01 |
931 620 40
|
Boom assy. |
1 |
InternBDB: SK 929 795 40 | InternKon: KO-LISTE / 1
|
|
|
|
04 |
911 801 40
|
Pin with plate (Standard) |
1 |
InternBDB: 250x1870 | InternKon: 931 620 40 / 2
|
|
|
|
04 |
938 698 40
|
Pin with plate (Cold weather design) |
1 |
InternBDB: 945 481 40 Pos 2 / 250x1870 | InternKon: 931 620 40 / 2
|
|
|
|
05 |
911 806 40
|
Pin with plate (Standard) |
2 |
InternBDB: 150x532 | InternKon: 931 620 40 / 3
|
|
|
|
05 |
942 600 40
|
Pin with plate (Cold weather design) |
2 |
InternBDB: 945 481 40 Pos 3 / 150x532 | InternKon: 931 620 40 / 3
|
|
|
|
06 |
911 804 40
|
Pin with plate (Standard) |
2 |
InternBDB: 170x422 | InternKon: 931 620 40 / 4
|
|
|
|
06 |
942 602 40
|
Pin with plate (Cold weather design) |
2 |
InternBDB: 945 481 40 Pos 4 / 170x422 | InternKon: 931 620 40 / 4
|
|
|
|
07 |
636 151 40
|
Bushing |
4 |
InternKon: 931 620 40 / 5
|
|
|
|
08 |
907 022 40
|
Seal ring |
4 |
InternKon: 931 620 40 / 6
|
|
|
|
09 |
905 206 40
|
Cap |
1 |
InternKon: 931 620 40 / 7
|
|
|
|
10 |
332 361 99
|
Nut |
1 |
InternBDB: M 30 /934 | InternKon: 931 620 40 / 16
|
|
|
|
11 |
500 117 98
|
O-ring |
1 |
InternBDB: 336,0x7,0 NB90 | InternKon: 931 620 40 / 12
|
|
|
|
12 |
925 982 40
|
Stop |
4 |
InternKon: 931 620 40 / 9
|
|
|
|
13 |
004 860 98
|
Grease nipple |
1 |
InternKon: 931 620 40 / 13
|
|
|
|
14 |
517 123 98
|
Lock washer |
33 |
InternBDB: 16 WN 65593840 | InternKon: 931 620 40 / 15
|
|
|
|
15 |
926 840 40
|
Twist lock - cap |
1 |
InternKon: 931 620 40 / 8
|
|
|
|
16 |
911 834 40
|
Shackle |
2 |
InternKon: 931 620 40 / 18
|
|
|
|
17 |
933 003 40
|
Mainfold |
1 |
InternKon: 931 620 40 / 23
|
|
|
|
18 |
911 825 40
|
Carrier |
1 |
InternKon: 931 620 40 / 25
|
|
|
|
19 |
905 271 40
|
Shackle |
4 |
InternKon: 931 620 40 / 11
|
|
|
|
20 |
462 208 40
|
Catch |
8 |
InternKon: 931 620 40 / 10
|
|
|
|
21 |
332 338 99
|
Nut |
1 |
InternBDB: M 20 | InternKon: 931 620 40 / 91
|
|
|
|
22 |
307 826 99
|
Bolt |
16 |
InternBDB: M16x50 /933 | InternKon: 931 620 40 / 14
|
|
|
|
23 |
534 008 99
|
Cover plate |
38 |
InternBDB: S-DP-A-4 | InternKon: 931 620 40 / 78
|
|
|
|
24 |
510 151 98
|
Bolt |
40 |
InternBDB: M12x120 /931 | InternKon: 931 620 40 / 79
|
|
|
|
25 |
332 334 99
|
Nut |
98 |
InternBDB: M 12 /934 | InternKon: 931 620 40 / 80
|
|
|
|
26 |
894 924 40
|
Connecting block |
1 |
InternKon: 931 620 40 / 73
|
|
|
|
27 |
512 885 98
|
Pair of clamps |
6 |
InternBDB: S-4-R-50 | InternKon: 931 620 40 / 86
|
|
|
|
28 |
505 440 98
|
Pair of clamps |
14 |
InternBDB: S-4-R-65 | InternKon: 931 620 40 / 87
|
|
|
|
29 |
504 445 98
|
Pair of clamps |
9 |
InternBDB: S-4-R-65-AL | InternKon: 931 620 40 / 82
|
|
|
|
30 |
502 976 98
|
Pair of clamps |
9 |
InternBDB: S-4-R-50-AL | InternKon: 931 620 40 / 81
|
|
|
|
31 |
500 129 98
|
Flange |
4 |
