01 |
|
Hydr. cylinder |
1 |
InternBDB: 926 870 40 | InternKon: 924 969 40 / 1
|
485-4281a |
|
|
02 |
912 683 40
|
Piping, assy. r.h. fig-nos. 05-33 |
1 |
InternBDB: E-ST | InternKon: 924 969 40 / 2
|
|
|
|
03 |
912 682 40
|
Piping, assy. l.h. fig-nos. 05-33 |
1 |
InternBDB: E-ST | InternKon: 924 969 40 / 2
|
|
|
|
05 |
910 174 40
|
Clamp clip |
1 |
InternBDB: 368 | InternKon: 912 683 40 / 1
|
|
|
|
06 |
910 176 40
|
Retainer |
1 |
InternBDB: 312 | InternKon: 912 683 40 / 2
|
|
|
|
07 |
513 303 98
|
Connecting block 2" |
1 |
InternKon: 912 683 40 / 6
|
|
|
|
08 |
513 302 98
|
Connecting block 1 1/2" |
1 |
InternKon: 912 683 40 / 7
|
|
|
|
09 |
793 229 73
|
Pipe assy.Ш 50 |
1 |
InternBDB: 910 178 40 | InternKon: 912 683 40 / 3
|
|
|
|
10 |
793 230 73
|
Pipe assy.Ш 65 |
1 |
InternBDB: 910 179 40 | InternKon: 912 683 40 / 4
|
|
|
|
11 |
505 440 98
|
Pair of clamps |
1 |
InternBDB: S-4-R-65 | InternKon: 912 683 40 / 8
|
|
|
|
12 |
534 008 99
|
Cover plate |
3 |
InternBDB: S-DP-A-4 | InternKon: 912 683 40 / 10
|
|
|
|
13 |
504 448 98
|
Flange |
2 |
InternBDB: FE 6500-32/6 | InternKon: 912 683 40 / 12
|
|
|
|
14 |
504 449 98
|
Collar ring |
1 |
InternBDB: KO-6580-32 | InternKon: 912 683 40 / 14
|
|
|
|
15 |
504 461 98
|
Collar ring |
1 |
InternBDB: K-6580-32 | InternKon: 912 683 40 / 16
|
|
|
|
16 |
385 243 40
|
Quadring |
2 |
InternBDB: 2" NBR 90 | InternKon: 912 683 40 / 18
|
|
|
|
18 |
356 209 40
|
Quadring |
2 |
InternBDB: 1 1/2" NBR 90 | InternKon: 912 683 40 / 19
|
|
|
|
20 |
319 323 99
|
Bolt |
4 |
InternBDB: M 20x90 / 912 | InternKon: 912 683 40 / 20
|
|
|
|
21 |
308 424 99
|
Bolt |
4 |
InternBDB: M 16x110 / 931 | InternKon: 912 683 40 / 23
|
|
|
|
22 |
308 414 99
|
Bolt |
4 |
InternBDB: M 20x130 / 931 | InternKon: 912 683 40 / 22
|
|
|
|
23 |
308 434 99
|
Bolt |
2 |
InternBDB: M 12x115 / 931 | InternKon: 912 683 40 / 24
|
|
|
|
24 |
308 615 99
|
Bolt |
4 |
InternBDB: M 12x130 / 931 | InternKon: 912 683 40 / 25
|
|
|
|
25 |
334 601 99
|
Nut |
8 |
InternBDB: M 16 / 8 | InternKon: 912 683 40 / 27
|
|
|
|
26 |
340 469 99
|
Washer |
2 |
InternBDB: Ш 17 / 140HV | InternKon: 912 683 40 / 28
|
|
|
|
27 |
509 310 98
|
Locking plate |
2 |
InternBDB: SI 6 | InternKon: 912 683 40 / 5
|
|
|
|
28 |
512 885 98
|
Pair of clamps |
2 |
InternBDB: S-4-R-50 | InternKon: 912 683 40 / 9
|
|
|
|
29 |
500 127 98
|
Flange |
2 |
InternBDB: FE 5000-24/6 | InternKon: 912 683 40 / 13
|
|
|
|
30 |
500 203 98
|
Collar ring |
1 |
InternBDB: KO-5060-24 | InternKon: 912 683 40 / 15
|
|
|
|
31 |
501 898 98
|
Collar ring |
1 |
InternBDB: K-5060-24 | InternKon: 912 683 40 / 17
|
|
|
|
32 |
319 289 99
|
Bolt |
4 |
InternBDB: M 16x60 / 912 | InternKon: 912 683 40 / 21
|
|
|
|
33 |
334 600 99
|
Nut |
4 |
InternBDB: M 12 | InternKon: 912 683 40 / 26
|
|
