ROTARY JOINT | PC3000-6E S/N 06262 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
?	886 850 40	Rotary joint	1
?	566 886 40	Housing	1	InternKon: 886 850 40 / 1
?	891 804 40	Rotor	1	InternKon: 886 850 40 / 2
?	574 416 40	Drive ring	1	InternKon: 886 850 40 / 3
?	566 891 40	Cover	1	InternKon: 886 850 40 / 4
?	574 417 40	Race	1	InternKon: 886 850 40 / 5
?	576 034 40	Seal ring	8	InternBDB: Bu. u. Lu. GS-56133-2200-10N \| InternKon: 886 850 40 / 6
?	506 862 98	O-ring	8	InternBDB: 227,97x5,33 \| InternKon: 886 850 40 / 7
?	510 031 98	O-ring	1	InternBDB: 247,02x5,33 \| InternKon: 886 850 40 / 8
?	269 072 40	O-ring	1	InternBDB: 145,42x5,33 \| InternKon: 886 850 40 / 9
?	576 033 40	Seal ring	1	InternBDB: Rexroth V-seal WVA 0220-N60B-AF \| InternKon: 886 850 40 / 10
?	356 132 40	Rod guide ring	4	InternBDB: Bu. u. Lu. BB-50705-2200-C-TLG \| InternKon: 886 850 40 / 11
?	168 474 40	Plug	4	InternBDB: Vsti M42x2 ed \| InternKon: 886 850 40 / 12
?	360 873 40	Plug	1	InternBDB: Vsti M26x1,5 ed \| InternKon: 886 850 40 / 13
?	202 970 40	Plug	2	InternBDB: Vsti M16x1,5 ed \| InternKon: 886 850 40 / 14
?	004 860 98	Grease nipple	1	InternBDB: AR 1/4 \| InternKon: 886 850 40 / 15
?	319 299 99	Bolt	4	InternBDB: M16x70 /912 \| InternKon: 886 850 40 / 16
?	308 614 99	Bolt	8	InternBDB: M12x120 /931 \| InternKon: 886 850 40 / 17
?	316 216 99	Washer	4	InternBDB: 13 /6916 \| InternKon: 886 850 40 / 18
?	761 540 73	Seal kit consist. of fig-nos: 07-12	1	InternBDB: E-ST
