01 |
914 998 40
|
Wall |
1 |
InternKon: 918 800 40 / 1
|
|
|
|
03 |
675 598 40
|
Wall |
4 |
InternKon: 918 800 40 / 2
|
|
|
|
04 |
661 606 40
|
Plate |
2 |
InternKon: 918 800 40 / 3
|
|
|
|
05 |
661 607 40
|
Profiled joint |
2 |
InternBDB: Z 125 10x100x1340 | InternKon: 918 800 40 / 8
|
|
|
|
06 |
308 424 99
|
Bolt |
8 |
InternBDB: M16x110 | InternKon: 918 800 40 / 5
|
|
|
|
07 |
308 321 99
|
Bolt |
8 |
InternBDB: M16x90 | InternKon: 918 800 40 / 6
|
|
|
|
08 |
332 355 99
|
Nut |
8 |
InternBDB: M 16 | InternKon: 918 800 40 / 7
|
|
|
|
09 |
510 733 98
|
Resilient sleeve |
16 |
InternKon: 918 800 40 / 4
|
|
|
|
15 |
928 775 40
|
Modification Machinery House consist of fig. nos. 21-38 |
1 |
|
|
|
|
20 |
928 732 40
|
Door Assy consist of fig. nos. 21-29 |
1 |
InternBDB: PC 5500-6 | InternKon: 928 775 40 / 1
|
|
|
|
21 |
928 733 40
|
Door |
1 |
InternBDB: SK | InternKon: 928 732 40 / 1
|
|
|
|
22 |
323 635 40
|
Edge |
1 |
InternBDB: 7-113 ohne Spezialnuss Wss-1011 | InternKon: 928 732 40 / 2
|
|
|
|
23 |
323 661 40
|
Handle |
1 |
InternBDB: 13-228 | InternKon: 928 732 40 / 3
|
|
|
|
24 |
321 009 99
|
Srew |
4 |
InternBDB: M5x16 / 4.8 / DIN 84 | InternKon: 928 732 40 / 4
|
|
|
|
25 |
346 509 99
|
Lock washer |
4 |
InternBDB: A 5 DIN 128 | InternKon: 928 732 40 / 5
|
|
|
|
26 |
318 576 99
|
Srew |
4 |
InternBDB: M5x10 / 4,8 / DIN 964 | InternKon: 928 732 40 / 6
|
|
|
|
27 |
928 738 40
|
Fixing rod |
2 |
InternBDB: ST50-2K 655 | InternKon: 928 732 40 / 7
|
|
|
|
28 |
928 729 40
|
Plate |
2 |
InternBDB: 8x24x24 ST52-3N | InternKon: 928 732 40 / 8
|
|
|
|
29 |
332 114 99
|
Nut |
2 |
InternBDB: M10 DIN 934 | InternKon: 928 732 40 / 9
|
|
|
|
30 |
928 740 40
|
Door |
1 |
InternBDB: PC 5500-6 | InternKon: 928 775 40 / 2
|
|
|
|
31 |
928 744 40
|
Door catch |
1 |
InternBDB: PC 5500-6 | InternKon: 928 775 40 / 3
|
|
|
|
32 |
928 774 40
|
Strip |
1 |
InternKon: 928 775 40 / 4
|
|
|
|
33 |
621 983 40
|
Band roller with grease nippel |
4 |
InternBDB: 1033 U7/20K 100 mm | InternKon: 928 775 40 / 5
|
|
|
|
34 |
928 749 40
|
Plate |
1 |
InternBDB: 8x24x24 | InternKon: 928 775 40 / 6
|
|
|
|
35 |
928 748 40
|
Angle |
2 |
InternBDB: 50x5x40 | InternKon: 928 775 40 / 7
|
|
|
|
36 |
308 608 99
|
Srew |
2 |
InternBDB: M12x70 8.8 / DIN 931
|
|
|
|
37 |
512 958 98
|
Resilent Sleeve |
2 |
InternBDB: 13 / 25x45
|
|
|
|
38 |
332 334 99
|
Nut |
2 |
InternBDB: M12 / DIN 934
|
|
|
|
50 |
324 576 40
|
Handle |
1 |
InternBDB: Happich 580 0176 | InternKon: 928 732 40 / 10
|
|
|
|
|$$30 |
256 952 40
|
Adhesive 0,2 Kg |
-2 |
|
|
