1
PB9828
SCREW, FLAT HEAD - #10 - 32NF X 7/8"
8
2
EL4154
PLATE, BENT (D.I.D. PANEL MOUNTING)
1
3
SM4275
PLATE, SIDE - L.H.
1
4
PB9829
SCREW, PANEL - M6 X 1.00 X 16
10
5
SM4274
PLATE, SIDE - R.H.
1
6
WB3093
CLAMP, CUSHIONED - 1"
3
7
WA4513
SCREW, SELF-TAPPING - #10 - 24NC X 1/2"
3
8
DF3445
FLAT WASHER - #12
3
9
EL2222
HARNESS, ENGINE/CAB DIAGNOSTIC
1
10
EL5428
PLATE, COVER
1
11
WB3098
CLAMP, CUSHIONED - 3/8"
1
12
PB8334
CLAMP, STRAIN RELIEF
5
13
VP3271
GROMMET
1
14
TC1231
LOCKWASHER - 3/8"
6
15
VC8762
CAPSCREW - 3/8" - 16NC X 1 1/2"
6
16
TR4436
FLAT WASHER - 3/8"
6
17
SM5049
NUT, SPRING - 3/8" - 16NC
6
18
PB9785
PANEL, DIAGNOSTIC INFORMATION DISPLAY (D.I.D.)
1
19
EL2941
PLATE, FLOOR COVER
1
20
MM0593
CAPSCREW - M8 X 1.25 X 20
4
21
01643-30823
FLAT WASHER - M8 (HARDENED)
4
22
WB3120
NAME PLATE - VHMS DIAG 6
1
23
WB3117
NAME PLATE - INTERFACE DIAG 5
1
24
WB3118
NAME PLATE - PAYLOAD DIAG 7
1
25
WB3115
NAME PLATE - ENGINE DIAG 4
1
26
WB3114
NAME PLATE - ENGINE DIAG 2
1
27
EL4141
PLATE, DIAGNOSTIC
1
28
MM0376
LOCKWASHER - M3 (EXTERNAL TOOTH)
8
29
MM0370
NUT - M3
8
30
MM0331
MACHINE SCREW - M3 X 0.5 X 20
8
31
WB3116
NAME PLATE - DRIVE SYSTEM DIAG 1
1
32
WB3119
NAME PLATE - DRIVE SYSTEM DIAG 3
1
33
PB8256
SCREW LOCK, FEMALE
5
34
WB3314
NAME PLATE - GE/MM DIAG8
1
