PC4000-6 S/N 08195

Komatsu parts book diagram for PC4000-6 S/N 08195: TRACK GROUP - IDLER SIDE RI + LE

01 01 02 03 04 04 05 05 05 06 06 07 08 09 09 10 10 11 11 12 13

	#	Part Number	Partname	Quantity	Options	Reference
	01		Track roller	14	InternBDB: 895 904 40 \| InternKon: 945 147 40 / 2	355-3135b
	02		Idler assy.	2	InternBDB: 429 697 40 \| InternKon: 945 147 40 / 3	355-3115c
	03	934 565 40	Nut	56	InternBDB: M30 \| InternKon: 945 147 40 / 14
	03	934 580 40	Nut	56	InternBDB: M30 TT \| InternKon: 945 147 40 / 14
	04	904 210 40	Plate	4	InternKon: 945 147 40 / 15
	05	255 057 40	Washer	160	InternBDB: 31 / DIN 6916 \| InternKon: 945 147 40 / 18
	06	308 342 99	Bolt	56	InternBDB: M30x240 / DIN 931 / 10.9 \| InternKon: 945 147 40 / 29
	06	511 761 98	Bolt	56	InternBDB: M30x240 10.9 Kaltzдh \| InternKon: 945 147 40 / 29
	07	316 212 99	Washer	32	InternBDB: 21 / DIN 6916 \| InternKon: 945 147 40 / 37
	08	302 573 99	Bolt	32	InternBDB: M20x100 / DIN 931 / 10.9 \| InternKon: 945 147 40 / 38
	08	514 763 98	Bolt	32	InternBDB: M20x100 10.9 Kaltzдh \| InternKon: 945 147 40 / 38
	09		Tensioner	4	InternBDB: 912 655 40 \| InternKon: 945 147 40 / 39	355-3118b
	10	930 496 40	Space keeper	4	InternBDB: 150x260 \| InternKon: 945 147 40 / 41
	11	319 311 99	Bolt	16	InternBDB: M20x100 / DIN 912 / 10.9 \| InternKon: 945 147 40 / 42
	11	507 085 98	Bolt	16	InternBDB: M20x100 10.9 Kaltzдh \| InternKon: 945 147 40 / 42
	12	502 213 98	Bolt	24	InternBDB: M30x140 / DIN 931 / 10.9 \| InternKon: 945 147 40 / 55
	12	510 516 98	Bolt	24	InternBDB: M30x140 10.9 Kaltzдh \| InternKon: 945 147 40 / 55
	13		Top roller	6	InternBDB: 429 687 40 \| InternKon: 945 147 40 / 7	515-3140b

Komatsu PC4000-6 S/N 08195 parts catalog PDF

TRACK GROUP - IDLER SIDE RI + LE (355-3110e) in PC4000-6 S/N 08195. Diagram image and parts list.