InternBDB: FE 3800-20/6 /011 747 99 | InternKon: 931 620 40 / 67
|
|
|
|
32 |
501 871 98
|
Ring |
4 |
InternBDB: K-3850-20 | InternKon: 931 620 40 / 68
|
|
|
|
33 |
356 210 40
|
Flange seal |
4 |
InternBDB: 1 1/4 NBR 90 | InternKon: 931 620 40 / 69
|
|
|
|
34 |
319 209 99
|
Bolt |
16 |
InternBDB: M14x45 /912 | InternKon: 931 620 40 / 70
|
|
|
|
35 |
500 127 98
|
Flange |
16 |
InternBDB: FE-5000-24/6 | InternKon: 931 620 40 / 59
|
|
|
|
36 |
501 898 98
|
Ring |
10 |
InternBDB: K-5060-24 | InternKon: 931 620 40 / 65
|
|
|
|
37 |
356 209 40
|
Flange seal |
20 |
InternBDB: 1 1/2 NBR 90 | InternKon: 931 620 40 / 60
|
|
|
|
38 |
319 289 99
|
Bolt |
40 |
InternBDB: M16x60 /912 | InternKon: 931 620 40 / 66
|
|
|
|
39 |
504 448 98
|
Flange |
18 |
InternBDB: FE-6500-32/6 | InternKon: 931 620 40 / 54
|
|
|
|
40 |
504 461 98
|
Ring |
8 |
InternBDB: K-6580-32 | InternKon: 931 620 40 / 71
|
|
|
|
41 |
385 243 40
|
Flange seal |
26 |
InternBDB: 2 NBR 90 | InternKon: 931 620 40 / 55
|
|
|
|
42 |
319 323 99
|
Bolt |
32 |
InternBDB: M20x90 /912 | InternKon: 931 620 40 / 72
|
|
|
|
43 |
500 203 98
|
Ring |
6 |
InternBDB: KO-5060-24 | InternKon: 931 620 40 / 61
|
|
|
|
44 |
319 292 99
|
Bolt |
40 |
InternBDB: M16x90 /912 | InternKon: 931 620 40 / 62
|
|
|
|
45 |
332 355 99
|
Nut |
46 |
InternBDB: M 16 /934 | InternKon: 931 620 40 / 63
|
|
|
|
46 |
504 449 98
|
Ring |
10 |
InternBDB: KO-6580-32 | InternKon: 931 620 40 / 56
|
|
|
|
47 |
319 313 99
|
Bolt |
56 |
InternBDB: M20x120 /912 | InternKon: 931 620 40 / 57
|
|
|
|
48 |
332 338 99
|
Nut |
56 |
InternBDB: M 20 /934 | InternKon: 931 620 40 / 58
|
|
|
|
49 |
319 305 99
|
Bolt |
16 |
InternBDB: M20x60 /912 | InternKon: 931 620 40 / 64
|
|
|
|
50 |
940 366 40
|
Hose assy. DN 50x1810 |
2 |
InternBDB: SHL NW 50 GH466-32X 1810 FS2/FS2 90 | InternKon: 931 620 40 / 29
|
|
|
|
51 |
933 086 40
|
Manifold |
1 |
InternKon: 931 620 40 / 19
|
|
|
|
52 |
334 695 99
|
Nut |
8 |
InternBDB: M 16 / 985 | InternKon: 931 620 40 / 22
|
|
|
|
53 |
319 304 99
|
Bolt |
4 |
InternBDB: M16x70 /912 | InternKon: 931 620 40 / 21
|
|
|
|
54 |
319 291 99
|
Bolt |
4 |
InternBDB: M 16 x 80 / 912 | InternKon: 931 620 40 / 74
|
|
|
|
55 |
321 539 99
|
Bolt |
4 |
InternBDB: M 14 x 100 / 912 | InternKon: 931 620 40 / 75
|
|
|
|
56 |
940 318 40
|
Hose assy. DN 50x2100 |
2 |
InternBDB: SHL NW 50 GH466-32X 2100 FS2/FS2 | InternKon: 931 620 40 / 31
|
|
|
|
57 |
940 321 40
|
Hose assy. DN 50x2400 |
2 |
InternBDB: SHL NW 50 GH466-32X 2400 FS2/FS2 | InternKon: 931 620 40 / 32
|
|
|
|
58 |
515 911 98
|
Hose assy. DN 40x1600 |
2 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 /341 951 40 | InternKon: 931 620 40 / 30
|
|
|
|
59 |
386 162 40
|
Hose assy. DN 40x2400 |
2 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 /341 951 40 | InternKon: 931 620 40 / 33
