. Ш 20	1	InternKon: 886 298 40 / 17
18	371 260 99	Union nut	1	InternBDB: AS 20 /3870 \| InternKon: 886 298 40 / 18
19	371 233 99	Olive	1	InternBDB: S 20 /3861 \| InternKon: 886 298 40 / 19
20	461 133 40	Ball cock	1	InternBDB: Argus BK 3021-0016- 5942-50 \| InternKon: 886 298 40 / 20
21	215 539 99	Pipe Ш 20	1	InternBDB: 20x3 /2391 \| InternKon: 886 298 40 / 21
23	373 754 99	Union	1	InternBDB: TR 15/10/15-L 010 877 99 \| InternKon: 886 298 40 / 23
24	510 922 98	Hose assy.	1	InternBDB: SHL240 08X 450 DOL 10 DOL 10 90 WN 34195140 \| InternKon: 886 298 40 / 24
27	372 426 99	Union	1	InternBDB: VERSHR C L15E ST ZN DIN 02353 \| InternKon: 886 298 40 / 27
28	215 811 99	Pipe assy.	1	InternBDB: 15x1,5 / DIN 2391 \| InternKon: 886 298 40 / 28
31	371 275 99	Union nut	1	InternBDB: AL 15 \| InternKon: 886 298 40 / 22
32	374 416 99	Socket	1	InternBDB: SDS-L10XG 1/4A- TYPE E ST A3C ISO 08434 \| InternKon: 886 298 40 / 25
35	886 298 40	Valve block assy.	1	InternKon: 886 240 40 / 17
36	796 009 73	Seal kit	1	InternBDB: R961003382
