PC5500-6 S/N 15056

Komatsu parts book diagram for PC5500-6 S/N 15056: PUMP MOUNTING (FRONT/REAR)

01 01 01 02 03 04 05 06 07 07 07 08 08 09 09 09 10 10 11 11 11 12 12 12 13 13 13 20 20 20 21 21 21

	#	Part Number	Partname	Quantity	Options	Reference
	01		Main pumps	6	InternBDB: 655 564 40 \| InternKon: 913 528 40 / 1	991-0263a
	02	940 048 40	Circulation pump	2	InternBDB: Kracht KP3/71 S20G Q00 6VL2/405 \| InternKon: 913 528 40 / 2	991-0492c
	03	940 048 40	Gear oil pump	2	InternBDB: Kracht KP3/71 S20G Q00 6VL2/405 \| InternKon: 913 528 40 / 2	991-0492c
	04	907 622 40	Pilot pump	2	InternBDB: Kracht KP3/82 S20J Q00 6VL2/405 \| InternKon: 913 528 40 / 6	991-0492c
	05		Fan pump ( water )	2	InternBDB: 896 443 40 \| InternKon: 913 528 40 / 4	991-0165
	06		Fan pump ( oil )	2	InternBDB: 896 443 40 \| InternKon: 913 528 40 / 4	991-0165
	07	307 804 99	Bolt	24	InternBDB: M12 x 30 / 933
	08	307 806 99	Bolt	16	InternBDB: M12 x 40 / 933 \| InternKon: 913 528 40 / 13
	09	500 152 98	O-ring	6	InternBDB: 315 x 5 / 3771 83 FPM
	10	958 230	O-ring	4	InternBDB: 140 x 3
	11	621 666 40	Splined hub	6	InternBDB: Brьninghaus A4VS 500 1 1/4" SO \| InternKon: 913 528 40 / 3
	12	307 848 99	Bolt	48	InternBDB: M20 x 65 / 933 8.8 \| InternKon: 913 528 40 / 10
	13	340 470 99	Washer	48	InternBDB: B 21 / 125 \| InternKon: 913 528 40 / 11
	20	767 135 73	O-ring	3	InternBDB: 102x3 / 80 Viton
	21	795 493 73	Gasket set	1	InternBDB: Kracht KP 3-6DL2/405 (P.016142...)

Komatsu PC5500-6 S/N 15056 parts catalog PDF

PUMP MOUNTING (FRONT/REAR) (515-1230g) in PC5500-6 S/N 15056. Diagram image and parts list.
