01 |
634 368 40
|
Lube pinion |
1 |
InternBDB: Lincoln-Helios 235-13140-9 Z=8 M=24 C=210mm | InternKon: 933 905 40 / 2
|
|
|
|
02 |
506 188 98
|
Bolt |
4 |
InternBDB: M12x75 /939 | InternKon: 933 905 40 / 14
|
|
|
|
03 |
340 467 99
|
Washer |
4 |
InternBDB: 13 /125 | InternKon: 933 905 40 / 16
|
|
|
|
04 |
334 600 99
|
Nut |
4 |
InternBDB: M 12 /985 | InternKon: 933 905 40 / 15
|
|
|
|
05 |
517 291 98
|
Union |
2 |
InternBDB: 6-SR/OMD WN 65593440 | InternKon: 933 905 40 / 28
|
|
|
|
06 |
|
Metering valve |
1 |
InternBDB: 269 880 40 | InternKon: 933 905 40 / 1
|
991-0091 |
|
|
07 |
317 319 40
|
Bolt |
2 |
InternBDB: M8x50 /931 | InternKon: 933 905 40 / 11
|
|
|
|
08 |
308 556 99
|
Thread plate |
2 |
InternKon: 933 905 40 / 13
|
|
|
|
10 |
512 273 98
|
Socket |
1 |
InternBDB: EVGE 12-S /3/8 NPT | InternKon: 933 905 40 / 18
|
|
|
|
11 |
341 754 40
|
Ultimate pressure control |
1 |
InternBDB: Typ X1T-5180 180 /+10 bar | InternKon: 933 905 40 / 5
|
|
|
|
12 |
551 391 40
|
Union |
1 |
InternBDB: GE 10-PS/R 1/4-ED / OMD | InternKon: 933 905 40 / 25
|
|
|
|
13 |
894 381 40
|
Connector plate |
1 |
InternKon: 933 905 40 / 24
|
|
|
|
16 |
634 481 40
|
Union |
1 |
InternBDB: Red 25/12-PS/OMD | InternKon: 933 905 40 / 19
|
|
|
|
17 |
604 527 40
|
Hose assy. DN 20x3400 |
1 |
InternBDB: DOS 25 /DOS 25 | InternKon: 933 905 40 / 6
|
|
|
|
18 |
516 843 98
|
Union |
1 |
InternBDB: SWE-10 ISO 08434 | InternKon: 933 905 40 / 23
|
|
|
|
19 |
906 981 40
|
Union |
6 |
InternBDB: GE 6L 1/8 NPT/OMD WN 65593340 | InternKon: 933 905 40 / 17
|
|
|
|
20 |
576 160 40
|
Plastic hose DN 4 |
-2 |
InternKon: 933 905 40 / 7
|
|
|
|
21 |
515 028 40
|
Collet |
4 |
InternBDB: 432-23031-1 | InternKon: 933 905 40 / 8
|
|
|
|
22 |
515 029 40
|
Hose connection 90° |
2 |
InternBDB: 532-30739-1 | InternKon: 933 905 40 / 10
|
|
|
|
23 |
515 027 40
|
Hose connection, straight |
2 |
InternBDB: 432-23030-1 | InternKon: 933 905 40 / 9
|
|
|
|
24 |
356 524 40
|
Plug to fig-no. 11 |
1 |
InternBDB: VG 95234-E10-SL-3SN
|
|
|
|
25 |
360 940 40
|
Connecting tube |
2 |
InternBDB: Lincoln 81646 | InternKon: 933 905 40 / 3
|
|
|
|
26 |
374 443 99
|
Union |
1 |
InternBDB: S-S 25 ISO 08434 | InternKon: 933 905 40 / 20
|
|
|
|
27 |
516 248 98
|
Socket |
1 |
InternBDB: S 25 /3942 | InternKon: 936 507 40 / 5
|
|
|
|
28 |
516 615 98
|
Union |
2 |
InternBDB: RS 25 /2353 | InternKon: 936 507 40 / 4
|
|
|
|
29 |
512 962 98
|
Hose assy. DN 20x6700 |
1 |
InternBDB: DOS 25 /DOS 25 | InternKon: 936 507 40 / 3
|
|
|
|
30 |
515 885 98
|
Socket |
1 |
InternBDB: EVGE 10-S /3/8 NPT | InternKon: 933 905 40 / 21
|
|
|
|
31 |
504 923 98
|
Half clamp |
6 |
InternBDB: S-3-G-32 /3015 | InternKon: 933 905 40 / 29
|
|
|
|
32 |
534 005 99
|
Weld on plate |
3 |
InternBDB: S-AP-A-3 /3015 | InternKon: 933 905 40 / 30
|
|
|
|
33 |
534 004 99
|
Cover plate |
3 |
InternBDB: S-DP-A-3 /3015 | InternKon: 933 905 40 / 31
|
|
|
|
34 |
308 581 99
|
Bolt |
6 |
InternBDB: M10x70 /931 | InternKon: 933 905 40 / 32
|
|
|
|
35 |
343 005 99
|
Washer |
6 |
InternBDB: 10,5 /93 | InternKon: 933 905 40 / 33
|
|
|
|
36 |
654 130 40
|
Injector protection cap |
4 |
InternBDB: Linco 83272 | InternKon: 933 905 40 / 34
|
|
|
|
37 |
907 080 40
|
Olive |
8 |
InternBDB: ES-4 S6 WN 655 939 40 | InternKon: 933 905 40 / 35
|
|
|
|
38 |
371 271 99
|
Union nut |
6 |
InternBDB: N-L 6 ISO 08434 | InternKon: 933 905 40 / 36
|
|
|
|
39 |
371 257 99
|
Union nut |
2 |
InternBDB: N-S 6 ISO 08434 | InternKon: 933 905 40 / 37
|
|
