490 772 40
|
Radiator |
1 |
InternBDB: Mesabi 60710
|
|
|
|
? |
768 313 73
|
Tank top |
1 |
InternBDB: 91798 | InternKon: H 455 S / 1
|
|
|
|
? |
768 314 73
|
Tank center |
1 |
InternBDB: 91802 | InternKon: H 455 S / 3
|
|
|
|
? |
768 315 73
|
Tank bottom |
1 |
InternBDB: 91799 | InternKon: H 455 S / 2
|
|
|
|
? |
768 316 73
|
SurgeTank |
1 |
InternBDB: 91797 | InternKon: H 455 S / 6
|
|
|
|
? |
768 317 73
|
Radiator frame |
1 |
InternBDB: 91801 | InternKon: H 455 S / 4
|
|
|
|
? |
768 318 73
|
Radiator frame |
1 |
InternBDB: 91801.99 | InternKon: H 455 S / 5
|
|
|
|
? |
768 319 73
|
Cooling tube |
168 |
InternBDB: 26.10.3625 | InternKon: H 455 S / 8
|
|
|
|
? |
768 320 73
|
Air baffle top |
2 |
InternBDB: 33082.61 | InternKon: H 455 S / 11
|
|
|
|
? |
768 321 73
|
Air baffle bottom |
2 |
InternBDB: 33083.61 | InternKon: H 455 S / 12
|
|
|
|
? |
780 314 73
|
Rubber Seal |
532 |
InternBDB: 35780 | InternKon: H 455 S / 9
|
|
|
|
? |
764 494 73
|
Rubber Seal |
532 |
InternBDB: 87530 | InternKon: H 455 S / 10
|
|
|
|
? |
764 499 73
|
Support |
12 |
InternBDB: 39300 | InternKon: H 455 S / 13
|
|
|
|
? |
768 322 73
|
Bolt |
18 |
InternBDB: 33056.04 1/2-13 UNC x 1 | InternKon: H 455 S / 14
|
|
|
|
? |
346 501 99
|
Lock washer |
20 |
InternBDB: 33068.13 14 /128 | InternKon: H 455 S / 15
|
|
|
|
? |
768 323 73
|
Plug |
1 |
InternBDB: 33538.02 1/4 N.P.T | InternKon: H 455 S / 16
|
|
|
|
? |
340 467 99
|
Washer |
6 |
InternBDB: 33069.09 13 /125 | InternKon: H 455 S / 17
|
|
|
|
? |
768 324 73
|
Hose |
1 |
InternBDB: 34987.40 | InternKon: H 455 S / 18
|
|
|
|
? |
768 325 73
|
Hose |
2 |
InternBDB: 73340.08 | InternKon: H 455 S / 21
|
|
|
|
? |
768 326 73
|
Hose clip |
3 |
InternBDB: 48063 Ш 1/2" | InternKon: H 455 S / 19
|
|
|
|
? |
768 327 73
|
Union |
4 |
InternBDB: 34167.03 | InternKon: H 455 S / 20
|
|
|
|
? |
761 086 73
|
Cap |
1 |
InternBDB: 33016.04 | InternKon: H 455 S / 22
|
|
|
|
? |
763 832 73
|
Connector |
4 |
InternBDB: 33429.01 | InternKon: H 455 S / 23
|
|
|
|
? |
005 834 98
|
Bolt |
6 |
InternBDB: 33056.05 1/2-13 UNC x 1 1/4 | InternKon: H 455 S / 25
|
|
|
|
? |
768 328 73
|
Tube Assembly |
364 |
InternBDB: 26.10.3625.01 | InternKon: H 455 S / 7
|
|
|
|
? |
768 332 73
|
Bracket |
2 |
InternBDB: 91869 | InternKon: H 455 S / 24
|
|
