01 |
912 486 40
|
Holding device, muffler |
2 |
InternKon: 925 822 40 / 2
|
|
|
|
02 |
914 540 40
|
Exhaust pipe |
2 |
InternKon: 925 822 40 / 9
|
|
|
|
03 |
925 818 40
|
Exhaust pipe |
2 |
InternKon: 925 822 40 / 8
|
|
|
|
04 |
924 373 40
|
Holding device, muffler |
2 |
InternKon: 925 822 40 / 1
|
|
|
|
05 |
906 476 40
|
Weather protecting cap |
4 |
InternBDB: 10" | InternKon: 925 822 40 / 4
|
|
|
|
06 |
894 258 40
|
Strap retainer |
8 |
InternKon: 925 822 40 / 5
|
|
|
|
07 |
210 976 40
|
Muffler |
4 |
InternBDB: 10" MOM19-0001 | InternKon: 925 822 40 / 3
|
|
|
|
09 |
635 521 40
|
Clamp |
8 |
InternBDB: D=152 | InternKon: 925 822 40 / 7
|
|
|
|
11 |
635 520 40
|
Flex. pipe |
4 |
InternKon: 925 822 40 / 6
|
|
|
|
12 |
502 434 98
|
Bolt |
32 |
InternBDB: M16x90 / 933 / 10.9 | InternKon: 925 822 40 / 19
|
|
|
|
13 |
510 733 98
|
Resilient sleeve |
32 |
InternBDB: 17/30x50 / 34194840 | InternKon: 925 822 40 / 20
|
|
|
|
14 |
332 355 99
|
Nut |
32 |
InternBDB: M 16 / 934 / 10 | InternKon: 925 822 40 / 21
|
|
|
|
15 |
332 336 99
|
Nut |
32 |
InternBDB: M 16 / 934 / 8 | InternKon: 925 822 40 / 22
|
|
|
|
17 |
307 779 99
|
Bolt |
16 |
InternBDB: M10x30 /933 / 8.8 | InternKon: 925 822 40 / 11
|
|
|
|
18 |
507 037 98
|
Nut |
24 |
InternBDB: M 10 /985 / 8.8 | InternKon: 925 822 40 / 12
|
|
|
|
20 |
334 600 99
|
Nut |
20 |
InternBDB: M 12 / 895 | InternKon: 925 822 40 / 17
|
|
|
|
21 |
340 688 99
|
Washer |
16 |
InternBDB: 17 / 7349 | InternKon: 925 822 40 / 23
|
|
|
|
22 |
894 268 40
|
Pipe |
4 |
InternBDB: 255x2x110 | InternKon: 925 822 40 / 18
|
|
|
|
25 |
909 632 40
|
Plate |
4 |
InternKon: 925 822 40 / 9
|
|
|
|
26 |
768 740 73
|
Clamp |
4 |
InternBDB: Cu 3 016 306
|
|
|
|
27 |
894 302 40
|
Muffler connection pipe |
4 |
InternBDB: PC 3000-1 | InternKon: 925 822 40 / 24
|
|
|
|
29 |
340 465 99
|
Washer |
24 |
InternBDB: B 10,5 /125 | InternKon: 925 822 40 / 13
|
|
|
|
30 |
230 179 40
|
Half clamp |
4 |
InternKon: 925 822 40 / 14
|
|
|
|
31 |
230 178 40
|
Half clamp |
4 |
InternKon: 925 822 40 / 15
|
|
|
|
32 |
307 806 99
|
Bolt |
8 |
InternBDB: M 12x40 / 933 / 8.8 | InternKon: 925 822 40 / 16
|
|