|
|
|
|
60 |
768 266 73
|
Pipe assy. Ш 38 kpl. |
1 |
InternBDB: 894 939 40 | InternKon: 931 620 40 / 38
|
|
|
|
62 |
767 972 73
|
Pipe assy. Ш 38 kpl. |
1 |
InternBDB: 890 853 40 | InternKon: 931 620 40 / 39
|
|
|
|
63 |
793 165 73
|
Pipe assy. Ш 50 kpl. |
1 |
InternBDB: 911 841 40 | InternKon: 931 620 40 / 41
|
|
|
|
64 |
793 166 73
|
Pipe assy. Ш 50 kpl. |
1 |
InternBDB: 911 837 40 | InternKon: 931 620 40 / 35
|
|
|
|
65 |
793 167 73
|
Pipe assy. Ш 50 kpl. |
1 |
InternBDB: 911 839 40 | InternKon: 931 620 40 / 37
|
|
|
|
66 |
795 039 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 933 097 40 | InternKon: 931 620 40 / 45
|
|
|
|
67 |
793 169 73
|
Pipe assy. Ш 50 kpl. |
1 |
InternBDB: 911 846 40 | InternKon: 931 620 40 / 46
|
|
|
|
68 |
793 170 73
|
Pipe assy. Ш 50 kpl. |
1 |
InternBDB: 911 852 40 | InternKon: 931 620 40 / 52
|
|
|
|
69 |
793 171 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 911 851 40 | InternKon: 931 620 40 / 51
|
|
|
|
70 |
794 774 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 929 798 40 | InternKon: 931 620 40 / 43
|
|
|
|
71 |
767 981 73
|
Pipe assy. Ш 50 kpl. |
1 |
InternBDB: 890 862 40 | InternKon: 931 620 40 / 40
|
|
|
|
72 |
793 173 73
|
Pipe assy. Ш 50 kpl. |
1 |
InternBDB: 911 847 40 | InternKon: 931 620 40 / 47
|
|
|
|
73 |
793 174 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 911 842 40 | InternKon: 931 620 40 / 42
|
|
|
|
74 |
794 775 73
|
Pipe assy. Ш 65 kpl. |
2 |
InternBDB: 929 799 40 | InternKon: 931 620 40 / 44
|
|
|
|
75 |
794 776 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 933 001 40 | InternKon: 931 620 40 / 49
|
|
|
|
76 |
794 777 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 933 002 40 | InternKon: 931 620 40 / 50
|
|
|
|
77 |
793 178 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 911 836 40 | InternKon: 931 620 40 / 34
|
|
|
|
78 |
793 179 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 911 848 40 | InternKon: 931 620 40 / 48
|
|
|
|
79 |
793 152 73
|
Pipe assy. Ш 65 kpl. |
1 |
InternBDB: 911 838 40 | InternKon: 931 620 40 / 36
|
|
|
|
80 |
173 494 40
|
Plug |
1 |
InternBDB: VSTI M 33 x 2,0 / 341 913 40 | InternKon: 931 620 40 / 76
|
|
|
|
81 |
693 228
|
Seal |
1 |
InternBDB: ED 33 x 2
|
|
|
|
82 |
319 290 99
|
Bolt |
4 |
InternBDB: M 16x120 / 912 | InternKon: 931 620 40 / 24
|
|
|
|
83 |
940 324 40
|
Hose assy. DN 50x2800 |
2 |
InternBDB: SHL NW 50 GH466-32X 2800 FS2/FS2 | InternKon: 931 620 40 / 27
|
|
|
|
84 |
515 901 98
|
Hose assy. DN 40x2800 |
2 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 /341 951 40 | InternKon: 931 620 40 / 28
|
|
|
|
85 |
168 474 40
|
Plug |
2 |
InternBDB: M 42x2 | InternKon: 931 620 40 / 83
|
|
|
|
86 |
911 830 40
|
Pipe bridge |
1 |
InternKon: 931 620 40 / 26
|
|
|
|
87 |
342 085 99
|
Cotter pin |
1 |
