PC4000-6 S/N 08195

Komatsu parts book diagram for PC4000-6 S/N 08195: DRIVE SPROCKET

01 02 03 04 05 06 07 08 09 10 11

	#	Part Number	Partname	Quantity	Options	Reference
	01	643 936 40	Drive sprocket assy., oversize (cold weather design)	1	InternBDB: Ш1792
	01	643 940 40	Drive sprocket assy. (cold weather design)	1	InternBDB: Ш1760
	01	643 945 40	Drive sprocket assy. (standard)	1	InternBDB: Ш1760
	02	887 105 40	Drive sprocket, oversize	1	InternKon: 643 945 40 / 1
	03	361 031 40	Drive sprocket hub	1	InternKon: 643 945 40 / 2
	04	504 386 98	Bolt (cold weather design)	12	InternBDB: M36x200 / 10.9 Kaltzдh / DIN 931 \| InternKon: 643 945 40 / 4
	05	501 124 98	Nut (cold weather design)	12	InternBDB: M36 / 10 Kaltzдh / DIN 934 \| InternKon: 643 945 40 / 5
	06	255 056 40	Washer	12	InternBDB: 37 / C45-TQ+T / DIN 6916 \| InternKon: 643 945 40 / 6
	07	429 691 40	Pin, Oversize Ш 52	6	InternBDB: 160 \| InternKon: 643 945 40 / 7
	08	887 110 40	Drive sprocket	1	InternKon: 643 945 40 / 1
	09	429 689 40	Pin Ш 50	6	InternBDB: 160 \| InternKon: 643 945 40 / 3
	10	308 356 99	Bolt (standard)	12	InternBDB: M36x200 / 10.9 / DIN 931 \| InternKon: 643 945 40 / 4
	11	332 369 99	Nut (standard)	12	InternBDB: M36 / 10 / DIN 934 \| InternKon: 643 945 40 / 5

Komatsu PC4000-6 S/N 08195 parts catalog PDF

DRIVE SPROCKET (355-3125) in PC4000-6 S/N 08195. Diagram image and parts list.
