02 |
|
Hydraulic cylinder
see page 515 - 5075 |
2 |
InternBDB: 641 940 40 | InternKon: 641 974 40 / 1
|
|
|
|
03 |
630 331 40
|
Piping, assy.
fig nos: 04-26 |
2 |
InternBDB: E-ST | InternKon: 641 974 40 / 2
|
|
|
|
04 |
576 927 40
|
Half clamp |
2 |
InternKon: 630 331 40 / 3
|
|
|
|
05 |
576 926 40
|
Half clamp |
2 |
InternKon: 630 331 40 / 2
|
|
|
|
06 |
006 728 98
|
O-ring |
4 |
InternBDB: 47x4 NB90 011 745 99 | InternKon: 630 331 40 / 19
|
|
|
|
07 |
267 135 40
|
Connecting block |
4 |
InternKon: 630 331 40 / 1
|
|
|
|
08 |
319 293 99
|
Bolt |
16 |
InternBDB: M16x100/912 10.9 | InternKon: 630 331 40 / 13
|
|
|
|
09 |
768 624 73
|
Pipe, assy. Ш 50, |
2 |
InternBDB: 627 522 40 | InternKon: 630 331 40 / 4
|
|
|
|
10 |
500 127 98
|
Flange |
4 |
InternBDB: FE-5000-24/6 | InternKon: 630 331 40 / 9
|
|
|
|
11 |
501 898 98
|
Collar ring |
2 |
InternBDB: K-5060-24 | InternKon: 630 331 40 / 11
|
|
|
|
12 |
500 203 98
|
Collar ring |
2 |
InternBDB: KO-5060-24 | InternKon: 630 331 40 / 10
|
|
|
|
13 |
356 209 40
|
Tetra seal |
2 |
InternBDB: Busak FR76-5937 -2200 | InternKon: 630 331 40 / 18
|
|
|
|
16 |
334 601 99
|
Nut |
4 |
InternBDB: M16/985 | InternKon: 630 331 40 / 17
|
|
|
|
18 |
308 632 99
|
Bolt |
4 |
InternBDB: M16x60/931 | InternKon: 630 331 40 / 14
|
|
|
|
19 |
534 009 99
|
Plate |
2 |
InternBDB: ES6 011 839 99 | InternKon: 630 331 40 / 6
|
|
|
|
20 |
502 976 98
|
Half clamp |
4 |
InternBDB: CS6/50 011 839 99 | InternKon: 630 331 40 / 7
|
|
|
|
21 |
534 008 99
|
Plate |
2 |
InternBDB: DS6 011 839 99 | InternKon: 630 331 40 / 8
|
|
|
|
22 |
343 006 99
|
Washer |
4 |
InternBDB: 13/93 | InternKon: 630 331 40 / 16
|
|
|
|
23 |
308 459 99
|
Bolt |
4 |
InternBDB: M12x100/931 -10.9 | InternKon: 630 331 40 / 15
|
|
|
|
25 |
500 895 98
|
Round bar steel Ш 10x50
Bulk ware, state length
required |
4 |
InternBDB: Ш 10 /1013 | InternKon: 630 331 40 / 5
|
|
|
|
26 |
319 289 99
|
Bolt |
4 |
InternBDB: M16x60 /912 10.9 | InternKon: 630 331 40 / 12
|
|
