01 |
907 622 40
|
Gear pump |
1 |
InternBDB: Kracht KP3/82 S20J Q00 6VL2/405
|
|
|
|
02 |
|
Housing |
1 |
InternBDB: KP3/82 E.0221970001 | InternKon: Z-NR. 31161421-01 / 10
|
|
|
|
03 |
|
Cover flange |
1 |
InternBDB: E.0221950001 | InternKon: Z-NR. 31161421-01 / 20
|
|
|
|
04 |
|
Waving wheel |
1 |
InternBDB: E.0222000001 | InternKon: Z-NR. 31161421-01 / 30
|
|
|
|
05 |
|
Pin wheel |
1 |
InternBDB: E.0099770001 | InternKon: Z-NR. 31161421-01 / 40
|
|
|
|
06 |
|
Screed plate |
2 |
InternBDB: E.0135650001 | InternKon: Z-NR. 31161421-01 / 50
|
|
|
|
07 |
|
Bearing bush |
4 |
InternBDB: E.0101200001 | InternKon: Z-NR. 31161421-01 / 60
|
|
|
|
08 |
|
Dowel pin |
2 |
InternBDB: E.0111170001 | InternKon: Z-NR. 31161421-01 / 70
|
|
|
|
09 |
|
Seal |
2 |
InternBDB: E.0100020001 | InternKon: Z-NR. 31161421-01 / 80
|
|
|
|
10 |
|
Support strip |
2 |
InternBDB: E.0192210001 | InternKon: Z-NR. 31161421-01 / 90
|
|
|
|
11 |
|
Disc |
4 |
InternBDB: E.0112350001 | InternKon: Z-NR. 31161421-01 / 100
|
|
|
|
12 |
|
Serial plate |
1 |
InternBDB: E.9192130001 | InternKon: Z-NR. 31161421-01 / 110
|
|
|
|
13 |
|
Cylinder bolt |
4 |
InternBDB: N.0009120025 M16x110 12.9 912 | InternKon: Z-NR. 31161421-01 / 120
|
|
|
|
14 |
|
Circlip |
1 |
InternBDB: 52x2 | InternKon: Z-NR. 31161421-01 / 130
|
|
|
|
16 |
|
O-ring |
1 |
InternBDB: 125x3,0 FP90 | InternKon: Z-NR. 31161421-01 / 150
|
|
|
|
17 |
793 357 73
|
Shaft seal |
1 |
InternBDB: WDR 35X52x6/6,5 BABSL 05 FP L0044170144 | InternKon: Z-NR. 31161421-01 / 160
|
|
|
|
18 |
|
Half-round-grooved drive stud |
2 |
InternBDB: N.0014760002 | InternKon: Z-NR. 31161421-01 / 170
|
|
|
|
19 |
|
Protective plug |
1 |
InternBDB: L.0064000044 | InternKon: Z-NR. 31161421-01 / 180
|
|
|
|
20 |
|
Protective plug |
1 |
InternBDB: L.0064000009 | InternKon: Z-NR. 31161421-01 / 190
|
|
|
|
31 |
|
Adapter |
1 |
InternBDB: E.0221980001 | InternKon: Z-NR. 31161421-01 / 300
|
|
|
|
32 |
793 357 73
|
Shaft seal |
1 |
InternBDB: WDR 35X52x6/6,5 BABSL 05 FP L0044170144 | InternKon: Z-NR. 31161421-01 / 310
|
|
|
|
33 |
|
Circlip |
1 |
InternBDB: N.0004720079 | InternKon: Z-NR. 31161421-01 / 320
|
|
|
|
35 |
|
Strainer |
1 |
InternBDB: L.0067020001 | InternKon: Z-NR. 31161421-01 / 340
|
|
|
|
36 |
307 869 99
|
Bolt |
2 |
InternBDB: N.0009330079 | InternKon: Z-NR. 31161421-01 / 350
|
|
|
|
37 |
319 157 99
|
Cylinder bolt |
4 |
InternBDB: N.0009120168 | InternKon: Z-NR. 31161421-01 / 360
|
|
|
|
40 |
940 048 40
|
Gear pump |
1 |
InternBDB: Kracht KP3/71 S20G Q00 6VL2/405
|
|
|
|
41 |
|
Housing |
1 |
InternBDB: KP3/71 E.0221960001 | InternKon: Z-NR. 31161421-01 / 10
|
|
|
|
42 |
|
Waving wheel |
1 |
InternBDB: E.0222000001 | InternKon: Z-NR. 31161421-01 / 30
|
|
|
|
43 |
|
Pin wheel |
1 |
InternBDB: E.0099770001 | InternKon: Z-NR. 31161421-01 / 40
|
|
|
|
44 |
|
Cylinder bolt |
4 |
InternBDB: N.0009120411 M16x100 12.9 912 | InternKon: Z-NR. 31161421-01 / 120
|
|
|
|
45 |
|
Protective plug |
1 |
InternBDB: L.0064000044 | InternKon: Z-NR. 31161421-01 / 180
|
|
|
|
50 |
795 493 73
|
Seal kit pumps |
1 |
InternBDB: 0084860048
|
|
