01 |
643 769 40
|
Ladder assy. |
1 |
InternKon: 643 775 40 / 1
|
|
|
|
02 |
643 794 40
|
Ladder |
1 |
InternKon: 643 769 40 / 1
|
|
|
|
03 |
606 660 40
|
Guide |
1 |
InternKon: 643 769 40 / 2
|
|
|
|
04 |
463 274 40
|
Counterweight, fig-nos. 30-37 |
2 |
InternKon: 643 769 40 / 3
|
|
|
|
05 |
606 661 40
|
Sheave |
4 |
InternKon: 643 769 40 / 4
|
|
|
|
06 |
400 158 40
|
Plate |
2 |
InternKon: 643 769 40 / 5
|
|
|
|
07 |
621 085 40
|
Pin |
6 |
InternKon: 643 769 40 / 6
|
|
|
|
08 |
621 592 40
|
Bushing |
6 |
InternKon: 643 769 40 / 7
|
|
|
|
09 |
400 166 40
|
End disc |
6 |
InternKon: 643 769 40 / 8
|
|
|
|
10 |
400 169 40
|
Roller |
6 |
InternKon: 643 769 40 / 9
|
|
|
|
11 |
343 854 99
|
Lock washer |
12 |
InternBDB: 8 /7980 | InternKon: 643 769 40 / 16
|
|
|
|
12 |
320 332 99
|
Screw |
12 |
InternBDB: M8x20 /6912 | InternKon: 643 769 40 / 21
|
|
|
|
13 |
513 418 98
|
Supporting disc |
2 |
InternBDB: S 30x42x2 /988 | InternKon: 643 769 40 / 11
|
|
|
|
14 |
342 530 99
|
Circlip |
2 |
InternBDB: 30x1,5 /471 | InternKon: 643 769 40 / 12
|
|
|
|
15 |
501 046 98
|
Bolt |
2 |
InternBDB: M10x200 /912 | InternKon: 643 769 40 / 13
|
|
|
|
16 |
332 114 99
|
Nut |
4 |
InternBDB: M 10 /934 | InternKon: 643 769 40 / 14
|
|
|
|
17 |
505 251 98
|
Compression spring |
2 |
InternBDB: 5x32x75 /2098 | InternKon: 643 769 40 / 15
|
|
|
|
18 |
419 984 40
|
Sleeve |
2 |
InternKon: 643 769 40 / 26
|
|
|
|
19 |
419 983 40
|
Buffer |
2 |
InternKon: 643 769 40 / 27
|
|
|
|
20 |
300 024 99
|
Cable clamp |
15 |
InternBDB: 5 /741 | InternKon: 643 769 40 / 18
|
|
|
|
21 |
501 354 98
|
Rope
Bulk ware, state length
required |
-2 |
InternBDB: 5 /3060 | InternKon: 19 / 24
|
|
|
|
22 |
400 181 40
|
Angle |
2 |
InternKon: 643 769 40 / 20
|
|
|
|
23 |
400 164 40
|
Plate |
2 |
InternKon: 643 769 40 / 17
|
|
|
|
24 |
307 806 99
|
Bolt |
8 |
InternBDB: M12x40 /933 | InternKon: 643 769 40 / 23
|
|
|
|
25 |
332 334 99
|
Nut |
16 |
InternBDB: M 12 /934 | InternKon: 643 769 40 / 22
|
|
|
|
26 |
472 687 99
|
Chain
Bulk ware, state length
required |
-2 |
InternBDB: 1,6 /5686 | InternKon: 643 769 40 / 28
|
|
|
|
27 |
643 787 40
|
Lever |
1 |
InternKon: 643 769 40 / 25
|
|
|
|
28 |
472 508 99
|
Chain
Bulk ware, state length
required |
-2 |
InternBDB: 2-8x24 /32891 | InternKon: 643 769 40 / 29
|
|
|
|
29 |
497 594 40
|
Round piece |
1 |
InternKon: 643 769 40 / 30
|
|
|
|
30 |
463 275 40
|
Plate |
1 |
InternKon: 463 274 40 / 1
|
|
|
|
31 |
400 174 40
|
Plate |
1 |
InternKon: 463 274 40 / 2
|
|
|
|
32 |
405 689 40
|
Square |
2 |
InternKon: 463 274 40 / 8
|
|
|
|
33 |
400 175 40
|
Plastic slider |
12 |
InternKon: 463 274 40 / 3
|
|
|
|
34 |
308 640 99
|
Bolt |
2 |
InternBDB: M16x120 /931 | InternKon: 463 274 40 / 4
|
|
|
|
35 |
346 502 99
|
Lock washer |
2 |
InternBDB: 16 /128 | InternKon: 463 274 40 / 5
|
|
|
|
36 |
313 502 99
|
Eyebolt |
1 |
InternBDB: M 12 /580 | InternKon: 463 274 40 / 6
|
|
|
|
37 |
346 498 99
|
Lock washer |
1 |
InternBDB: 12 /128 | InternKon: 463 274 40 / 7
|
|
|
|
38 |
643 782 40
|
Lock |
1 |
InternKon: 606 660 40 / 24
|
|
|
|
39 |
643 784 40
|
Locking lever |
1 |
InternKon: 643 782 40 / 1
|
|
|
|
40 |
421 102 40
|
Pin |
1 |
InternKon: 643 782 40 / 2
|
|
|
|
41 |
081 410 40
|
Conical handle |
1 |
InternKon: 643 782 40 / 3
|
|
|
|
42 |
515 736 40
|
Switch |
1 |
InternBDB: IFM IC 5006 ICE 3040-FNKG | InternKon: 630 175 40 / 106
|
|
|
|
43 |
661 670 40
|
Hinge |
2 |
InternKon: 606 660 40 / 21
|
|
|
|
44 |
606 662 40
|
Bushing |
2 |
InternKon: 643 769 40 / 31
|
|
|
|
45 |
308 427 99
|
Bolt |
2 |
InternBDB: M16x75 /931 10.9 | InternKon: 643 769 40 / 32
|
|
|
|
46 |
334 601 99
|
Nut |
2 |
InternBDB: M 16 /985 | InternKon: 643 769 40 / 33
|
|
|
|
47 |
340 469 99
|
Washer |
4 |
InternBDB: 17 /125 | InternKon: 643 769 40 / 34
|
|
|
|
48 |
350 562 99
|
Grease nipple |
6 |
InternBDB: AM 10x1 /71412 | InternKon: 643 769 40 / 35
|
|
