01 |
255 348 40
|
Drive, assy. |
1 |
InternBDB: SWF 105 323 | InternKon: 431 196 40 / 85
|
|
|
|
02 |
|
Wiper motor |
1 |
InternBDB: 402 676
|
|
|
|
03 |
255 349 40
|
Wiper arm, assy. 750 lg. |
1 |
InternBDB: 104.580 | InternKon: 431 196 40 / 83
|
|
|
|
04 |
255 350 40
|
Wiper blade |
1 |
InternBDB: WBP 104.579 | InternKon: 431 196 40 / 84
|
|
|
|
05 |
318 741 40
|
Engine covering |
1 |
|
|
|
|
06 |
058 453 40
|
Wiper motor 120 ? |
1 |
InternBDB: SWF VSWL 400445 | InternKon: 431 196 40 / 86
|
|
|
|
07 |
269 616 40
|
Wiper arm with spring 350 lg. |
1 |
InternBDB: SWF 104 623 | InternKon: 431 196 40 / 87
|
|
|
|
08 |
343 871 40
|
Wiper blade 400 lg. |
1 |
InternBDB: SWF 104 570 | InternKon: 431 196 40 / 88
|
|
|
|
09 |
196 484 40
|
Water can 3,5 l |
1 |
InternBDB: WRB 102 488 | InternKon: 427 959 40 / 12
|
|
|
|
10 |
196 482 40
|
Diaphragm pump |
1 |
InternBDB: WPE 500 441 | InternKon: 427 959 40 / 13
|
|
|
|
11 |
196 485 40
|
Non-return valve |
1 |
InternBDB: WRD 103 501 | InternKon: 427 959 40 / 14
|
|
|
|
12 |
196 488 40
|
Hose Ш 6
Bulk ware, state length
required |
-2 |
InternBDB: 6x1 PVC glasklar
6x1 /PVC glasklar | InternKon: 427 959 40 / 15
|
|
|
|
13 |
385 790 40
|
Retainer |
1 |
InternKon: 385 700 40 / 11
|
|
|
|
14 |
318 308 99
|
Bolt |
3 |
InternBDB: M6x16 /963 | InternKon: 385 700 40 / 32
|
|
|
|
15 |
346 499 99
|
Lock washer |
3 |
InternBDB: 6 /128 | InternKon: 385 700 40 / 34
|
|
|
|
16 |
332 110 99
|
Nut |
3 |
InternBDB: 6 /934 | InternKon: 385 700 40 / 33
|
|
|
|
17 |
307 752 99
|
Bolt |
3 |
InternBDB: M8x20 /933 | InternKon: 385 700 40 / 29
|
|
|
|
18 |
346 510 99
|
Lock washer |
3 |
InternBDB: 8 /128 | InternKon: 385 700 40 / 30
|
|
|
|
19 |
320 975 99
|
Screw |
2 |
InternBDB: AM 4x16 /84 | InternKon: 385 700 40 / 48
|
|
|
|
20 |
340 459 99
|
Washer |
2 |
InternBDB: A 4,3 /125 | InternKon: 385 700 40 / 49
|
|
