|$$1 |
635 090 40
|
Pump distributor gear assy. |
1 |
InternBDB: L & S GFC 395 1001 AT-Nr. 710 601 73
|
|
|
|
01 |
763 806 73
|
Housing |
1 |
InternBDB: 0/0125/9434/1
|
|
|
|
02 |
806 759 73
|
Joint shaft flange |
1 |
InternBDB: 2/0231/9042/0
|
|
|
|
03 |
763 807 73
|
Drive gear |
1 |
InternBDB: 2/0306/9050/0
|
|
|
|
04 |
763 800 73
|
Spur gear |
3 |
InternBDB: 1/0306/9051/0
|
|
|
|
05 |
763 801 73
|
Spur gear |
1 |
InternBDB: 2/0306/9053/1
|
|
|
|
06 |
763 802 73
|
Spur gear |
1 |
InternBDB: 2/0306/9052/1
|
|
|
|
09 |
806 760 73
|
Intermediate ring |
1 |
InternBDB: 4/0403/9338/1
|
|
|
|
11 |
806 974 73
|
Retainer |
1 |
InternBDB: 4/0408/9855/0
|
|
|
|
12 |
763 772 73
|
Bearing cap |
1 |
InternBDB: 1/0582/9094/2
|
|
|
|
13 |
805 529 73
|
Cover |
2 |
InternBDB: 4/0438/9518/1
|
|
|
|
15 |
763 775 73
|
Flange |
3 |
InternBDB: 1/0582/9093/3
|
|
|
|
16 |
806 977 73
|
Flange |
1 |
InternBDB: 1/0582/9102/2
|
|
|
|
17 |
763 804 73
|
Flange |
1 |
InternBDB: 1/0582/9063/3
|
|
|
|
20 |
806 230 73
|
Cover |
1 |
InternBDB: 2/0438/9538/2
|
|
|
|
22 |
806 232 73
|
Meter unit |
1 |
InternBDB: 3/0940/9151/0
|
|
|
|
23 |
806 233 73
|
Seal |
1 |
InternBDB: NW 10 ND 16 468 040
|
|
|
|
24 |
806 546 73
|
Oil dipstick |
1 |
InternBDB: R 1/2" x 265 432 153
|
|
|
|
26 |
513 595 98
|
Roller bearing |
6 |
InternBDB: 6222 J /C3 /625 410 376
|
|
|
|
28 |
368 218 99
|
Roller bearing |
4 |
InternBDB: 6216 J /C3 /625 410 201
|
|
|
|
29 |
360 626 99
|
Roller bearing |
1 |
InternBDB: 6326 M /C3 /625 306 651
|
|
|
|
30 |
508 999 98
|
Cylindrical roller bearing |
1 |
InternBDB: NJ 2220 EM /5412 411 318
|
|
|
|
33 |
367 090 99
|
Radial seal |
2 |
InternBDB: 160x190x15 A /3760 461 417
|
|
|
|
35 |
086 388
|
Radial seal |
6 |
InternBDB: 80x100x10 C /3760 461 362
|
|
|
|
36 |
367 058 99
|
Radial seal |
6 |
InternBDB: 110x140x12 A /3760 461 383
|
|
|
|
37 |
172 570 40
|
O-ring |
3 |
InternBDB: 315x5 /3771 463 300
|
|
|
|
38 |
513 592 98
|
O-ring |
3 |
InternBDB: 450x4 463 600
|
|
|
|
39 |
504 588 98
|
O-ring |
1 |
InternBDB: 410x4 /3771 463 312
|
|
|
|
40 |
971 177
|
O-ring |
2 |
InternBDB: 140x3 /3771 463 234
|
|
|
|
41 |
500 388 98
|
O-ring |
1 |
InternBDB: 440x4 /3771 463 315
|
|
|
|
42 |
504 595 98
|
O-ring |
1 |
InternBDB: 330x4 /3771 463 301
|
|
|
|
43 |
006 657 98
|
O-ring |
2 |
InternBDB: 125x3 /3771 463 201
|
|
|
|
44 |
082 821
|
O-ring |
2 |
InternBDB: 80x3 /3771 463 159
|
|
|
|
45 |
319 157 99
|
Bolt |
4 |
InternBDB: M12x35 /912
|
|
|
|
46 |
308 666 99
|
Bolt |
24 |
InternBDB: M20x70 441 370
|
|
|
|
47 |
307 825 99
|
Bolt |
8 |
InternBDB: M16x45 441 276
|
|
|
|
48 |
307 825 99
|
Bolt |
8 |
InternBDB: M16x45 441 276
|
|
|
|
49 |
307 781 99
|
Bolt |
8 |
InternBDB: M10x40
|
|
|
|
50 |
307 802 99
|
Bolt |
4 |
InternBDB: M12x35 441 194
|
|
|
|
51 |
307 822 99
|
Bolt |
2 |
InternBDB: M16x30 441 273
|
|
|
|
52 |
313 395 99
|
Plug |
20 |
InternBDB: M12x1,5 /908 444 170
|
|
|
|
53 |
511 498 98
|
Plug |
1 |
InternBDB: M30x2 /910 444 241
|
|
|
|
54 |
331 322 99
|
Plug |
1 |
InternBDB: G 1/2 /910 444 203
|
|
|
|
55 |
508 923 98
|
Plug |
1 |
InternBDB: G 3/4 - NPT /906 444 150
