PC3000-6 S/N 46174

Komatsu parts book diagram for PC3000-6 S/N 46174: BACKHOE STICK 4,0M

01 02 03 03 04 04 05 05 06 06 07 07 08 08 09 09 09 09 09 09 09 09 11 11 12 13 15 16 16 17 17 18 18 20

	#	Part Number	Partname	Quantity	Options	Reference
	01	913 050 40	Stick assy.	1
	02	913 060 40	Stick ( weldment )	1	InternKon: 913 050 40 / 1
	03	934 019 40	Freeze-in bushing	2	InternKon: 913 050 40 / 2
	04	911 854 40	Flanged bush	2	InternKon: 913 050 40 / 3
	05	911 858 40	Flanged bush	2	InternKon: 913 050 40 / 4
	06	900 690 40	Freeze-in bushing	2	InternKon: 913 050 40 / 5
	07	911 857 40	Freeze-in bushing	2	InternKon: 913 050 40 / 6
	08	907 028 40	Seal ring	2	InternKon: 913 050 40 / 7
	09	907 020 40	Seal ring	8	InternKon: 913 050 40 / 8
	11	911 855 40	Ring	2	InternKon: 913 050 40 / 9
	12	907 441 40	Clevis	2	InternBDB: C14 VC-Sch 4,0 / 7984331 RUD \| InternKon: 913 050 40 / 10
	13	907 440 40	Link oval	2	InternBDB: A40 15T Globus \| InternKon: 913 050 40 / 11
	15	908 934 40	Pin with plate (Standard)	2	InternBDB: 150x395 \| InternKon: 938 838 40 / 3
	15	923 845 40	Pin with plate (Cold weather design)	2	InternBDB: 938 838/9 40 Pos. 3 \| InternKon: 938 838 40 / 3
	16	905 749 40	Shackle	4	InternBDB: 187 \| InternKon: 938 838 40 / 4
	17	307 886 99	Bolt	8	InternBDB: M 24x55 / 933 \| InternKon: 938 838 40 / 5
	18	002 027 79	Washer	8	InternBDB: 77 \| InternKon: 938 838 40 / 6
	20	913 909 40	Pin with plate (Standard)	2	InternBDB: 150x420 \| InternKon: 931 500 40 / 3
	20	938 833 40	Pin with plate (Cold weather design)	2	InternBDB: 938 831 40 Pos. 3

Komatsu PC3000-6 S/N 46174 parts catalog PDF

BACKHOE STICK 4,0M (485-4210b) in PC3000-6 S/N 46174. Diagram image and parts list.
