01 |
269 887 40
|
Metering valve, assy. |
1 |
InternBDB: Lincoln-Heli. SL1/81770-3
|
|
|
|
02 |
269 880 40
|
Metering valve, assy. |
1 |
InternBDB: SL1/81770-4
|
|
|
|
03 |
693 442
|
Body
to fig-no: 01 |
1 |
InternBDB: 11963
|
|
|
|
04 |
693 443
|
Body
to fig-no: 02 |
1 |
InternBDB: 11964
|
|
|
|
05 |
693 444
|
Adjusting screw |
1 |
InternBDB: 11623
|
|
|
|
06 |
693 445
|
Nut |
1 |
InternBDB: 11624
|
|
|
|
07 |
693 446
|
Screw plug |
1 |
InternBDB: 11450
|
|
|
|
08 |
|
Seal
These parts are not sold
separately |
2 |
InternBDB: 31057
|
|
|
|
09 |
|
Disk
These parts are not sold
separately |
2 |
InternBDB: 48242
|
|
|
|
10 |
|
Seal ring
These parts are not sold
separately |
1 |
InternBDB: 34155
|
|
|
|
11 |
|
Bolt with nut
These parts are not sold
separately |
1 |
InternBDB: 11626
|
|
|
|
12 |
|
Disk
These parts are not sold
separately |
2 |
InternBDB: 48231
|
|
|
|
13 |
|
Seal ring
These parts are not sold
separately |
1 |
InternBDB: 35081
|
|
|
|
14 |
|
Piston
These parts are not sold
separately |
1 |
InternBDB: 11451
|
|
|
|
15 |
|
Compression spring
These parts are not sold
separately |
1 |
InternBDB: 55136
|
|
|
|
16 |
|
Spring retainer
These parts are not sold
separately |
1 |
InternBDB: 11717
|
|
|
|
17 |
|
Seal ring
These parts are not sold
separately |
1 |
InternBDB: 34137
|
|
|
|
18 |
|
Disk
These parts are not sold
separately |
1 |
InternBDB: 11816
|
|
|
|
19 |
|
Seal ring
These parts are not sold
separately |
1 |
InternBDB: 34136
|
|
|
|
20 |
|
Disk
These parts are not sold
separately |
1 |
InternBDB: 48230
|
|
|
|
21 |
|
Piston
These parts are not sold
separately |
1 |
InternBDB: 11815
|
|
|
|
22 |
693 517
|
Seal |
1 |
InternBDB: 31064
|
|
|
|
23 |
693 500
|
Adapter bolt |
1 |
InternBDB: 11961
|
|
|
|
24 |
693 501
|
Valve housing |
1 |
InternBDB: 11814
|
|
|
|
25 |
693 502
|
Union |
1 |
InternBDB: 90471
|
|
|
|
26 |
270 131 40
|
Metering valve assy. |
1 |
InternBDB: SL1/81770-2
|
|
|
|
27 |
697 845 73
|
Body to fig-no: 26 |
1 |
InternBDB: 11962
|
|
|
|
28 |
551 969 40
|
Metering valve assy. |
1 |
InternBDB: SL 1 /81770-5
|
|
|
|
29 |
764 009 73
|
Body to fig-no: 28 |
1 |
InternBDB: 11965
|
|
|
|
|$$30 |
764 312 73
|
Spare metering valve
to fig-nos. 01,02,26,28 |
1 |
InternBDB: SL 1 /81733 A
|
|
|
|
|$$31 |
764 780 73
|
Repair kit |
1 |
InternBDB: 250 158
|
|
