CABLES - CAB SUPPORT | H285 S/N 78099 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	323 950 40	Cable union	7	InternBDB: Sievert 5010.100.009
02	504 546 99	Cable nut	7	InternBDB: HPG9 /46258
03	324 217 40	Mounting box	2	InternBDB: Contact 10.4620
04	501 677 98	Cable nut	3	InternBDB: APG 21 /46258
05	323 354 40	Union	3	InternBDB: Sievert 5010.100.021
06	358 223 40	Mounting box	5	InternBDB: Contact 10.4720
07	356 242 40	Conduit Bulk ware, state length required	-2	InternBDB: Sievert 220.101.021
08	356 241 40	Conduit Bulk ware, state length required	-2	InternBDB: 220.101.017
09	356 238 40	Conduit Bulk ware, state length required	-2	InternBDB: 220.101.010
10	358 273 40	Series clamping	-2	InternBDB: Sievert 225 5014
11	358 274 40	Series clamping	-2	InternBDB: 225 5022
12	385 224 40	Socket	5	InternBDB: Contact 10.5830
13	385 225 40	Plug insert (1-16)	7	InternBDB: 10.5330
14	385 226 40	Plug insert (17-32)	5	InternBDB: 10.5430
15	358 264 40	Protecting cover	5	InternBDB: 10.4816
16	358 261 40	Protecting cover	2	InternBDB: Contact 10.4695
17	358 263 40	Protecting cover	5	InternBDB: 10.4815
18	323 953 40	Cable union	4	InternBDB: 5010.100.016
19	600 805 99	Cable nut	4	InternBDB: APG16 /46258
20	385 227 40	Insert (1-16)	7	InternBDB: Contact 10.5320
21	385 228 40	Insert (17-32)	5	InternBDB: 10.5420
22	697 772 73	Plug	2	InternBDB: Sievert PG 16 2466394
23	697 773 73	Plug	1	InternBDB: PG 9 2466391
24	320 816 99	Screw	8	InternBDB: AM5x10 /84
25	340 462 99	Washer	8	InternBDB: 5,3 /125
26	332 109 99	Nut	8	InternBDB: M5 /934
27	356 250 40	Socket	8	InternBDB: Sievert 520.030.021
28	358 262 40	Protecting cover	2	InternBDB: Contact 10.4696
29	358 222 40	Socket	2	InternBDB: 10.5820
30	356 249 40	Socket	2	InternBDB: Sievert 520.030.016
31	356 246 40	Socket	4	InternBDB: 520.030.009
32	358 286 40	Diaphragm-type press. accum. 5 bar	2	InternBDB: Suco 7032-3/5 bar
33	323 592 40	Protection cap	2	InternBDB: Suco 701.00.08
34	440 151 99	Receptacle for tabs	4	InternBDB: He. u. Bu. 50.252.510
35	323 954 40	Plug-in sleeve	2	InternBDB: Sievert 5031.028.007
36	056 211 40	Conduit Bulk ware, state length required	-2	InternBDB: x
37	270 788 40	Cable Bulk ware, state length required	-2	InternBDB: 2x0,75
38	006 300 98	Clamp	10	InternBDB: RSGU 1100. 10/15 011 660 99
39	343 092 99	Lock washer	10	InternBDB: 4 /128
40	332 442 99	Nut	10	InternBDB: M 4 /934
41	697 774 73	Reduction PG 11-7	1	InternBDB: Sievert 2466441/11/7
42	697 775 73	Reduction PG 9-7	-2	InternBDB: 2466440/9/7
43	323 949 40	Cable union	-2	InternBDB: 5010.100.007
44	502 609 98	Cable Bulk ware, state length required	-2	InternBDB: 1 qmm bl.
45	471 719 99	Cable Bulk ware, state length required	-2	InternBDB: 6 qmm
46	471 861 99	Cable Bulk ware, state length required	-2	InternBDB: 1,5 qmm
47	502 825 98	Cable nut	-2	InternBDB: APG 7 /46258
48	320 975 99	Screw	20	InternBDB: AM 4x16 /84
