LUBE PUMP STATION | PC5500-6 S/N 15049 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options	Reference
01	907 677 40	Lube pump station	1	InternBDB: HL-A 07.007 BL.57 Index A/ mit Peilstab
02		Lube pump	1	InternBDB: 509-32178-1 /769 397 73 \| InternKon: HL-A07.007BL57 / 1	991-0266a
03	770 396 73	Housing, empty	1	InternBDB: 237-13413-9 /75x160x75
04	794 378 73	Cover assy.	1	InternBDB: 409-70605-1 \| InternKon: HL-A07.007BL57 / 2
05	505 940 99	Assembly rail	-2	InternBDB: 237-13393-1
06	770 401 73	Union	1	InternBDB: 223-14187-6 \| InternKon: HL-A07.007BL57 / 45
07	794 379 73	Elbow union	1	InternBDB: 223-12365-2 \| InternKon: HL-A07.007BL57 / 19
08	374 418 99	Socket	1	InternBDB: EVGE 20-S G 3/4 C \| InternKon: HL-A07.007BL57 / 4
09	698 303 73	Filter assy.	1	InternBDB: 84 004 \| InternKon: HL-A07.007BL57 / 6
10	372 052 99	Union	2	InternBDB: EVL 20-SC 223-13761-7 \| InternKon: HL-A07.007BL57 / 7
11	372 971 99	Union	1	InternBDB: KOR 20/10-SC \| InternKon: HL-A07.007BL57 / 8
12	372 048 99	Union	1	InternBDB: EVL 10-SC \| InternKon: HL-A07.007BL57 / 9
13	501 610 98	Reducing socket	2	InternBDB: 1/2 NPT x G 3/4 \| InternKon: HL-A07.007BL57 / 5
14	372 869 99	Union	1	InternBDB: MAVE 10-S G 1/4 C 223-14268-2 \| InternKon: HL-A07.007BL57 / 10
15	769 894 73	Elbow union	1	InternBDB: 223-13620-2 \| InternKon: HL-A07.007BL57 / 3
16	698 321 73	Pressure gauge 0-400 bar	1	InternBDB: Ш 63 234-13132-7 \| InternKon: HL-A07.007BL57 / 12
17	371 852 99	Breech block	1	InternBDB: 10-L/S 223-13640-3 \| InternKon: HL-A07.007BL57 / 11
18	356 265 40	Corner angle	2	InternBDB: 237-13314-4 /116 535-04
19	373 692 99	Union	1	InternBDB: GR 25/20-SC WN 010 878 99 \| InternKon: HL-A07.007BL57 / 16
23	215 219 99	Pipe Ш 20	-2	InternKon: HL-A07.007BL57 / 41
24	768 506 73	Union	1	InternBDB: GE 20-S G 1/2 C 223-12360-6 \| InternKon: HL-A07.007BL57 / 22
25	769 879 73	2/2-Directional solenoid valve	1	InternBDB: 235-13185-1 \| InternKon: HL-A07.007BL57 / 20
26	766 876 73	Plug	1	InternBDB: 236-13869-1 \| InternKon: HL-A07.007BL57 / 21
27	768 507 73	Clamp	2	InternBDB: 226-13058-3 \| InternKon: HL-A07.007BL57 / 15
28	768 508 73	Elbow union	2	InternBDB: SWVE 12-L G 3/8 223-13669-3 \| InternKon: HL-A07.007BL57 / 27
29	215 424 99	Pipe Ш 12	-2	InternKon: HL-A07.007BL57 / 40
30	576 472 40	Union	1	InternBDB: GR 15/12-L 223-12542-8 \| InternKon: HL-A07.007BL57 / 32
32	319 133 99	Screw	1	InternBDB: M6x30 /912 \| InternKon: HL-A07.007BL57 / 39
33	794 137 73	Clamp	1	InternBDB: 226-13058-5 \| InternKon: HL-A07.007BL57 / 31
34	371 259 99	Nut	1	InternBDB: AS 12 M 12 /223-12373-2 \| InternKon: HL-A07.007BL57 / 33
35	698 301 73	Socket	1	InternBDB: GE 10-L G 1/4 223-12272-9 \| InternKon: HL-A07.007BL57 / 35
36	769 875 73	2/2-Directional solenoid valve	1	InternBDB: 235-13181-8 \| InternKon: HL-A07.007BL57 / 36
37	318 603 99	Screw	2	InternBDB: M6x16 /912 200-13022-4 \| InternKon: HL-A07.007BL57 / 37
41	794 528 73	Level indication assy. analog	1	InternBDB: Linco 529-36999-8.0 \| InternKon: HL-A07.007BL57 / 26
42	794 330 73	Junction box assy.	1	InternBDB: E 631 \| InternKon: HL-A07.007BL57 / 42
43	764 658 73	Filter	1	InternBDB: BF8-R 1/4 235-13029-8 \| InternKon: HL-A07.007BL57 / 23
46	698 316 73	Filter element	1	InternBDB: Linco 69524
47	371 241 99	Olive	1	InternBDB: D 12-US 223-12296-1 \| InternKon: HL-A07.007BL57 / 34
49	696 293 73	Seal ca. 1900	-2	InternKon: HL-A07.007BL57 / 44
50	490 372 40	Series terminal PE	5	InternBDB: 237-13318-9 /165 113-16
51	356 271 40	Series terminal PE	10	InternBDB: 237-13318-8 /115 116-07
52	356 272 40	Cover plate	2	InternBDB: 237-13314-4 /118 368-16
53	906 077 40	Cover plate	2	InternBDB: 237-13312-2 /199 878-01
54	770 399 73	Socket shell	1	InternBDB: 236-14461-9 /HD 10-9P-96 Deutsch
55	896 769 40	Protection cap	1	InternBDB: 236-10022-1 /HDC-16-9
56	770 402 73	Seal	1	InternBDB: 236-14462-8
57	906 695 40	Pin contact	9	InternBDB: 236-14462-5 /0460-202-16141
58	794 083 73	Dipstick	1	InternBDB: 409-70376-1 \| InternKon: HL-A07.007BL57 / 18
59	794 353 73	Sleeve	1	InternBDB: 304-16058-1 G 3/4x45 \| InternKon: 529-36999-8.0 / 1
60	794 338 73	Seal ring	1	InternBDB: 35x25x2 934 035-E \| InternKon: 529-36999-8.0 / 2
61	794 339 73	Socket	1	InternBDB: 222-12047-8 G 3/4xG 1/2 \| InternKon: 529-36999-8.0 / 3
62	940 733 40	Sensor capacitiv assy.	1	InternBDB: 535-34229-1 eingestellt fьr Container \| InternKon: 529-36999-8.0 / 4
63	794 521 73	Cable to fig.-no.62	1	InternBDB: 113-35258-4