InternBDB: 5x50 | InternKon: 931 620 40 / 92
|
|
|
|
88 |
319 442 99
|
Bolt |
1 |
InternBDB: M 16x40 | InternKon: 931 620 40 / 93
|
|
|
|
89 |
905 205 40
|
Catch |
4 |
InternBDB: 40x260 | InternKon: 931 620 40 / 94
|
|
|
|
90 |
502 965 98
|
Cover plate |
4 |
InternBDB: S-DP-S-4 | InternKon: 931 620 40 / 85
|
|
|
|
91 |
409 329 40
|
Cap |
1 |
InternKon: 931 620 40 / 13
|
|
|
|
92 |
933 098 40
|
Bracket |
1 |
InternKon: 931 620 40 / 95
|
|
|
|
93 |
308 640 99
|
Bolt |
4 |
InternBDB: M16x120/931 | InternKon: 931 620 40 / 96
|
|
|
|
94 |
502 371 98
|
Pair of clamps |
10 |
InternBDB: S-4-E | InternKon: 931 620 40 / 97
|
|
|
|
95 |
304 322 99
|
Bolt |
4 |
InternBDB: M12x160/931 10.9 | InternKon: 931 620 40 / 98
|
|
|
|
96 |
502 626 98
|
Grommet |
10 |
InternBDB: S-4-56,4 | InternKon: 931 620 40 / 99
|
|
|
|
97 |
308 616 99
|
Bolt |
22 |
InternBDB: M12x140/931 | InternKon: 931 620 40 / 100
|
|
|
|
98 |
517 118 98
|
Lock washer |
26 |
InternBDB: 12 WN 65593840 | InternKon: 931 620 40 / 101
|
|
|
|
99 |
509 064 98
|
Pair of clamps |
8 |
InternBDB: S-5-E | InternKon: 931 620 40 / 102
|
|
|
|
100 |
500 398 98
|
Cover plate |
8 |
InternBDB: S-DP-A-5 | InternKon: 931 620 40 / 103
|
|
|
|
101 |
516 024 98
|
Grommet |
6 |
InternBDB: S-5-70 | InternKon: 931 620 40 / 104
|
|
|
|
102 |
308 643 99
|
Bolt |
6 |
InternBDB: M16x160/931 | InternKon: 931 620 40 / 105
|
|
|
|
103 |
307 825 99
|
Bolt |
3 |
InternBDB: M16x45/933 | InternKon: 931 620 40 / 106
|
|
|
|
104 |
928 526 40
|
Guard plate |
1 |
InternKon: 931 620 40 / 107
|
|
|
|
105 |
928 528 40
|
Guard plate |
1 |
InternKon: 931 620 40 / 108
|
|
|
|
106 |
308 612 99
|
Bolt |
32 |
InternBDB: M 12x100 / DIN 931 | InternKon: 931 620 40 / 115
|
|
|
|
110 |
940 314 40
|
Hose assy. DN 50x1600 |
2 |
InternBDB: SHL NW 50 GH466-32X 1600 FS2/FS2 | InternKon: 931 620 40 / 110
|
|
|
|
111 |
500 399 98
|
Weld on plate |
2 |
InternBDB: S-AP-A-5 W1 DIN 03015 | InternKon: 931 620 40 / 119
|
|
|
|
112 |
515 846 98
|
Insert |
2 |
InternBDB: S-5-57 GUMMI DIN 03015 | InternKon: 931 620 40 / 120
|
|
|
|
113 |
514 060 98
|
Bolt |
4 |
InternBDB: M16X 260 8.8 DIN 00931 | InternKon: 931 620 40 / 121
|
|
|
|
114 |
534 005 99
|
Weld on plate |
1 |
InternBDB: S-AP-A-3 W1 DIN 03015 | InternKon: 931 620 40 / 122
|
|
|
|
115 |
518 032 98
|
Pair of clamps |
1 |
InternBDB: S-3-E PA DIN 03015 | InternKon: 931 620 40 / 123
|
|
|
|
116 |
534 004 99
|
Cover plate |
1 |
InternBDB: S-DP-A-3 W1 DIN 03015 | InternKon: 931 620 40 / 124
|
|
|
|
117 |
504 926 98
|
Grommet |
1 |
InternBDB: S-3-32 GUMMI DIN 03015 | InternKon: 931 620 40 / 125
|
|
|
|
118 |
308 581 99
|
Bolt |
2 |
InternBDB: M10X 70 8.8 DIN 00931 | InternKon: 931 620 40 / 126
|
|
|
|
119 |
517 122 98
|
Lock washer |
2 |
InternBDB: 10 STZN WN 65593840 | InternKon: 931 620 40 / 127
|
|
