H285 S/N 78099

Komatsu parts book diagram for H285 S/N 78099: CABLES - ENGINE, CU

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	356 242 40	Protecting hose PG 21 Bulk ware, state length required	-2	InternBDB: 220.101.021
	?	356 238 40	Protecting hose PG 9 Bulk ware, state length required	-2	InternBDB: 220.101.010
	?	356 239 40	Protecting hose PG 11 Bulk ware, state length required	-2	InternBDB: 220.101.013
	?	356 250 40	Socket	8	InternBDB: Sievert 520.030.21
	?	356 246 40	Socket	6	InternBDB: 520.030.009
	?	356 247 40	Socket	4	InternBDB: 520.030.011
	?	471 861 99	Cable Bulk ware, state length required	-2	InternBDB: 1 qmm
	?	471 719 99	Cable Bulk ware, state length required	-2	InternBDB: 6 qmm
	?	255 745 40	Rubber grommet	6	InternBDB: Soeffing 313.0558.000
	?	056 076 40	Rubber grommet	4
	?	006 302 98	Clamp	20	InternBDB: RSGU 1100 15/15

Komatsu H285 S/N 78099 parts catalog PDF

CABLES - ENGINE, CU (114-2182) in H285 S/N 78099. Diagram image and parts list.
