01 |
414 581 40
|
Hydr. motor assy. |
1 |
InternBDB: Hydromatik A2FM56/61W-PAB 03 423 443 AT-Nr. 669 224 73
|
|
|
|
02 |
|
Housing |
1 |
InternBDB: 410 035 | InternKon: 423 443 / 03
|
|
|
|
03 |
319 147 99
|
Bolt |
2 |
InternBDB: M10x25 /912 | InternKon: 423 443 / 07
|
|
|
|
04 |
343 855 99
|
Lock washer |
6 |
InternBDB: 10 /7980 | InternKon: 423 443 / 08
|
|
|
|
05 |
319 431 99
|
Bolt |
4 |
InternBDB: M10x60 /912 | InternKon: 423 443 / 10
|
|
|
|
06 |
771 809 73
|
Connector plate |
1 |
InternBDB: 424 688 | InternKon: 423 443 / 04
|
|
|
|
07 |
971 096
|
O-ring |
1 |
InternBDB: 78,97x3,53 | InternKon: 423 443 / 06
|
|
|
|
08 |
344 777 99
|
Parallel pin |
1 |
InternBDB: 5M6x12 /7 | InternKon: 423 443 / 05
|
|
|
|
09 |
757 167 73
|
Power unit assy.
consist. of fig-no: 10,17-26 |
1 |
InternBDB: 420 323 | InternKon: 423 443 / 01
|
|
|
|
10 |
771 811 73
|
Transmission
consist. of fig-nos: 11-16 |
1 |
InternBDB: 418 924 | InternKon: 420 323 / 01
|
|
|
|
11 |
771 829 73
|
Control plate |
1 |
InternBDB: 409 735 | InternKon: 418 924 / 02
|
|
|
|
12 |
771 830 73
|
Cylinder |
1 |
InternBDB: 421 305 | InternKon: 418 924 / 01
|
|
|
|
13 |
754 467
|
Spring plate |
1 |
InternBDB: 417 558 | InternKon: 418 924 / 06
|
|
|
|
14 |
753 596
|
Cup spring |
4 |
InternBDB: 402 352 | InternKon: 418 924 / 07
|
|
|
|
15 |
753 597
|
Trunnion |
1 |
InternBDB: 409 992 | InternKon: 418 924 / 03
|
|
|
|
16 |
771 815 73
|
Piston |
7 |
InternBDB: 426 817 + 2x 156 245 | InternKon: 418 924 / 04
|
|
|
|
17 |
502 607 98
|
Screw |
7 |
InternBDB: M5x16 /7985 | InternKon: 420 323 / 20
|
|
|
|
18 |
754 469
|
Withdrawal plate |
1 |
InternBDB: 417 825 | InternKon: 420 323 / 07
|
|
|
|
19 |
753 602
|
Disc |
1 |
InternBDB: 409 994 | InternKon: 420 323 / 05
|
|
|
|
20 |
757 168 73
|
Drive shaft with bearing set |
1 |
InternBDB: 270 836 | InternKon: 420 323 / 02
|
|
|
|
21 |
753 607
|
Shim washer 85x105x0,1 |
2 |
InternBDB: 152 831 | InternKon: 420 323 / 17
|
|
|
|
22 |
341 518 99
|
Shim washer 85x105x0,3 |
1 |
InternBDB: 084 592 | InternKon: 420 323 / 18
|
|
|
|
23 |
972 199
|
O-ring |
1 |
InternBDB: 98,02x3,53 | InternKon: 420 323 / 15
|
|
|
|
24 |
975 304
|
Shaft seal |
1 |
InternBDB: 40x55x7-NB 827 SK | InternKon: 420 323 / 14
|
|
|
|
25 |
753 605
|
Cover assy.
with fig-no: 24 |
1 |
InternBDB: 408 442 + 152 916 | InternKon: 420 323 / 04
|
|
|
|
26 |
342 671 99
|
Circlip |
1 |
InternBDB: 105x4 /472 | InternKon: 420 323 / 12
|
|
|
|
|$$27 |
999 064
|
Seal kit
consist. of fig-nos: 07,23,25 |
-2 |
InternBDB: E-ST
|
|
