REFUELING EQUIPMENT | PC4000-6E S/N 08202 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	930 827 40	Plate	1	InternKon: 930 828 40 / 1
02	307 804 99	Bolt	4	InternBDB: M12x30/933 \| InternKon: 930 828 40 / 7
03	340 467 99	Washer	4	InternBDB: 13/125 \| InternKon: 930 828 40 / 10
04	515 878 40	Plate (central lubrication)	1	InternKon: 930 828 40 / 23
05	515 879 40	Plate (pinion lubrication)	1	InternKon: 930 828 40 / 24
06	515 877 40	Plate (hydr. oil)	1	InternKon: 930 828 40 / 22
07	515 880 40	Plate (water for cab)	1	InternKon: 930 828 40 / 25
08	334 600 99	Nut	4	InternBDB: M12/985 \| InternKon: 930 828 40 / 9
09	513 148 98	Hose assy. DN 20x5300	1	InternBDB: DOL 22 /DOL 22-90 WN34195140 \| InternKon: 930 828 40 / 37
10	514 744 98	Hose assy. DN 20x9400	2	InternBDB: DOL 22 /DOL 22-90 \| InternKon: 930 828 40 / 38
11	513 455 98	Hose assy. DN 20x8800	1	InternBDB: DOL 22 /DOL 22-90 \| InternKon: 930 828 40 / 39
12	517 057 98	Union	1	InternBDB: SWDS-L22XG 3/4 ISO 08434 \| InternKon: 930 828 40 / 30
13	516 281 98	Union	2	InternBDB: SWRT-L22 ISO 08434 \| InternKon: 930 828 40 / 28
14	374 409 99	Socket	5	InternBDB: SDS-L 22X M26x1,5 ISO 08434 \| InternKon: 930 828 40 / 26
15	270 861 40	Filler neck	1	InternBDB: Wiggins 6005 A 12 \| InternKon: 930 828 40 / 15
16	341 710 40	Filler neck	1	InternBDB: Wiggins OSP 2 \| InternKon: 930 828 40 / 17
17	341 711 40	Filler neck	1	InternBDB: Wiggins 6000 B 12 \| InternKon: 930 828 40 / 16
18	270 862 40	Cap	1	InternBDB: Wiggins 6008-12 \| InternKon: 930 828 40 / 19
19	360 856 40	Cap	1	InternBDB: Wiggins 6009-12 \| InternKon: 930 828 40 / 20
20	323 906 40	Filler neck	1	InternBDB: EC 285 A8 \| InternKon: 930 828 40 / 18
21	324 438 40	Cap	1	InternBDB: 1208-8 \| InternKon: 930 828 40 / 21
23	323 430 40	Box, aluminium	1	InternBDB: Bopla A 123 \| InternKon: 903 475 40 / 4
24	942 119 40	Indicator lamp with LED, red	7	InternKon: 903 475 40 / 2
26	323 677 40	Press button adapter	1	InternBDB: Lumitas 040 122 \| InternKon: 903 475 40 / 5
27	255 328 40	Circuit element	1	InternBDB: 04.910.50 \| InternKon: 903 475 40 / 1
28	305 992 99	Ball cock	1	InternBDB: G 3/4 WN 341 960 40 \| InternKon: 930 828 40 / 14
29	374 438 99	Socket	1	InternBDB: SDS-L22X 3/4 ISO 08434 \| InternKon: 930 828 40 / 31
30	551 483 40	Union	1	InternBDB: Red 22/15-PL/OMD \| InternKon: 930 828 40 / 33
31	510 903 98	Hose assy. DN20x8600	1	InternBDB: DOL 22 /DOL 22-90 \| InternKon: 930 828 40 / 41
32	518 046 98	Hose assy. DN 12x1500	1	InternBDB: DOL 15 /DOL 15-90 \| InternKon: 930 828 40 / 42
34	516 160 98	Union	3	InternBDB: SWE-L22 ISO 08434 \| InternKon: 930 828 40 / 27
35	515 882 98	Union	1	InternBDB: GV 22-LR WN 655 906 40 \| InternKon: 930 828 40 / 29
36	654 458 40	Valve	2	InternBDB: RHD 22-PL/OMD \| InternKon: 930 828 40 / 13
37	906 751 40	Union	1	InternBDB: GR22/12-L/OMD WN65593240 \| InternKon: 930 828 40 / 34
38	906 752 40	Olive	2	InternBDB: ES-4 L22 \| InternKon: 930 828 40 / 11
39	371 277 99	Union nut	2	InternBDB: N-L 22 ISO 08434 \| InternKon: 930 828 40 / 12
40	906 347 40	Olive	1	InternBDB: ES-4 S12 \| InternKon: 930 828 40 / 35
41	371 274 99	Union nut	1	InternBDB: N-L 12 ISO 08434 \| InternKon: 930 828 40 / 36
42	403 239 40	Pipe	1	InternKon: 930 828 40 / 2
43	410 031 40	Pipe	1	InternKon: 930 828 40 / 3
44	500 942 99	Clamp Set	1	InternBDB: L-3-R-22/3015 \| InternKon: 930 828 40 / 4
45	533 992 99	Weld on plate	1	InternBDB: L-AP-K-3/3015 \| InternKon: 930 828 40 / 5
46	511 856 98	Cover plate	1	InternBDB: L-3 /3015 \| InternKon: 930 828 40 / 6
47	308 536 99	Bolt	2	InternBDB: M6x40/931 \| InternKon: 930 828 40 / 8
