H135S S/N 61064

Komatsu parts book diagram for H135S S/N 61064: CABLES, CAB SUPPORT

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	385 224 40	Socket	3	InternBDB: Contact 10.5830
	?	358 264 40	Safety cover	3	InternBDB: 10.4816
	?	385 227 40	Insert	3	InternBDB: 10.5320 H-A 16 SS (1-16)
	?	385 228 40	Insert	3	InternBDB: 10.5420 H-A 16 SS (17-32)
	?	600 815 99	Reducing 29-21	3	InternBDB: Sievert 246 6452 H-PG 29-21/ DIN 46320
	?	323 354 40	Cable union	3	InternBDB: 5010.100.021
	?	356 250 40	Socket	6	InternBDB: 520.030.021
	?	356 242 40	Cable protection hose PG 21 Bulk ware, state length required	-2	InternBDB: Sievert 220.101.021
	?	356 241 40	Cable protection hose PG 16 Bulk ware, state length required	-2	InternBDB: 220.101.017
	?	356 249 40	Socket	4	InternBDB: 520.030.016
	?	471 861 99	Cable ca. 3000 lg. Bulk ware, state length required	96	InternBDB: 1 qmm bl.
	?	055 515	Cable ca. 1500 lg. Bulk ware, state length required	1	InternBDB: 2x0,75
	?	055 515	Cable ca. 1700 lg. Bulk ware, state length required	1	InternBDB: 2x0,75
	?	055 515	Cable ca. 1900 lg. Bulk ware, state length required	1	InternBDB: 2x0,75
	?	055 515	Cable ca. 2100 lg. Bulk ware, state length required	1	InternBDB: 2x0,75
	?	055 515	Cable ca. 3700 lg. Bulk ware, state length required	1	InternBDB: 2x0,75
	?	055 515	Cable ca. 3300 lg. Bulk ware, state length required	1	InternBDB: 2x0,75
	?	358 273 40	Series clamping	-2	InternBDB: Sievert 225 2014
	?	358 274 40	Series clamping	-2	InternBDB: 225 5022

Komatsu H135S S/N 61064 parts catalog PDF

CABLES, CAB SUPPORT (116-2145) in H135S S/N 61064. Diagram image and parts list.
