01 |
456 315 40
|
Suction tank assy. |
1 |
InternKon: 410 878 40 / 8
|
|
|
|
02 |
456 316 40
|
Suction tank |
1 |
InternKon: 456 315 40 / 1
|
|
|
|
03 |
425 344 40
|
Plate |
1 |
InternKon: 456 315 40 / 2
|
|
|
|
04 |
425 343 40
|
Plate |
1 |
InternKon: 456 315 40 / 3
|
|
|
|
05 |
081 496 40
|
Protection cap |
1 |
InternBDB: Techno-Chemie 63-6591-620- 051 | InternKon: 456 315 40 / 4
|
|
|
|
06 |
081 495 40
|
Sleeve |
1 |
InternBDB: 61-6511-620- 022 | InternKon: 456 315 40 / 5
|
|
|
|
07 |
307 821 99
|
Bolt |
6 |
InternBDB: M16x25 /933 | InternKon: 456 315 40 / 6
|
|
|
|
07 |
500 507 98
|
Bolt |
6 |
InternBDB: M16x25 /933 Kaltzдh | InternKon: 456 315 40 / 6
|
|
|
|
08 |
343 817 99
|
Lock washer |
6 |
InternBDB: 16 /127 | InternKon: 456 315 40 / 7
|
|
|
|
09 |
202 967 40
|
Plug |
1 |
InternBDB: Vsti G 3/4 ED | InternKon: 456 315 40 / 8
|
|
|
|
10 |
324 825 40
|
Annular flap with clamping lever |
1 |
InternBDB: CAVO Typ M6001 DN 20 | InternKon: 410 878 40 / 39
|
|
|
|
11 |
319 293 99
|
Bolt |
6 |
InternBDB: M16x100 /912 | InternKon: 410 878 40 / 55
|
|
|
|
11 |
500 656 98
|
Bolt |
6 |
InternBDB: M16x100 /912 Kaltzдh | InternKon: 410 878 40 / 55
|
|
|
|
12 |
345 148 99
|
Dowel pin |
2 |
InternBDB: 16x70 /1481 | InternKon: 410 878 40 / 56
|
|
|
|
13 |
307 750 99
|
Bolt |
2 |
InternBDB: M8x15 /933 | InternKon: 410 878 40 / 81
|
|
|
|
14 |
346 510 99
|
Lock washer |
2 |
InternBDB: 8 /128 | InternKon: 410 878 40 / 82
|
|
|
|
15 |
312 780 99
|
Bolt |
2 |
InternBDB: M16x120 /939 10.9 | InternKon: 410 878 40 / 96
|
|
|
|
15 |
312 779 99
|
Bolt (s/no: 61 021 and
from 61 023) |
2 |
InternBDB: M16x110 /939 8.8 | InternKon: 410 878 40 / 96
|
|
|
|
16 |
332 336 99
|
Nut |
2 |
InternBDB: M 16 /934 | InternKon: 410 878 40 / 97
|
|
|
|
17 |
400 067 40
|
Angle |
1 |
InternKon: 410 878 40 / 91
|
|
|
|
18 |
324 550 40
|
Plug |
1 |
InternBDB: Linc.-Helios 3/4 NPT | InternKon: 456 315 40 / 9
|
|
|
|
19 |
358 657 40
|
Plug |
1 |
InternBDB: 1 NPT | InternKon: 456 315 40 / 10
|
|
