00 |
410 842 40
|
Fuel tank assy. |
1 |
InternKon: 410 878 40 / 6
|
|
|
|
01 |
410 822 40
|
Fuel tank w/o mounting parts |
1 |
InternKon: 410 842 40 / 1
|
|
|
|
02 |
457 068 40
|
Filler cap |
1 |
InternKon: 410 842 40 / 2
|
|
|
|
03 |
457 066 40
|
Seal |
1 |
InternKon: 410 842 40 / 3
|
|
|
|
04 |
307 754 99
|
Bolt |
12 |
InternBDB: M8x25 /933 | InternKon: 410 842 40 / 4
|
|
|
|
05 |
346 510 99
|
Lock washer |
12 |
InternBDB: 8 /128 | InternKon: 410 842 40 / 5
|
|
|
|
06 |
081 067 40
|
Oil-level glass |
1 |
InternBDB: KUHN Gr.10/NR.221/ mit Dichtung | InternKon: 410 842 40 / 6
|
|
|
|
07 |
490 655 40
|
Measuring transducer |
1 |
InternBDB: Philips /P20 940427010031 | InternKon: 410 842 40 / 7
|
|
|
|
08 |
372 833 99
|
Union |
1 |
InternBDB: GAI 15 LR | InternKon: 410 842 40 / 8
|
|
|
|
09 |
372 173 99
|
Union |
1 |
InternBDB: DDL 15 /2353 | InternKon: 410 842 40 / 9
|
|
|
|
10 |
371 783 99
|
Socket |
1 |
InternBDB: EVGE 15-LM-ed
|
|
|
|
11 |
081 495 40
|
Quick disconnect coupling |
1 |
InternBDB: Techno-Chemie 616511620022 | InternKon: 410 842 40 / 11
|
|
|
|
12 |
081 496 40
|
Protection cap |
1 |
InternBDB: 636591620051 | InternKon: 410 842 40 / 14
|
|
|
|
13 |
258 311 40
|
Seal |
1 |
InternKon: 410 842 40 / 15
|
|
|
|
14 |
258 309 40
|
Cover |
1 |
InternKon: 410 842 40 / 16
|
|
|
|
15 |
255 694 40
|
Plug |
1 |
InternBDB: vsti G 3/8 ed | InternKon: 410 842 40 / 17
|
|
|
|
16 |
372 415 99
|
Union |
1 |
InternBDB: ES 25 /2353 | InternKon: 410 842 40 / 12
|
|
|
|
17 |
371 867 99
|
Breech block |
1 |
InternBDB: 25-S | InternKon: 410 842 40 / 13
|
|
|
|
18 |
323 950 40
|
Cable union |
1 |
InternBDB: Sievert 5010.100.009
|
|
|
|
19 |
356 246 40
|
Socket |
1 |
InternBDB: 520.030l.009
|
|
|
|
20 |
356 238 40
|
Cable protection hose
Bulk ware, state length
required |
1 |
InternBDB: Sievert 0220.101.010
|
|
|
|
21 |
057 299 40
|
Plug 3-polig |
1 |
InternBDB: Cannon MS 3106 E 10- S 1-3PF 80
|
|
|
|
22 |
471 164 99
|
Cable
Bulk ware, state length
required |
1 |
InternBDB: NMH-J3x1,5/ 47709
|
|
|
|
23 |
308 321 99
|
Bolt |
8 |
InternBDB: M16x90 /931 | InternKon: 410 878 40 / 51
|
|
|
|
24 |
365 442 40
|
Resilient sleeve |
8 |
InternKon: 410 878 40 / 53
|
|
|
|
25 |
145 766 40
|
Dust cap |
1 |
InternBDB: MS 25042-10C
|
|
|
|
26 |
461 806 40
|
Ball cock |
1 |
InternBDB: Schwietzke DN 12 /PN 32 R 1/2 | InternKon: 410 842 40 / 19
|
|
|
|
27 |
371 928 99
|
Socket |
2 |
InternBDB: evGE 15-PLR ed | InternKon: 410 842 40 / 10
|
|
|
|
28 |
650 800 40
|
Retainer |
1 |
InternKon: 410 842 40 / 18
|
|
|
|
29 |
501 559 98
|
Pair of clamps |
1 |
InternBDB: L-4-R-30 /3015 | InternKon: 410 842 40 / 20
|
|
|
|
30 |
319 417 99
|
Screw |
2 |
InternBDB: M6x35 /912 | InternKon: 410 842 40 / 21
|
|
|
|
31 |
340 405 99
|
Washer |
2 |
InternBDB: 6,4 /433 | InternKon: 410 842 40 / 22
|
|
|
|
32 |
180 113 40
|
Plug |
1 |
InternBDB: Vsti G 1/4 ed | InternKon: 410 842 40 / 23
|
|