|
|
|
|
56 |
313 122 99
|
Plug |
1 |
InternBDB: M22x1,5 /910 444 186
|
|
|
|
57 |
313 126 99
|
Plug |
2 |
InternBDB: M48x2 /910 444 195
|
|
|
|
58 |
339 879 99
|
Seal ring |
20 |
InternBDB: A 12x18x1,5 /7603 462 046
|
|
|
|
59 |
339 907 99
|
Seal ring |
2 |
InternBDB: A 22x27x1,5 /7603 462 045
|
|
|
|
60 |
339 967 99
|
Seal ring |
2 |
InternBDB: A 48x55x2 /7603 462 058
|
|
|
|
61 |
340 103 99
|
Seal ring |
1 |
InternBDB: A 30x36x2 /7603 462 055
|
|
|
|
62 |
763 782 73
|
Tube pole cap |
3 |
InternBDB: VK 90x12 306 569
|
|
|
|
63 |
806 259 73
|
Tube pole cap |
1 |
InternBDB: VK 52x10 451 261
|
|
|
|
66 |
342 707 99
|
Circlip |
1 |
InternBDB: 280x5 /472 452 355
|
|
|
|
67 |
313 199 99
|
Plug |
8 |
InternBDB: G 1/4 /910 444 201
|
|
|
|
68 |
340 275 99
|
Seal ring |
8 |
InternBDB: A 14x18x1,5 /7603 462 043
|
|
|
|
69 |
372 732 99
|
Union |
3 |
InternBDB: WE 8-PLM 437 134
|
|
|
|
71 |
763 762 73
|
Union |
5 |
InternBDB: WE 10-PLR 437 157
|
|
|
|
72 |
370 312 99
|
Union |
1 |
InternBDB: GE 10-PLR 437 212
|
|
|
|
78 |
214 768 99
|
Precision tubing Ш 10x1,5 |
-2 |
InternBDB: 10x1,5 /2391 062 017
|
|
|
|
79 |
215 037 99
|
Precision tubing Ш 28x2 |
-2 |
InternBDB: 28x2 /2391 062 115
|
|
|
|
80 |
215 218 99
|
Precision tubing |
-2 |
InternBDB: 18x1,5 /2391 062 063
|
|
|
|
81 |
806 236 73
|
Pipe |
3 |
InternBDB: 4/0995/9091/0
|
|
|
|
87 |
763 767 73
|
Spray pipe |
1 |
InternBDB: 3/0940/9167/0
|
|
|
|
87 |
763 768 73
|
Union |
1 |
InternBDB: RI 1/2"x1/4" 436 265
|
|
|
|
87 |
513 589 98
|
Sealing washer |
1 |
InternBDB: 12 /470 451 208
|
|
|
|
88 |
763 769 73
|
Spray pipe |
1 |
InternBDB: 3/0940/9168/0
|
|
|
|
88 |
763 768 73
|
Union |
1 |
InternBDB: RI 1/2"x1/4" 436 265
|
|
|
|
88 |
513 589 98
|
Sealing washer |
1 |
InternBDB: 12/470 451 208
|
|
|
|
99 |
308 604 99
|
Bolt |
4 |
InternBDB: M12x50 441 199
|
|
|
|
100 |
340 002 99
|
Seal ring |
1 |
InternBDB: A27x32x2 /7603 462 047
|
|
|
|
102 |
806 276 73
|
Union |
2 |
InternBDB: EVT 28-PLR 437 320
|
|
|
|
103 |
763 785 73
|
Union |
1 |
InternBDB: EVW 28-PLR 437 326
|
|
|
|
110 |
313 316 99
|
Plug |
1 |
InternBDB: M33x2 /910 444 194
|
|
|
|
111 |
340 323 99
|
Seal ring |
1 |
InternBDB: A 33x39x2 /7603 462 056
|
|
|
|
115 |
806 278 73
|
Expansion tank |
1 |
InternBDB: 4/0023/7816/2
|
|
|
|
116 |
806 978 73
|
Breather with dipstick |
1 |
InternBDB: 4/0950/9097/0
|
|
|
|
118 |
372 035 99
|
Union |
1 |
InternBDB: EVL 18-PLR 437 321
|
|
|
|
119 |
763 786 73
|
Union |
1 |
InternBDB: EVW 18-PLR 437 530
|
|
|
|
120 |
372 760 99
|
Union |
2 |
InternBDB: WE 18-PLR 437 161
|
|
|
|
121 |
372 615 99
|
Union |
1 |
InternBDB: T 18-PL 437 274
|
|
|
|
123 |
763 773 73
|
Intermediate ring |
1 |
InternBDB: 4/0403/9343/0
|
|
|
|
124 |
512 711 98
|
O-ring |
1 |
InternBDB: 130x4 /3771 463 214
|
|
|
|
125 |
763 787 73
|
Plug |
3 |
InternBDB: GPN 600 B 3110 469 054
|
|
|
|
126 |
806 244 73
|
Plug |
2 |
InternBDB: GPN 600 B 1390 469 045
|
|
|
|
130 |
307 805 99
|
Bolt |
4 |
InternBDB: M12x35 441 196
|
|
|
|
131 |
763 805 73
|
Cover |
1 |
InternBDB: 2/0438/9668/0
|
|
|
|
|$$87 |
|
Bulk ware, state length required |
-2 |
|
|
