635 229 40
|
Pilot oil unit assy. |
1 |
InternBDB: Rexroth 4TH6 V06-1x, YT 34 M 01
|
|
|
|
? |
765 500 73
|
Mounting group - control |
1 |
InternBDB: 213 104 00
|
|
|
|
? |
765 501 73
|
Bellow 15 ? |
1 |
InternBDB: 258 137 00 | InternKon: RD 64 555-E / 1.37
|
|
|
|
? |
756 342 73
|
Nut |
1 |
InternBDB: 111 366.099 | InternKon: RD 64 555-E / 1.3
|
|
|
|
? |
754 445
|
Nut |
1 |
InternBDB: 188 579.000 | InternKon: RD 64 555-E / 1.4
|
|
|
|
? |
754 446
|
Shift disk |
1 |
InternBDB: 184 060.000 | InternKon: RD 64 555-E / 1.5
|
|
|
|
? |
754 447
|
Cardan joint |
1 |
InternBDB: 184 081.001 | InternKon: RD 64 555-E / 1.6
|
|
|
|
? |
765 502 73
|
Retainer |
1 |
InternBDB: 258 398 00 | InternKon: RD 64 555-E / 1.31
|
|
|
|
? |
765 503 73
|
Upper |
1 |
InternBDB: 187 877.002 | InternKon: RD 64 555-E / 2.1
|
|
|
|
? |
500 095 98
|
O-ring |
1 |
InternBDB: 14x2 | InternKon: RD 64 555-E / 2.4
|
|
|
|
? |
972 166
|
O-ring |
1 |
InternBDB: 59,99x2,62 | InternKon: RD 64 555-E / 2.5
|
|
|
|
? |
344 969 99
|
Pin |
2 |
InternBDB: 5x12 /7 | InternKon: RD 64 555-E / 2.3
|
|
|
|
? |
504 708 98
|
O-ring |
1 |
InternBDB: 13,6x2,7 | InternKon: RD 64 555-E / 2.6
|
|
|
|
? |
756 339 73
|
Bolt |
1 |
InternBDB: 191 853.000 | InternKon: RD 64 555-E / 2.7
|
|
|
|
? |
754 450
|
Repair kit - tappet |
1 |
InternBDB: 309 299
|
|
|
|
? |
962 875
|
Lock pad |
4 |
InternBDB: 180 719.001 | InternKon: RD 64 555-E / 3.5
|
|
|
|
? |
754 452
|
Spring plate |
4 |
InternBDB: 184 000.002 | InternKon: RD 64 555-E / 3.6
|
|
|
|
? |
765 504 73
|
Compression spring |
4 |
InternBDB: 190 038.00 | InternKon: RD 64 555-E / 3.7
|
|
|
|
? |
765 505 73
|
Return spring |
4 |
InternBDB: 191 133 00 | InternKon: RD 64 555-E / 3.8
|
|
|
|
? |
994 954
|
Shim ring 0,1 |
4 |
InternBDB: 181 213.000 | InternKon: RD 64 555-E / 3.9
|
|
|
|
? |
994 955
|
Shim ring 0,2 |
4 |
InternBDB: 181 214.000 | InternKon: RD 64 555-E / 3.9
|
|
|
|
? |
989 568
|
Shim ring 0,5 |
4 |
InternBDB: 182 646.000 | InternKon: RD 64 555-E / 3.9
|
|
|
|
? |
765 506 73
|
Handle assy, incl. 27 |
1 |
InternBDB: 213 114 00 | InternKon: RD 64 555-E / 1.56
|
|
|
|
? |
765 507 73
|
Push button, set |
1 |
InternBDB: 213 103 00
|
|
