00 |
561 890 40
|
Fuel tank assy. |
1 |
InternBDB: DKG | InternKon: 653 660 40 / 5
|
|
|
|
01 |
561 886 40
|
Fuel tank |
1 |
InternKon: 561 890 40 / 1
|
|
|
|
02 |
636 870 40
|
Cover with filler cap |
1 |
InternKon: 561 890 40 / 2
|
|
|
|
03 |
208 910 40
|
Filler cap lockable |
2 |
InternKon: 636 870 40 / 3
|
|
|
|
04 |
307 752 99
|
Bolt |
8 |
InternBDB: M8x20 8.8 /933 | InternKon: 561 890 40 / 12
|
|
|
|
05 |
346 510 99
|
Washer |
15 |
InternBDB: Ш 8 /128 | InternKon: 561 890 40 / 13
|
|
|
|
06 |
561 892 40
|
Gasket |
1 |
InternKon: 561 890 40 / 3
|
|
|
|
07 |
173 495 40
|
Plug |
2 |
InternBDB: M48x2,0ED /WN34191340 | InternKon: 561 890 40 / 14
|
|
|
|
08 |
324 741 40
|
Plug |
3 |
InternBDB: F 26 P\PPELMANN | InternKon: 561 890 40 / 17
|
|
|
|
09 |
592 266 40
|
Ball cock |
2 |
InternBDB: BKH 28-L 25 11 13 Pister | InternKon: 561 890 40 / 16
|
|
|
|
10 |
371 941 99
|
Socket |
2 |
InternBDB: EVGE 28 LM-ED / 011 788 99 | InternKon: 561 890 40 / 15
|
|
|
|
11 |
340 086 99
|
Gasket |
1 |
InternBDB: A30x38 /7603 | InternKon: 561 890 40 / 18
|
|
|
|
12 |
081 495 40
|
Coupling sleeve DN 20 |
1 |
InternBDB: TCH 61 6511 620 022 | InternKon: 561 890 40 / 4
|
|
|
|
13 |
081 496 40
|
Protection cap |
1 |
InternBDB: TCH 63 6591 620 051 | InternKon: 561 890 40 / 5
|
|
|
|
14 |
372 803 99
|
Union |
1 |
InternBDB: UL 15 /2353 | InternKon: 561 890 40 / 7
|
|
|
|
15 |
371 928 99
|
Socket |
1 |
InternBDB: EVGE15-PLR-ED / 011 575 99 | InternKon: 561 890 40 / 8
|
|
|
|
16 |
461 806 40
|
Ball cock |
1 |
InternBDB: DN15 PN32 R1/2ML BOEHMER | InternKon: 561 890 40 / 9
|
|
|
|
17 |
339 998 99
|
Seal |
1 |
InternBDB: A21x26 / 7603 | InternKon: 561 890 40 / 10
|
|
|
|
18 |
896 583 40
|
Measuring transformer |
1 |
InternBDB: DMP 331 | InternKon: 561 890 40 / 11
|
|
|
|
19 |
650 800 40
|
Pipe mounting |
1 |
InternBDB: 20x3x35 /2391 | InternKon: 561 890 40 / 22
|
|
|
|
20 |
504 901 98
|
Half clamp |
2 |
InternBDB: L-4-G-30 /3015 | InternKon: 561 890 40 / 19
|
|
|
|
21 |
501 584 98
|
Plate |
1 |
InternBDB: L-AP-K-4 /3015 | InternKon: 561 890 40 / 20
|
|
|
|
22 |
319 417 99
|
Bolt |
2 |
InternBDB: M6x35 8.8 /912 | InternKon: 561 890 40 / 21
|
|
|
|
23 |
511 761 98
|
Bolt Cold weather design |
4 |
InternBDB: M30x240 /931 | InternKon: 872 255 40 / 20
|
|
|
|
24 |
511 747 98
|
Bolt Cold weather design |
4 |
InternBDB: M30x160 /931 | InternKon: 872 255 40 / 19
|
|
|
|
25 |
255 057 40
|
Washer |
8 |
InternBDB: 31 | InternKon: 872 255 40 / 25
|
|
|
|
29 |
258 309 40
|
Cover |
1 |
InternBDB: 160x160 | InternKon: 561 890 40 / 23
|
|
|
|
30 |
258 311 40
|
Seal |
1 |
InternBDB: 160 / 115x2 Klinger SIL C-4400 | InternKon: 561 890 40 / 24
|
|
|
|
31 |
307 754 99
|
Bolt |
6 |
InternBDB: M8x25 8.8 /933 | InternKon: 561 890 40 / 25
|
|
|
|
32 |
180 477 40
|
Plug |
2 |
InternBDB: VSTI R 1/2 ED /341 913 40 | InternKon: 561 890 40 / 26
|
|
|
|
35 |
674 980 40
|
Cover with breather part |
1 |
InternKon: 561 890 40 / 2
|
|
|
|
36 |
551 704 40
|
Breather part |
1 |
InternKon: 674 980 40 / 2
|
|
