1
WB3298
NAME PLATE - GROUND LEVEL POWER RELAY
1
2
MM0352
MACHINE SCREW - M5 X .8 X 25
24
3
MM0373
NUT - M5 X 0.8
24
4
MM0459
FLAT WASHER - M6
30
5
MM0379
LOCKWASHER - M5 (EXTERNAL TOOTH)
30
6
EH7285
RESISTOR
1
7
EH7284
RESISTOR/CAPACITOR
1
8
EH3010
NAME PLATE - PVM
1
9
PB7276
RELAY - 24V, 50 AMP
4
10
EK7545
HARNESS, AUXILIARY BOX/ENGINE INTERFACE
1
11
PC0606
ENGINE ECM MODULE
1
12
WB2835
NAME PLATE - KEY SWITCH POWER RELAY
1
13
EM1463
HARNESS, AUXILIARY CONTROL CABINET INTERNAL
1
13
EF6927
RESISTOR (22,100 OHM)
1
14
EK0744
DIODE, 40 AMP
2
15
EK7515
BRACKET, INSULATED
1
16
TR6643
NUT - 1/2" - 13NC
2
17
TR5445
LOCKWASHER - 1/2"
2
18
MM0176
NUT - M6 X 1.00
6
19
MM0469
LOCKWASHER - M6
6
20
EK7516
BUS BAR
1
21
MM0025
CAPSCREW - M6 X 1.00 X 20
6
22
EC8825
NAME PLATE - DB1
1
23
EC8824
NAME PLATE - RB6
1
24
WB2280
NAME PLATE - RB7
1
25
WB3237
NAME PLATE - RB9
1
26
TD0791
CAPSCREW - 3/8" - 16NC X 1 1/4"
2
27
EK4993
DIODE BOARD ASSEMBLY - DB1 (SEE FIG 55613)
1
55613
28
EK4991
RELAY BOARD ASSEMBLY - RB6 (SEE FIG 55613)
4
55613
29
PC1207
TIMER, AUTO LUBE
1
30
78619-25330
SENSOR, ANGLE
1
31
TG5720
CAPSCREW - 3/8" - 16NC X 1"
3
32
TR9008
JAM NUT - 3/8" - 16NC
3
33
TC1231
LOCKWASHER - 3/8"
5
34
TR4436
FLAT WASHER - 3/8"
5
35
WB2733
NAME PLATE - RB8
1
36
EL7628
NAME PLATE - INCLINOMETER
1
37
WB2836
NAME PLATE - 12V POWER RELAY
1
38
WB2289
NAME PLATE - CONTROL POWER RELAY
1
39
WB2281
NAME PLATE - LUBE TIMER
1
40
EG8333
RESISTOR - 20 OHM
1
41
SM3124
DIODE
1
42
EG0664
RESISTOR - 270 OHM
1
43
EH7286
RESISTOR
1
44
TC1233
NUT - 3/8" - 16NC
2
45
EL7629
NAME PLATE - GB32
1
46
ED0913
ROD, THREADED - 1/4"
4
47
TD1549
NUT - 1/4" - 20NC
4
48
DC3584
LOCKWASHER - 1/4"
8
49
TR1307
FLAT WASHER - 1/4"
8
50
MM0019
CAPSCREW - M6 X 1.00 X 16
4
